User’s Manual of WGSW-24040 / WGSW-24040R

SGSW-24040 / SGSW-24040R

Figure 4-5-3 Aggregation Group Configuration page screenshot

The page includes the following fields:

Object Description

• Locality

Indicates the aggregation group type. This field is only valid for stackable

switches.

•

Global: The group members may reside on different units in the stack. The

device supports two 8-port global aggregations.

•

Local: The group members reside on the same unit. Each local

aggregation may consist of up to 16 members.

• Group ID

Indicates the group ID for the settings contained in the same row. Group ID

"Normal" indicates there is no aggregation. Only one group ID is valid per port.

• Port Members

Each switch port is listed for each group ID. Select a radio button to include a port

in an aggregation, or clear the radio button to remove the port from the

aggregation. By default, no ports belong to any aggregation group.
