1 Specifications
1-2 ELECTRICAL SPECIFICATIONS
REYQ8PY1B REYQ10PY1B REYQ12PY1B REYQ14PY1B REYQ16PY1B REYQ18P7Y1B REYQ20P7Y1B REYQ22P7Y1B
Power Supply Name Y1 Y1 Y1
Phase 33333333
Frequency Hz 5050505050505050
Voltage V 380-415
Current Starting current (MSC) A 74 74 75 78.0 79.0 88.0
Maximum Running Current A 2.7 + 7.6 4.8 + 7.6 6.9 + 7.5 8.2x2 10.8x2 8.2 + 4.5 +
6.8
8.2 + 7.0 +
6.7
4.5 + 6.8 +
7.0 + 6.7
Minimum circuit amps (MCA) A 17.1 22.1 22.3 32.8 33.0 40.1 41.2 44.3
Maximum fuse amps (MFA) A 20 25 25 40 40 45.0 50.0 50.0
Total overcurrent amps (TOCA) A 31.5 31.5 31.5 33.1 33.1 48.0 48.0 63.0
Full load amps (FLA) A 0.7x2 0.7x2 0.8x2 1.0x2 1.1x2 0.7 + 0.9 0.7 + 1.2 0.9 + 1.2
Voltage range Minimum V 342 342 342 342 342 342 342 342
Maximum V 456 456 456 456 456 456 456 456
Notes RLA is based on following conditions : indoor temperature : 270CDB/190CWB , outdoor temperature :
350CDB
TOCA means the total value of each OC set
MSC means the maximum current during start up of the compressor
Voltage range : units are suitable for use on electrical systems where voltage supplied to unit terminal is
not below or above listed range limits
Maximum allowable voltage range variation between phases is 2%
Select wire size based on the larger value of MCA or TOCA
MFA is used to select the circuit breaker and the ground fault circuit interrupter (earth leakage circuit
breaker)
1-2 ELECTRICAL SPECIFICATIONS
REYQ24P7Y1B REYQ26P7Y1B REYQ28P7Y1B REYQ30P7Y1B REYQ32P7Y1B REYQ34P7Y1B REYQ36P7Y1B REYQ38P7Y1B
Power Supply Name Y1
Phase 33333333
Frequency Hz 5050505050505050
Voltage V 380-415
Current Starting current (MSC) A 88.0 98.0 98.0 108.0 109.0 101.0 102.0 111.0
Maximum Running Current A (7.0 +
6.7)x 2
4.5 + 6.8 +
6.1 + 7.6x
2
7.0 + 6.7 +
6.1 + 7.6x
2
3.4 + 7.5x
2 + 6.1 +
7.6x 2
(6.1 + 7.6x
2)x 2
8.2 + 4.5 +
6.8 + 6.1 +
7.6x 2
8.2 + 7.0 +
6.7 + 6.1 +
7.6x 2
4.5 + 6.8 +
7.0 + 6.7 +
6.1 + 7.6x
2
Minimum circuit amps (MCA) A 45.4 53.1 54.2 63.0 63.0 71.6 72.7 75.8
Maximum fuse amps (MFA) A 50.0 60.0 60.0 70.0 70.0 80.0 80.0 90.0
Total overcurrent amps (TOCA) A 63.0 77.9 77.9 92.8 92.8 94.5 94.5 109.4
Full load amps (FLA) A 1.2 + 1.2 0.9 + 0.6x
2
1.2 + 0.6x
2
(0.6x 2)x 2 (0.6x 2)x 2 0.7 + 0.9 +
0.6x 2
0.7 + 1.2 +
0.6x 2
0.9 + 1.2 +
0.6x 2
Voltage range Minimum V 342 342 342 342 342 342 342 342
Maximum V 456 456 456 456 456 456 456 456
1-2 ELECTRICAL SPECIFICATIONS REYQ40P7Y1B REYQ42P7Y1B REYQ44P7Y1B REYQ46P7Y1B REYQ48P7Y1B
Power Supply Name Y1
Phase 33333
Frequency Hz5050505050
Voltage V 380-415
Current Starting current (MSC) A 111.0 122.0 122.0 132.0 134.0
Maximum Running Current A (7.0 + 6.7)x 2 + 6.1
+ 7.6x 2
4.5 + 6.8 + (6.1 +
7.6x 2)x 2
7.0 + 6.7 + (6.1 +
7.6x 2)x 2
3.4 + 7.5x 2 + (6.1
+ 7.6x 2)x 2
(6.1 + 7.6x 2)x 3
Minimum circuit amps (MCA) A 76.9 84.6 85.7 94.5 94.5
Maximum fuse amps (MFA) A 90.0 100.0 100.0 110.0 110.0
Total overcurrent amps (TOCA) A 109.4 124.3 124.3 139.3 139.3
Full load amps (FLA) A 1.2 + 1.2 + 0.6x 2 0.9 + (0.6x 2)x 2 1.2 + (0.6x 2)x 2 0.6x 2+ (0.6x 2)x 2 (0.6x 2)x 3
Voltage range Minimum V 342 342 342 342 342
Maximum V 456 456 456 456 456
