User’s Manual of WGSW-24040 / WGSW-24040R
SGSW-24040 / SGSW-24040R
20
Jumbo Frame
10Kbytes
LED
Power, Link/Act and speed per Gigabit port
Power Consumption
Max. 30 watts / 102 BTU
Power Requirement – AC
AC 100~240V, 50/60Hz AC : 100~240V, 50/60Hz
Power Requirement – DC
---
-48V DC @ 0.6A
Range: -30 ~ -60V
Stacking Numbers
---
Stacking Bandwidth
---
Stack ID Display
---
SGSW Stackable / Fiber models
Product SGSW-24040 SGSW-24040R SGSW-24240 SGSW-24240R
Hardware Specification
Copper Ports
24 10/ 100/1000Base-T RJ-45
Auto-MDI/MDI-X ports
8 10/ 100/1000Base-T RJ-45
Auto-MDI/MDI-X ports, shared with
Port-1~Port-8
SFP/mini-GBIC Slots
4 SFP interfaces, shared with Port-21 to
Port-24
24 100/1000Base-X Dual Speed SFP
interfaces
Stacking Ports
2 5GbE / Cross-HDMI interface
Switch Fabric
68Gbps
Address Table
8K entries
Share data Buffer
1392 kilobytes
Switch Processing Scheme
Store-and-Forward
Flow Control
IEEE 802.3x Pause Frame for Full-Duplex
Back pressure for Half-Duplex
Jumbo Frame
10Kbytes
LED
Power, Stack Master, Stack Port LNK, Link/Act and speed per Gigabit port
Power Consumption
Max. 30.2 watts /
102.98 BTU
Max. 30.2 watts /
102.98 BTU
Max. 33.2 watts /
113.21 BTU
Max. 33.2 watts /
113.21 BTU
Power Requirement – AC
AC 100~240V,
50/60Hz
AC : 100~240V,
50/60Hz
AC 100~240V,
50/60Hz
AC : 100~240V,
50/60Hz
Power Requirement – DC
---
-48V DC @ 0.6A
Range: -30 ~ -60V
---
-48V DC @ 0.6A
Range: -30 ~ -60V
Stacking Numbers
16
Stacking Bandwidth
10Gbps Full-Duplex
Stack ID Display
7-Segment LED Display (1~9, A~F,0)
