Daikin REYQ14PY1B [35/137] Capacity tables
![Daikin REYQ14PY1B [35/137] Capacity tables](/views2/1713627/page35/bg23.png)
• Outdoor Units • VRV HEAT RECOVERY • REYQ8-48P7Y1B
1
3
• VRV Systems • Outdoor Units
34
3 Capacity tables
3 - 2 Cooling capacity tables
REYQ34P
TC: Total capacity (kW); PI: Power input (kW) (Compressor + outdoor fan motor)
Combination
(%)
Capacity index
Outdoor air
temp. °CDB
Indoor air temp.: °CWB
14°C 16°C 18°C 19°C 20°C 22°C 24°C
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW KW KW
130 (1105) 10 83.7 12.5 99.8 15.3 116 18.2 120 18.2 122 18.2 125 18.2 128 18.2
12 83.7 12.8 99.8 15.6 116 18.6 119 18.6 120 18.6 123 18.6 126 18.6
14 83.7 13.0 99.8 15.9 116 18.8 117 18.8 119 18.8 122 18.8 125 18.8
16 83.7 13.2 99.8 16.2 114 18.7 115 18.8 117 18.8 120 18.8 123 18.8
18 83.7 13.5 99.8 16.6 112 19.4 114 19.5 115 19.6 118 19.8 121 20.0
20 83.7 13.8 99.8 17.6 111 20.4 112 20.5 114 20.6 117 20.8 120 21.0
21 83.7 14.2 99.8 18.3 110 20.9 112 21.0 113 21.1 116 21.3 119 21.5
23 83.7 15.2 99.8 19.6 109 21.8 110 21.9 112 22.0 115 22.3 118 22.5
25 83.7 16.2 99.8 21.0 107 22.8 109 22.9 110 23.0 113 23.2 116 23.5
27 83.7 17.3 99.8 22.4 105 23.7 107 23.9 108 24.0 111 24.2 115 24.5
29 83.7 18.5 99.8 24.0 104 24.7 105 24.8 107 25.0 110 25.2 113 25.5
31 83.7 19.7 99.3 25.4 102 25.7 104 25.8 105 25.9 108 26.2 111 26.5
33 83.7 21.0 97.8 26.3 101 26.6 102 26.8 104 26.9 107 27.2 110 27.5
35 83.7 22.4 96.2 27.3 99.2 27.6 101 27.8 102 27.9 105 28.2 108 28.5
37 83.7 23.8 94.7 28.2 97.7 28.6 99.2 28.7 101 28.9 104 29.2 107 29.6
39 83.7 25.4 93.1 29.2 96.1 29.6 97.7 29.7 99.2 29.9 102 30.3 105 30.6
120 (1020) 10 77.3 11.4 92.1 14.0 107 16.6 114 18.0 120 18.0 123 18.0 125 18.0
12 77.3 11.7 92.1 14.2 107 16.9 114 18.3 118 18.3 121 18.3 124 18.3
14 77.3 11.9 92.1 14.5 107 17.3 114 18.7 117 18.7 119 18.7 122 18.7
16 77.3 12.1 92.1 14.8 107 17.6 114 18.8 115 18.8 118 18.8 121 18.8
18 77.3 12.3 92.1 15.1 107 18.2 112 19.4 114 19.5 116 19.7 119 19.9
20 77.3 12.6 92.1 15.7 107 19.6 111 20.4 112 20.5 115 20.6 118 20.8
21 77.3 12.7 92.1 16.2 107 20.3 110 20.8 111 20.9 114 21.1 117 21.3
23 77.3 13.6 92.1 17.4 107 21.7 108 21.8 110 21.9 112 22.1 115 22.3
25 77.3 14.5 92.1 18.6 105 22.6 107 22.7 108 22.9 111 23.1 114 23.3
27 77.3 15.5 92.1 19.9 104 23.6 105 23.7 107 23.8 109 24.0 112 24.3
29 77.3 16.5 92.1 21.3 102 24.5 104 24.7 105 24.8 108 25.0 111 25.3
31 77.3 17.6 92.1 22.7 101 25.5 102 25.6 103 25.8 106 26.0 109 26.3
33 77.3 18.7 92.1 24.2 99.1 26.5 101 26.6 102 26.7 105 27.0 107 27.3
35 77.3 19.9 92.1 25.8 97.6 27.4 99.0 27.6 100 27.7 103 28.0 106 28.3
37 77.3 21.2 92.1 27.5 96.0 28.4 97.4 28.5 98.8 28.7 102 29.0 104 29.3
39 77.3 22.6 91.7 29.0 94.5 29.4 95.9 29.5 97.3 29.7 100 30.0 103 30.3
110 (935) 10 70.8 10.4 84.5 12.7 98.1 15.0 105 16.2 112 17.5 120 17.9 123 17.9
12 70.8 10.6 84.5 12.9 98.1 15.3 105 16.6 112 17.8 119 18.2 121 18.2
14 70.8 10.8 84.5 13.1 98.1 15.6 105 16.9 112 18.1 117 18.6 120 18.6
16 70.8 11.0 84.5 13.4 98.1 15.9 105 17.2 112 18.5 116 18.8 118 18.8
18 70.8 11.2 84.5 13.6 98.1 16.2 105 17.7 112 19.4 114 19.6 117 19.7
20 70.8 11.4 84.5 13.9 98.1 17.2 105 19.0 110 20.3 113 20.5 115 20.7
21 70.8 11.5 84.5 14.3 98.1 17.8 105 19.7 109 20.8 112 21.0 114 21.2
23 70.8 12.0 84.5 15.4 98.1 19.1 105 21.1 108 21.8 110 21.9 113 22.1
25 70.8 12.9 84.5 16.4 98.1 20.4 105 22.6 106 22.7 109 22.9 111 23.1
27 70.8 13.7 84.5 17.5 98.1 21.9 103 23.6 105 23.7 107 23.9 110 24.1
29 70.8 14.6 84.5 18.7 98.1 23.4 102 24.5 103 24.6 106 24.8 108 25.1
31 70.8 15.6 84.5 20.0 98.1 24.9 100 25.5 102 25.6 104 25.8 107 26.1
33 70.8 16.6 84.5 21.3 97.5 26.3 98.7 26.4 100 26.5 103 26.8 105 27.0
35 70.8 17.6 84.5 22.7 95.9 27.3 97.2 27.4 98.5 27.5 101 27.8 104 28.0
37 70.8 18.8 84.5 24.2 94.4 28.2 95.6 28.4 96.9 28.5 99.5 28.8 102 29.1
39 70.8 19.9 84.5 25.7 92.8 29.2 94.1 29.3 95.4 29.5 97.9 29.8 100 30.1
100 (850) 10 64.4 9.37 76.8 11.4 89.2 13.5 95.4 14.5 102 15.6 114 17.9 121 17.9
12 64.4 9.54 76.8 11.6 89.2 13.7 95.4 14.8 102 15.9 114 18.2 119 18.2
14 64.4 9.71 76.8 11.8 89.2 14.0 95.4 15.1 102 16.2 114 18.6 117 18.6
16 64.4 9.88 76.8 12.0 89.2 14.2 95.4 15.4 102 16.6 114 18.8 116 18.8
18 64.4 10.1 76.8 12.2 89.2 14.5 95.4 15.7 102 16.9 112 19.4 114 19.6
20 64.4 10.3 76.8 12.5 89.2 15.0 95.4 16.5 102 18.1 111 20.4 113 20.5
21 64.4 10.4 76.8 12.6 89.2 15.5 95.4 17.1 102 18.7 110 20.8 112 21.0
23 64.4 10.6 76.8 13.4 89.2 16.6 95.4 18.3 102 20.1 108 21.8 111 22.0
25 64.4 11.3 76.8 14.4 89.2 17.8 95.4 19.6 102 21.5 107 22.7 109 22.9
27 64.4 12.1 76.8 15.3 89.2 19.0 95.4 21.0 102 23.0 105 23.7 107 23.9
29 64.4 12.9 76.8 16.4 89.2 20.3 95.4 22.4 101 24.5 104 24.7 106 24.9
31 64.4 13.7 76.8 17.4 89.2 21.6 95.4 23.9 99.7 25.4 102 25.6 104 25.8
33 64.4 14.6 76.8 18.6 89.2 23.1 95.4 25.5 98.1 26.4 100 26.6 103 26.8
35 64.4 15.5 76.8 19.8 89.2 24.6 95.4 27.2 96.6 27.3 98.9 27.6 101 27.8
37 64.4 16.4 76.8 21.0 89.2 26.2 93.8 28.2 95.0 28.3 97.3 28.5 99.7 28.8
39 64.4 17.5 76.8 22.4 89.2 27.9 92.3 29.1 93.5 29.3 95.8 29.5 98.1 29.8
NOTES
1 The above table shows the average value of conditions which may occur.
