User’s Manual of WGSW-24040 / WGSW-24040R
SGSW-24040 / SGSW-24040R
22
WGSW / SGSW all models
Product All Models
Layer 2 function
System Configuration
Console, Telnet, Web Browser, SNMPv1, v2c and v3
Port configuration
Port disable/enable.
Auto-negotiation 10/100/1000Mbps full and half duplex mode selection.
Flow Control disable / enable.
Bandwidth control on each port.
Port Status
Display each port’s speed duplex mode, link status, Flow control status. Auto
negotiation status, trunk status.
VLAN
802.1Q Tagged Based VLAN ,up to 255 VLAN groups
Q-in-Q
Private VLAN
Port trunking
IEEE 802.3ad LACP / Static Trunk
Support 12 groups of 16-Port trunk support
QoS
Traffic classification based, Strict priority and WRR
4-level priority for switching
- Port Number
- 802.1p priority
- DS/TOS field in IP Packet
IGMP Snooping
IGMP (v1/v2) Snooping, up to 255 multicast Groups
IGMP Querier mode support
Access Control List
IP-Based ACL / MAC-Based ACL
Up to 256 entries
SNMP MIBs
RFC-1213 MIB-II
IF-MIB
RFC-1493 Bridge MIB
RFC-1643 Ethernet MIB
RFC-2863 Interface MIB
RFC-2665 Ether-Like MIB
RFC-2737 Entity MIB
RFC-2618 RADIUS Client MIB
RFC-2933 IGMP-STD-MIB ()
RFC3411 SNMP-Frameworks-MIB
IEEE802.1X PAE
LLDP
MAU-MIB
Standards Conformance
Regulation Compliance
FCC Part 15 Class A, CE
