Daikin REYQ14PY1B [25/137] Capacity tables
![Daikin REYQ14PY1B [25/137] Capacity tables](/views2/1713627/page25/bg19.png)
• Outdoor Units • VRV HEAT RECOVERY • REYQ8-48P7Y1B
1
3
• VRV Systems • Outdoor Units
24
3 Capacity tables
3 - 2 Cooling capacity tables
REYQ24P
TC: Total capacity (kW); PI: Power input (kW) (Compressor + outdoor fan motor)
Combination
(%)
Capacity index
Outdoor air
temp. °CDB
Indoor air temp.: °CWB
14°C 16°C 18°C 19°C 20°C 22°C 24°C
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW KW KW
130 (780) 10 58.8 8.84 70.1 10.8 81.4 12.9 84.4 12.9 85.4 12.9 87.6 12.9 89.7 12.9
12 58.8 9.00 70.1 11.0 81.4 13.1 83.3 13.1 84.4 13.1 86.5 13.1 88.6 13.1
14 58.8 9.17 70.1 11.2 81.1 13.3 82.2 13.3 83.3 13.3 85.4 13.3 87.5 13.3
16 58.8 9.35 70.1 11.5 80.1 13.2 81.1 13.3 82.2 13.3 84.3 13.3 86.4 13.3
18 58.8 9.53 70.1 11.7 79.0 13.7 80.0 13.8 81.1 13.9 83.2 14.0 85.3 14.1
20 58.8 9.72 70.1 12.4 77.9 14.4 78.9 14.5 80.0 14.5 82.1 14.7 84.2 14.8
21 58.8 10.00 70.1 12.9 77.3 14.7 78.4 14.8 79.5 14.9 81.6 15.0 83.7 15.2
23 58.8 10.7 70.1 13.8 76.2 15.4 77.3 15.5 78.4 15.6 80.5 15.7 82.6 15.9
25 58.8 11.4 70.1 14.8 75.2 16.1 76.2 16.2 77.3 16.2 79.4 16.4 81.5 16.6
27 58.8 12.2 70.1 15.8 74.1 16.7 75.1 16.8 76.2 16.9 78.3 17.1 80.4 17.3
29 58.8 13.0 70.1 16.9 73.0 17.4 74.0 17.5 75.1 17.6 77.2 17.8 79.3 18.0
31 58.8 13.9 69.8 17.9 71.9 18.1 72.9 18.2 74.0 18.3 76.1 18.5 78.2 18.7
33 58.8 14.8 68.7 18.6 70.8 18.8 71.9 18.9 72.9 19.0 75.0 19.2 77.1 19.4
35 58.8 15.8 67.6 19.3 69.7 19.5 70.8 19.6 71.8 19.7 73.9 19.9 76.1 20.1
37 58.8 16.8 66.5 19.9 68.6 20.2 69.7 20.3 70.7 20.4 72.9 20.6 75.0 20.9
39 58.8 17.9 65.4 20.6 67.5 20.9 68.6 21.0 69.6 21.1 71.8 21.4 73.9 21.6
120 (720) 10 54.3 8.08 64.7 9.87 75.2 11.7 80.4 12.7 84.1 12.7 86.1 12.7 88.0 12.7
12 54.3 8.23 64.7 10.1 75.2 12.0 80.4 12.9 83.0 12.9 85.0 12.9 86.9 12.9
14 54.3 8.38 64.7 10.2 75.2 12.2 80.4 13.2 81.9 13.2 83.9 13.2 85.8 13.2
16 54.3 8.54 64.7 10.4 75.2 12.4 79.9 13.3 80.8 13.3 82.8 13.3 84.8 13.3
18 54.3 8.70 64.7 10.6 75.2 12.8 78.8 13.7 79.7 13.8 81.7 13.9 83.7 14.0
20 54.3 8.87 64.7 11.1 75.2 13.8 77.7 14.4 78.7 14.4 80.6 14.6 82.6 14.7
21 54.3 8.96 64.7 11.5 75.2 14.3 77.1 14.7 78.1 14.8 80.1 14.9 82.0 15.1
23 54.3 9.57 64.7 12.3 75.1 15.3 76.0 15.4 77.0 15.5 79.0 15.6 80.9 15.7
25 54.3 10.2 64.7 13.1 74.0 16.0 75.0 16.1 75.9 16.1 77.9 16.3 79.8 16.4
27 54.3 10.9 64.7 14.1 72.9 16.6 73.9 16.7 74.8 16.8 76.8 17.0 78.8 17.1
29 54.3 11.6 64.7 15.0 71.8 17.3 72.8 17.4 73.8 17.5 75.7 17.7 77.7 17.8
31 54.3 12.4 64.7 16.0 70.7 18.0 71.7 18.1 72.7 18.2 74.6 18.4 76.6 18.5
33 54.3 13.2 64.7 17.1 69.6 18.7 70.6 18.8 71.6 18.9 73.5 19.1 75.5 19.3
35 54.3 14.1 64.7 18.2 68.5 19.4 69.5 19.5 70.5 19.6 72.4 19.8 74.4 20.0
37 54.3 15.0 64.7 19.4 67.4 20.0 68.4 20.2 69.4 20.3 71.4 20.5 73.3 20.7
39 54.3 15.9 64.4 20.5 66.3 20.7 67.3 20.8 68.3 21.0 70.3 21.2 72.2 21.4
110 (660) 10 49.7 7.34 59.3 8.93 68.9 10.6 73.7 11.5 78.5 12.3 84.6 12.6 86.4 12.6
12 49.7 7.47 59.3 9.10 68.9 10.8 73.7 11.7 78.5 12.6 83.5 12.9 85.3 12.9
14 49.7 7.60 59.3 9.27 68.9 11.0 73.7 11.9 78.5 12.8 82.4 13.1 84.2 13.1
16 49.7 7.74 59.3 9.45 68.9 11.2 73.7 12.1 78.5 13.1 81.3 13.3 83.1 13.3
18 49.7 7.89 59.3 9.63 68.9 11.5 73.7 12.5 78.4 13.7 80.2 13.8 82.0 13.9
20 49.7 8.05 59.3 9.83 68.9 12.1 73.7 13.4 77.3 14.4 79.1 14.5 80.9 14.6
21 49.7 8.12 59.3 10.1 68.9 12.6 73.7 13.9 76.8 14.7 78.6 14.8 80.4 14.9
23 49.7 8.50 59.3 10.8 68.9 13.5 73.7 14.9 75.7 15.4 77.5 15.5 79.3 15.6
25 49.7 9.08 59.3 11.6 68.9 14.4 73.7 16.0 74.6 16.0 76.4 16.2 78.2 16.3
27 49.7 9.69 59.3 12.4 68.9 15.4 72.6 16.6 73.5 16.7 75.3 16.9 77.1 17.0
29 49.7 10.3 59.3 13.2 68.9 16.5 71.5 17.3 72.4 17.4 74.2 17.5 76.0 17.7
31 49.7 11.0 59.3 14.1 68.9 17.6 70.4 18.0 71.3 18.1 73.1 18.2 74.9 18.4
33 49.7 11.7 59.3 15.0 68.4 18.6 69.3 18.7 70.2 18.7 72.0 18.9 73.8 19.1
35 49.7 12.5 59.3 16.0 67.4 19.2 68.3 19.3 69.2 19.4 70.9 19.6 72.7 19.8
37 49.7 13.2 59.3 17.1 66.3 19.9 67.2 20.0 68.1 20.1 69.9 20.3 71.6 20.5
39 49.7 14.1 59.3 18.2 65.2 20.6 66.1 20.7 67.0 20.8 68.8 21.0 70.6 21.2
100 (600) 10 45.2 6.62 53.9 8.02 62.6 9.51 67.0 10.3 71.4 11.0 80.1 12.6 84.7 12.6
12 45.2 6.73 53.9 8.17 62.6 9.68 67.0 10.5 71.4 11.3 80.1 12.9 83.6 12.9
14 45.2 6.85 53.9 8.32 62.6 9.87 67.0 10.7 71.4 11.5 80.1 13.1 82.5 13.1
16 45.2 6.98 53.9 8.48 62.6 10.1 67.0 10.9 71.4 11.7 79.8 13.3 81.4 13.3
18 45.2 7.11 53.9 8.64 62.6 10.3 67.0 11.1 71.4 11.9 78.7 13.7 80.3 13.8
20 45.2 7.24 53.9 8.81 62.6 10.6 67.0 11.6 71.4 12.8 77.6 14.4 79.3 14.5
21 45.2 7.31 53.9 8.90 62.6 10.9 67.0 12.1 71.4 13.2 77.1 14.7 78.7 14.8
23 45.2 7.50 53.9 9.49 62.6 11.7 67.0 12.9 71.4 14.2 76.0 15.4 77.6 15.5
25 45.2 8.01 53.9 10.1 62.6 12.5 67.0 13.8 71.4 15.2 74.9 16.1 76.5 16.2
27 45.2 8.53 53.9 10.8 62.6 13.4 67.0 14.8 71.4 16.3 73.8 16.7 75.4 16.9
29 45.2 9.09 53.9 11.5 62.6 14.3 67.0 15.8 71.1 17.3 72.7 17.4 74.3 17.5
31 45.2 9.67 53.9 12.3 62.6 15.3 67.0 16.9 70.0 17.9 71.6 18.1 73.3 18.2
33 45.2 10.3 53.9 13.1 62.6 16.3 67.0 18.0 68.9 18.6 70.5 18.8 72.2 18.9
35 45.2 10.9 53.9 14.0 62.6 17.4 67.0 19.2 67.8 19.3 69.4 19.5 71.1 19.6
37 45.2 11.6 53.9 14.8 62.6 18.5 65.9 19.9 66.7 20.0 68.4 20.1 70.0 20.3
39 45.2 12.3 53.9 15.8 62.6 19.7 64.8 20.6 65.6 20.6 67.3 20.8 68.9 21.0
NOTES
1 The above table shows the average value of conditions which may occur.
