Planet SGSW-24240 [217/328] User s manual of wgsw 24040 wgsw 24040r sgsw 24040 sgsw 24040r

User’s Manual of WGSW-24040 / WGSW-24040R

SGSW-24040 / SGSW-24040R

217

A PD shall return Class 0 to 3 in accordance with the maximum power draw as specified by Table 4-17-1.

Class Usage Range of maximum power used by the PD

0 Default 0.44 to 12.95 Watts

1 Optional 0.44 to 3.84 Watts

2 Optional 3.84 to 6.49 Watts

3 Optional 6.49 to 12.95 Watts

4 Not Allowed Reserved for Future Use

Table 4.17-1 Device class

Class 4 is defined but is reserved for future use. A Class 4 signature cannot be provided by a

compliant PD.
