Daikin REYQ14PY1B [29/137] Capacity tables
![Daikin REYQ14PY1B [29/137] Capacity tables](/views2/1713627/page29/bg1d.png)
• Outdoor Units • VRV HEAT RECOVERY • REYQ8-48P7Y1B
1
3
• VRV Systems • Outdoor Units
28
3 Capacity tables
3 - 2 Cooling capacity tables
REYQ28P
TC: Total capacity (kW); PI: Power input (kW) (Compressor + outdoor fan motor)
Combination
(%)
Capacity index
Outdoor air
temp. °CDB
Indoor air temp.: °CWB
14°C 16°C 18°C 19°C 20°C 22°C 24°C
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW KW KW
130 (910) 10 68.9 11.0 82.1 13.4 95.4 16.0 98.9 16.0 100 16.0 103 16.0 105 16.0
12 68.9 11.2 82.1 13.7 95.4 16.3 97.6 16.3 98.8 16.3 101 16.3 104 16.3
14 68.9 11.4 82.1 13.9 95.1 16.5 96.3 16.5 97.6 16.5 100 16.5 103 16.5
16 68.9 11.6 82.1 14.2 93.8 16.4 95.0 16.4 96.3 16.4 98.8 16.5 101 16.5
18 68.9 11.8 82.1 14.5 92.5 17.0 93.8 17.1 95.0 17.2 97.5 17.3 100 17.5
20 68.9 12.1 82.1 15.4 91.2 17.8 92.5 17.9 93.7 18.0 96.2 18.2 98.7 18.4
21 68.9 12.4 82.1 16.0 90.6 18.3 91.8 18.3 93.1 18.4 95.6 18.6 98.1 18.8
23 68.9 13.3 82.1 17.1 89.3 19.1 90.6 19.2 91.8 19.3 94.3 19.5 96.8 19.7
25 68.9 14.2 82.1 18.3 88.0 19.9 89.3 20.0 90.5 20.1 93.0 20.3 95.5 20.5
27 68.9 15.2 82.1 19.6 86.8 20.8 88.0 20.9 89.3 21.0 91.7 21.2 94.2 21.4
29 68.9 16.2 82.1 21.0 85.5 21.6 86.7 21.7 88.0 21.8 90.5 22.1 92.9 22.3
31 68.9 17.2 81.7 22.2 84.2 22.4 85.5 22.6 86.7 22.7 89.2 22.9 91.7 23.2
33 68.9 18.4 80.5 23.0 82.9 23.3 84.2 23.4 85.4 23.6 87.9 23.8 90.4 24.1
35 68.9 19.6 79.2 23.9 81.7 24.1 82.9 24.3 84.1 24.4 86.6 24.7 89.1 25.0
37 68.9 20.9 77.9 24.7 80.4 25.0 81.6 25.2 82.9 25.3 85.4 25.6 87.8 25.9
39 68.9 22.2 76.6 25.6 79.1 25.9 80.4 26.0 81.6 26.2 84.1 26.5 86.6 26.8
120 (840) 10 63.6 10.0 75.8 12.2 88.1 14.5 94.2 15.7 98.5 15.7 101 15.7 103 15.7
12 63.6 10.2 75.8 12.5 88.1 14.8 94.2 16.0 97.3 16.0 99.6 16.0 102 16.0
14 63.6 10.4 75.8 12.7 88.1 15.1 94.2 16.3 96.0 16.3 98.3 16.3 101 16.3
16 63.6 10.6 75.8 12.9 88.1 15.4 93.6 16.4 94.7 16.4 97.0 16.5 99.3 16.5
18 63.6 10.8 75.8 13.2 88.1 15.9 92.3 17.0 93.4 17.1 95.7 17.2 98.0 17.4
20 63.6 11.0 75.8 13.7 88.1 17.1 91.0 17.8 92.2 17.9 94.5 18.1 96.7 18.2
21 63.6 11.1 75.8 14.2 88.1 17.7 90.4 18.2 91.5 18.3 93.8 18.5 96.1 18.7
23 63.6 11.9 75.8 15.2 88.0 19.0 89.1 19.1 90.2 19.2 92.5 19.3 94.8 19.5
25 63.6 12.7 75.8 16.3 86.7 19.8 87.8 19.9 89.0 20.0 91.3 20.2 93.6 20.4
27 63.6 13.5 75.8 17.4 85.4 20.6 86.5 20.7 87.7 20.8 90.0 21.0 92.3 21.2
29 63.6 14.4 75.8 18.6 84.1 21.5 85.3 21.6 86.4 21.7 88.7 21.9 91.0 22.1
31 63.6 15.4 75.8 19.9 82.8 22.3 84.0 22.4 85.1 22.5 87.4 22.8 89.7 23.0
33 63.6 16.4 75.8 21.2 81.6 23.2 82.7 23.3 83.9 23.4 86.2 23.6 88.4 23.9
35 63.6 17.4 75.8 22.6 80.3 24.0 81.4 24.1 82.6 24.2 84.9 24.5 87.2 24.8
37 63.6 18.6 75.8 24.1 79.0 24.8 80.2 25.0 81.3 25.1 83.6 25.4 85.9 25.6
39 63.6 19.8 75.4 25.4 77.7 25.7 78.9 25.8 80.0 26.0 82.3 26.3 84.6 26.5
110 (770) 10 58.3 9.09 69.5 11.1 80.7 13.1 86.4 14.2 92.0 15.3 99.1 15.6 101 15.6
12 58.3 9.26 69.5 11.3 80.7 13.4 86.4 14.5 92.0 15.6 97.8 15.9 99.9 15.9
14 58.3 9.42 69.5 11.5 80.7 13.7 86.4 14.8 92.0 15.9 96.5 16.2 98.6 16.2
16 58.3 9.60 69.5 11.7 80.7 13.9 86.4 15.0 92.0 16.2 95.3 16.5 97.4 16.5
18 58.3 9.78 69.5 11.9 80.7 14.2 86.4 15.5 91.9 17.0 94.0 17.1 96.1 17.2
20 58.3 9.97 69.5 12.2 80.7 15.0 86.4 16.6 90.6 17.8 92.7 17.9 94.8 18.1
21 58.3 10.1 69.5 12.6 80.7 15.6 86.4 17.2 90.0 18.2 92.1 18.4 94.2 18.5
23 58.3 10.5 69.5 13.4 80.7 16.7 86.4 18.5 88.7 19.0 90.8 19.2 92.9 19.4
25 58.3 11.3 69.5 14.4 80.7 17.9 86.4 19.8 87.4 19.9 89.5 20.0 91.6 20.2
27 58.3 12.0 69.5 15.4 80.7 19.1 85.1 20.6 86.1 20.7 88.2 20.9 90.3 21.1
29 58.3 12.8 69.5 16.4 80.7 20.4 83.8 21.4 84.9 21.5 87.0 21.7 89.1 21.9
31 58.3 13.6 69.5 17.5 80.7 21.8 82.5 22.3 83.6 22.4 85.7 22.6 87.8 22.8
33 58.3 14.5 69.5 18.6 80.2 23.0 81.2 23.1 82.3 23.2 84.4 23.4 86.5 23.7
35 58.3 15.4 69.5 19.9 78.9 23.8 80.0 24.0 81.0 24.1 83.1 24.3 85.2 24.5
37 58.3 16.4 69.5 21.1 77.6 24.7 78.7 24.8 79.7 24.9 81.8 25.2 83.9 25.4
39 58.3 17.4 69.5 22.5 76.4 25.5 77.4 25.7 78.5 25.8 80.6 26.0 82.7 26.3
100 (700) 10 53.0 8.20 63.2 9.94 73.4 11.8 78.5 12.7 83.6 13.7 93.8 15.6 99.2 15.6
12 53.0 8.34 63.2 10.1 73.4 12.0 78.5 13.0 83.6 13.9 93.8 15.9 98.0 15.9
14 53.0 8.49 63.2 10.3 73.4 12.2 78.5 13.2 83.6 14.2 93.8 16.2 96.7 16.2
16 53.0 8.65 63.2 10.5 73.4 12.5 78.5 13.5 83.6 14.5 93.5 16.5 95.4 16.5
18 53.0 8.81 63.2 10.7 73.4 12.7 78.5 13.7 83.6 14.8 92.2 17.0 94.1 17.1
20 53.0 8.98 63.2 10.9 73.4 13.1 78.5 14.4 83.6 15.8 90.9 17.8 92.9 18.0
21 53.0 9.06 63.2 11.0 73.4 13.6 78.5 14.9 83.6 16.4 90.3 18.2 92.2 18.4
23 53.0 9.30 63.2 11.8 73.4 14.5 78.5 16.0 83.6 17.6 89.0 19.1 90.9 19.2
25 53.0 9.92 63.2 12.6 73.4 15.5 78.5 17.1 83.6 18.8 87.8 19.9 89.7 20.1
27 53.0 10.6 63.2 13.4 73.4 16.6 78.5 18.3 83.6 20.2 86.5 20.7 88.4 20.9
29 53.0 11.3 63.2 14.3 73.4 17.7 78.5 19.6 83.3 21.4 85.2 21.6 87.1 21.8
31 53.0 12.0 63.2 15.3 73.4 18.9 78.5 20.9 82.0 22.2 83.9 22.4 85.8 22.6
33 53.0 12.7 63.2 16.2 73.4 20.2 78.5 22.3 80.7 23.1 82.6 23.3 84.6 23.5
35 53.0 13.5 63.2 17.3 73.4 21.5 78.5 23.8 79.5 23.9 81.4 24.1 83.3 24.3
37 53.0 14.4 63.2 18.4 73.4 22.9 77.2 24.6 78.2 24.7 80.1 25.0 82.0 25.2
39 53.0 15.3 63.2 19.6 73.4 24.4 75.9 25.5 76.9 25.6 78.8 25.8 80.7 26.1
NOTES
1 The above table shows the average value of conditions which may occur.
