• Outdoor Units • VRV HEAT RECOVERY • REYQ8-48P7Y1B
1
3
• VRV Systems • Outdoor Units
86
3 Capacity tables
3 - 3 Heating capacity tables
REYQ44P
TC: Total capacity (kW); PI: Power input (kW) (Compressor + outdoor fan motor)
Combination
(%)
Capacity index
Outdoor air temp.
Indoor air temp.: °CDB
16°C 18°C 20°C 21°C 22°C 24°C
TC PI TC PI TC PI TC PI TC PI TC PI
°CDB °CWB kW kW kW kW kW kW kW kW kW kW kW kW
130 (1430) -19.8 -20.0 82.1 19.4 81.8 21.1 81.5 22.9 81.3 23.8 81.2 24.7 80.9 26.4
-18.8 -19.0 83.6 20.0 83.3 21.7 82.9 23.4 82.8 24.3 82.6 25.2 82.3 26.9
-16.7 -17.0 86.8 21.2 86.4 22.8 86.1 24.5 86.0 25.3 85.8 26.2 85.5 27.8
-13.7 -15.0 90.3 22.4 90.0 24.0 89.7 25.6 89.5 26.4 89.4 27.2 89.0 28.8
-11.8 -13.0 94.2 23.6 93.9 25.2 93.6 26.7 93.4 27.5 93.3 28.2 93.0 29.7
-9.8 -11.0 98.5 24.9 98.2 26.3 97.9 27.8 97.7 28.5 97.6 29.2 97.3 30.7
-9.5 -10.0 101 25.5 101 26.9 100 28.3 100 29.1 99.9 29.8 99.6 31.2
-8.5 -9.1 103 26.0 103 27.4 102 28.8 102 29.5 102 30.2 102 31.6
-7.0 -7.6 107 27.0 106 28.3 106 29.6 106 30.3 106 31.0 105 32.3
-5.0 -5.6 112 28.1 112 29.4 111 30.7 111 31.3 111 31.9 111 33.2
-3.0 -3.7 117 29.2 117 30.4 117 31.6 117 32.2 116 32.8 116 34.1
0.0 -0.7 127 30.8 126 32.0 126 33.1 126 33.6 126 34.2 125 35.3
3.0 2.2 136 32.3 136 33.3 136 34.4 135 34.9 135 35.4 135 36.4
5.0 4.1 143 33.2 143 34.2 142 35.2 142 35.7 142 36.2 142 37.1
7.0 6.0 150 34.1 150 35.0 149 35.9 149 36.4 149 36.9 149 37.8
9.0 7.9 157 34.9 157 35.8 157 36.7 157 37.1 156 37.6 156 38.4
11.0 9.8 165 35.6 165 36.5 165 37.3 164 37.8 164 38.2 156 36.3
13.0 11.8 174 36.4 173 37.2 173 38.0 173 38.4 168 37.1 156 34.1
15.0 13.7 182 37.1 182 37.9 179 37.9 174 36.5 168 35.0 156 32.2
120 (1320) -19.8 -20.0 81.7 21.8 81.4 23.4 81.1 25.0 81.0 25.8 80.8 26.7 80.5 28.3
-18.8 -19.0 83.1 22.3 82.9 23.9 82.6 25.5 82.4 26.3 82.3 27.1 82.0 28.7
-16.7 -17.0 86.3 23.4 86.0 24.9 85.7 26.5 85.6 27.3 85.5 28.0 85.2 29.6
-13.7 -15.0 89.9 24.5 89.6 26.0 89.3 27.5 89.2 28.2 89.0 29.0 88.7 30.4
-11.8 -13.0 93.8 25.7 93.5 27.1 93.2 28.5 93.1 29.2 92.9 29.9 92.6 31.3
-9.8 -11.0 98.1 26.8 97.8 28.2 97.5 29.5 97.4 30.2 97.2 30.9 96.9 32.2
-9.5 -10.0 100 27.4 100 28.7 99.8 30.0 99.7 30.7 99.5 31.4 99.2 32.7
-8.5 -9.1 103 27.9 102 29.2 102 30.5 102 31.1 102 31.8 101 33.1
-7.0 -7.6 106 28.8 106 30.0 106 31.2 106 31.9 105 32.5 105 33.7
-5.0 -5.6 112 29.8 111 31.0 111 32.2 111 32.8 111 33.4 110 34.5
-3.0 -3.7 117 30.8 117 32.0 116 33.1 116 33.6 116 34.2 116 35.3
0.0 -0.7 126 32.3 126 33.4 125 34.4 125 34.9 125 35.4 125 36.5
3.0 2.2 136 33.7 135 34.7 135 35.6 135 36.1 135 36.6 135 37.5
5.0 4.1 142 34.5 142 35.4 142 36.4 142 36.8 142 37.3 141 38.2
7.0 6.0 150 35.3 149 36.2 149 37.1 149 37.5 149 37.9 144 37.1
9.0 7.9 157 36.1 157 36.9 156 37.7 156 38.1 155 38.1 144 35.0
11.0 9.8 165 36.8 164 37.6 164 38.4 160 37.4 155 35.9 144 33.0
13.0 11.8 173 37.5 173 38.2 166 36.5 160 35.1 155 33.8 144 31.0
15.0 13.7 182 38.1 176 37.1 166 34.5 160 33.2 155 31.9 144 29.3
110 (1210) -19.8 -20.0 81.3 24.2 81.0 25.6 80.7 27.1 80.6 27.9 80.5 28.6 80.2 30.1
-18.8 -19.0 82.7 24.6 82.5 26.1 82.2 27.6 82.1 28.3 81.9 29.0 81.6 30.5
-16.7 -17.0 85.9 25.7 85.6 27.1 85.4 28.5 85.2 29.2 85.1 29.9 84.8 31.3
-13.7 -15.0 89.5 26.7 89.2 28.1 88.9 29.4 88.8 30.1 88.7 30.8 88.4 32.1
-11.8 -13.0 93.4 27.8 93.1 29.1 92.8 30.3 92.7 31.0 92.6 31.6 92.3 32.9
-9.8 -11.0 97.7 28.8 97.4 30.0 97.1 31.3 97.0 31.9 96.9 32.5 96.6 33.7
-9.5 -10.0 100 29.3 99.7 30.5 99.4 31.7 99.3 32.3 99.2 32.9 98.9 34.1
-8.5 -9.1 102 29.8 102 31.0 102 32.2 101 32.7 101 33.3 101 34.5
-7.0 -7.6 106 30.6 106 31.7 105 32.8 105 33.4 105 34.0 105 35.1
-5.0 -5.6 111 31.6 111 32.6 111 33.7 110 34.3 110 34.8 110 35.9
-3.0 -3.7 116 32.5 116 33.5 116 34.5 116 35.0 116 35.6 115 36.6
0.0 -0.7 126 33.9 125 34.8 125 35.8 125 36.2 125 36.7 125 37.7
3.0 2.2 135 35.1 135 36.0 135 36.9 135 37.3 135 37.7 132 37.7
5.0 4.1 142 35.9 142 36.7 142 37.5 141 38.0 141 38.4 132 35.5
7.0 6.0 149 36.6 149 37.4 149 38.2 147 38.0 142 36.4 132 33.5
9.0 7.9 157 37.3 156 38.0 152 37.2 147 35.7 142 34.3 132 31.6
11.0 9.8 164 37.9 162 37.8 152 35.0 147 33.7 142 32.4 132 29.8
13.0 11.8 171 38.1 162 35.5 152 32.9 147 31.7 142 30.5 132 28.1
15.0 13.7 171 35.9 162 33.5 152 31.1 147 30.0 142 28.8 132 26.6
100 (1100) -19.8 -20.0 80.8 26.5 80.6 27.9 80.4 29.3 80.2 29.9 80.1 30.6 79.9 32.0
-18.8 -19.0 82.3 27.0 82.0 28.3 81.8 29.7 81.7 30.3 81.6 31.0 81.3 32.3
-16.7 -17.0 85.5 27.9 85.2 29.2 85.0 30.5 84.9 31.1 84.7 31.8 84.5 33.0
-13.7 -15.0 89.0 28.9 88.8 30.1 88.5 31.3 88.4 31.9 88.3 32.5 88.1 33.8
-11.8 -13.0 93.0 29.8 92.7 31.0 92.5 32.2 92.3 32.8 92.2 33.3 92.0 34.5
-9.8 -11.0 97.3 30.8 97.0 31.9 96.8 33.0 96.6 33.6 96.5 34.1 96.3 35.3
-9.5 -10.0 99.5 31.3 99.3 32.3 99.1 33.4 98.9 34.0 98.8 34.5 98.6 35.6
-8.5 -9.1 102 31.7 101 32.7 101 33.8 101 34.4 101 34.9 101 36.0
-7.0 -7.6 105 32.4 105 33.4 105 34.4 105 35.0 105 35.5 104 36.5
-5.0 -5.6 111 33.3 110 34.3 110 35.2 110 35.7 110 36.2 110 37.2
-3.0 -3.7 116 34.1 116 35.1 116 36.0 115 36.4 115 36.9 115 37.8
0.0 -0.7 125 35.4 125 36.2 125 37.1 125 37.5 125 38.0 120 36.9
3.0 2.2 135 36.5 135 37.3 134 38.1 134 38.2 129 36.7 120 33.7
5.0 4.1 142 37.2 141 38.0 138 37.4 134 35.9 129 34.5 120 31.7
7.0 6.0 149 37.9 147 37.9 138 35.2 134 33.9 129 32.5 120 29.9
9.0 7.9 156 38.3 147 35.7 138 33.2 134 31.9 129 30.7 120 28.3
11.0 9.8 156 36.1 147 33.7 138 31.3 134 30.1 129 29.0 120 26.7
13.0 11.8 156 34.0 147 31.7 138 29.5 134 28.4 129 27.3 120 25.2
15.0 13.7 156 32.1 147 29.9 138 27.9 134 26.9 129 25.9 120 23.9
NOTES
1 is shown as reference.
When selecting the unit models, avoid the outdoor air temperature range shown by
2 The above table shows the average value of conditions which may occur.
