Daikin REYQ14PY1B [83/137] Capacity tables
![Daikin REYQ14PY1B [83/137] Capacity tables](/views2/1713627/page83/bg53.png)
• Outdoor Units • VRV HEAT RECOVERY • REYQ8-48P7Y1B
1
3
• VRV Systems • Outdoor Units
82
3 Capacity tables
3 - 3 Heating capacity tables
REYQ40P
TC: Total capacity (kW); PI: Power input (kW) (Compressor + outdoor fan motor)
Combination
(%)
Capacity index
Outdoor air temp.
Indoor air temp.: °CDB
16°C 18°C 20°C 21°C 22°C 24°C
TC PI TC PI TC PI TC PI TC PI TC PI
°CDB °CWB kW kW kW kW kW kW kW kW kW kW kW kW
130 (1300) -19.8 -20.0 72.2 15.9 71.9 17.5 71.6 19.1 71.5 19.9 71.3 20.7 71.0 22.3
-18.8 -19.0 73.4 16.4 73.2 18.0 72.9 19.5 72.7 20.3 72.6 21.1 72.3 22.7
-16.7 -17.0 76.2 17.5 75.9 19.0 75.6 20.5 75.5 21.2 75.4 22.0 75.1 23.5
-13.7 -15.0 79.3 18.6 79.0 20.0 78.7 21.5 78.6 22.2 78.4 22.9 78.2 24.4
-11.8 -13.0 82.7 19.7 82.5 21.1 82.2 22.5 82.0 23.2 81.9 23.9 81.6 25.2
-9.8 -11.0 86.5 20.8 86.2 22.2 85.9 23.5 85.8 24.1 85.6 24.8 85.4 26.1
-9.5 -10.0 88.5 21.4 88.2 22.7 87.9 24.0 87.8 24.6 87.7 25.3 87.4 26.5
-8.5 -9.1 90.4 21.9 90.1 23.2 89.8 24.4 89.7 25.0 89.5 25.7 89.2 26.9
-7.0 -7.6 93.7 22.7 93.4 23.9 93.1 25.1 92.9 25.7 92.8 26.4 92.5 27.6
-5.0 -5.6 98.3 23.8 98.0 24.9 97.8 26.1 97.6 26.7 97.5 27.2 97.2 28.4
-3.0 -3.7 103 24.8 103 25.9 102 27.0 102 27.5 102 28.1 102 29.2
0.0 -0.7 111 26.3 111 27.3 111 28.3 110 28.8 110 29.3 110 30.3
3.0 2.2 120 27.6 119 28.5 119 29.5 119 29.9 119 30.4 119 31.3
5.0 4.1 126 28.4 125 29.3 125 30.2 125 30.6 125 31.1 125 32.0
7.0 6.0 132 29.2 132 30.0 131 30.9 131 31.3 131 31.7 131 32.6
9.0 7.9 139 29.9 138 30.7 138 31.5 138 31.9 138 32.4 137 33.2
11.0 9.8 145 30.6 145 31.4 145 32.2 145 32.6 145 32.9 142 32.7
13.0 11.8 153 31.3 153 32.1 152 32.8 152 33.1 152 33.5 142 30.8
15.0 13.7 160 32.0 160 32.6 160 33.3 157 32.9 152 31.6 142 29.0
120 (1200) -19.8 -20.0 71.8 18.0 71.5 19.5 71.3 21.0 71.1 21.7 71.0 22.5 70.7 23.9
-18.8 -19.0 73.1 18.5 72.8 20.0 72.5 21.4 72.4 22.1 72.3 22.9 72.0 24.3
-16.7 -17.0 75.8 19.5 75.6 20.9 75.3 22.3 75.2 23.0 75.0 23.7 74.8 25.1
-13.7 -15.0 78.9 20.5 78.7 21.9 78.4 23.2 78.3 23.9 78.1 24.5 77.9 25.9
-11.8 -13.0 82.4 21.6 82.1 22.9 81.8 24.1 81.7 24.8 81.6 25.4 81.3 26.7
-9.8 -11.0 86.1 22.6 85.9 23.8 85.6 25.1 85.5 25.7 85.3 26.3 85.1 27.5
-9.5 -10.0 88.1 23.1 87.9 24.3 87.6 25.5 87.5 26.1 87.3 26.7 87.1 27.9
-8.5 -9.1 90.0 23.6 89.7 24.8 89.5 25.9 89.3 26.5 89.2 27.1 88.9 28.2
-7.0 -7.6 93.3 24.4 93.0 25.5 92.8 26.6 92.6 27.2 92.5 27.7 92.2 28.8
-5.0 -5.6 97.9 25.3 97.7 26.4 97.4 27.5 97.3 28.0 97.1 28.5 96.9 29.6
-3.0 -3.7 103 26.3 102 27.3 102 28.3 102 28.8 102 29.3 102 30.3
0.0 -0.7 111 27.6 111 28.6 110 29.5 110 30.0 110 30.4 110 31.4
3.0 2.2 119 28.9 119 29.7 119 30.6 119 31.0 119 31.5 118 32.3
5.0 4.1 125 29.6 125 30.4 125 31.3 125 31.7 124 32.1 124 32.9
7.0 6.0 132 30.3 131 31.1 131 31.9 131 32.3 131 32.7 131 33.5
9.0 7.9 138 31.0 138 31.8 138 32.5 137 32.9 137 33.3 131 31.6
11.0 9.8 145 31.7 145 32.4 144 33.1 144 33.4 140 32.4 131 29.8
13.0 11.8 153 32.3 152 33.0 150 33.0 145 31.7 140 30.4 131 28.0
15.0 13.7 160 32.9 160 33.5 150 31.1 145 29.9 140 28.7 131 26.5
110 (1100) -19.8 -20.0 71.4 20.2 71.2 21.6 70.9 22.9 70.8 23.6 70.7 24.3 70.5 25.6
-18.8 -19.0 72.7 20.6 72.4 22.0 72.2 23.3 72.1 24.0 71.9 24.6 71.7 26.0
-16.7 -17.0 75.4 21.6 75.2 22.8 75.0 24.1 74.8 24.7 74.7 25.4 74.5 26.7
-13.7 -15.0 78.5 22.5 78.3 23.7 78.1 24.9 77.9 25.5 77.8 26.2 77.6 27.4
-11.8 -13.0 82.0 23.4 81.7 24.6 81.5 25.8 81.4 26.4 81.2 27.0 81.0 28.1
-9.8 -11.0 85.7 24.4 85.5 25.5 85.2 26.6 85.1 27.2 85.0 27.7 84.8 28.9
-9.5 -10.0 87.7 24.9 87.5 26.0 87.3 27.1 87.1 27.6 87.0 28.1 86.8 29.2
-8.5 -9.1 89.6 25.3 89.4 26.4 89.1 27.4 89.0 28.0 88.9 28.5 88.6 29.6
-7.0 -7.6 92.9 26.0 92.6 27.0 92.4 28.0 92.3 28.6 92.2 29.1 91.9 30.1
-5.0 -5.6 97.6 26.9 97.3 27.9 97.1 28.9 97.0 29.3 96.8 29.8 96.6 30.8
-3.0 -3.7 102 27.7 102 28.7 102 29.6 102 30.1 102 30.5 101 31.4
0.0 -0.7 110 29.0 110 29.8 110 30.7 110 31.1 110 31.6 109 32.4
3.0 2.2 119 30.1 119 30.9 118 31.7 118 32.1 118 32.5 118 33.3
5.0 4.1 125 30.8 125 31.6 124 32.3 124 32.7 124 33.1 120 32.1
7.0 6.0 131 31.5 131 32.2 131 32.9 131 33.3 129 32.9 120 30.2
9.0 7.9 138 32.1 138 32.8 137 33.5 133 32.3 129 31.0 120 28.5
11.0 9.8 145 32.7 144 33.4 138 31.6 133 30.4 129 29.2 120 26.9
13.0 11.8 152 33.3 146 32.0 138 29.7 133 28.6 129 27.5 120 25.3
15.0 13.7 155 32.4 146 30.2 138 28.0 133 27.0 129 26.0 120 24.0
100 (1000) -19.8 -20.0 71.0 22.4 70.8 23.6 70.6 24.8 70.5 25.4 70.4 26.0 70.2 27.3
-18.8 -19.0 72.3 22.8 72.1 24.0 71.8 25.2 71.7 25.8 71.6 26.4 71.4 27.6
-16.7 -17.0 75.1 23.6 74.8 24.7 74.6 25.9 74.5 26.5 74.4 27.1 74.2 28.2
-13.7 -15.0 78.1 24.4 77.9 25.6 77.7 26.7 77.6 27.2 77.5 27.8 77.3 28.9
-11.8 -13.0 81.6 25.3 81.4 26.4 81.1 27.4 81.0 28.0 80.9 28.5 80.7 29.6
-9.8 -11.0 85.3 26.2 85.1 27.2 84.9 28.2 84.8 28.7 84.7 29.2 84.5 30.2
-9.5 -10.0 87.3 26.6 87.1 27.6 86.9 28.6 86.8 29.1 86.7 29.6 86.5 30.6
-8.5 -9.1 89.2 27.0 89.0 28.0 88.8 28.9 88.7 29.4 88.6 29.9 88.3 30.9
-7.0 -7.6 92.5 27.6 92.3 28.6 92.1 29.5 92.0 30.0 91.8 30.4 91.6 31.4
-5.0 -5.6 97.2 28.5 96.9 29.3 96.7 30.2 96.6 30.7 96.5 31.1 96.3 32.0
-3.0 -3.7 102 29.2 102 30.1 101 30.9 101 31.3 101 31.7 101 32.6
0.0 -0.7 110 30.4 110 31.1 110 31.9 109 32.3 109 32.7 109 33.4
3.0 2.2 119 31.4 118 32.1 118 32.8 118 33.2 117 33.1 109 30.4
5.0 4.1 125 32.0 124 32.7 124 33.4 121 32.5 117 31.2 109 28.7
7.0 6.0 131 32.6 131 33.3 125 31.8 121 30.6 117 29.4 109 27.1
9.0 7.9 137 33.2 133 32.3 125 30.0 121 28.8 117 27.7 109 25.5
11.0 9.8 141 32.6 133 30.4 125 28.2 121 27.2 117 26.2 109 24.1
13.0 11.8 141 30.6 133 28.6 125 26.6 121 25.6 117 24.7 109 22.8
15.0 13.7 141 28.9 133 27.0 125 25.1 121 24.2 117 23.3 109 21.6
NOTES
1 is shown as reference.
When selecting the unit models, avoid the outdoor air temperature range shown by
2 The above table shows the average value of conditions which may occur.
