Daikin REYQ14PY1B [27/137] Capacity tables
![Daikin REYQ14PY1B [27/137] Capacity tables](/views2/1713627/page27/bg1b.png)
• Outdoor Units • VRV HEAT RECOVERY • REYQ8-48P7Y1B
1
3
• VRV Systems • Outdoor Units
26
3 Capacity tables
3 - 2 Cooling capacity tables
REYQ26P
TC: Total capacity (kW); PI: Power input (kW) (Compressor + outdoor fan motor)
Combination
(%)
Capacity index
Outdoor air
temp. °CDB
Indoor air temp.: °CWB
14°C 16°C 18°C 19°C 20°C 22°C 24°C
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW KW KW
130 (845) 10 64.0 9.95 76.4 12.2 88.7 14.5 91.9 14.5 93.1 14.5 95.4 14.5 97.7 14.5
12 64.0 10.1 76.4 12.4 88.7 14.8 90.8 14.8 91.9 14.8 94.2 14.8 96.5 14.8
14 64.0 10.3 76.4 12.6 88.4 14.9 89.6 14.9 90.7 14.9 93.0 14.9 95.3 14.9
16 64.0 10.5 76.4 12.9 87.2 14.9 88.4 14.9 89.5 14.9 91.8 14.9 94.2 15.0
18 64.0 10.7 76.4 13.1 86.0 15.4 87.2 15.5 88.3 15.6 90.7 15.7 93.0 15.9
20 64.0 10.9 76.4 14.0 84.8 16.2 86.0 16.3 87.2 16.4 89.5 16.5 91.8 16.7
21 64.0 11.2 76.4 14.5 84.3 16.6 85.4 16.6 86.6 16.7 88.9 16.9 91.2 17.1
23 64.0 12.0 76.4 15.5 83.1 17.3 84.2 17.4 85.4 17.5 87.7 17.7 90.0 17.9
25 64.0 12.9 76.4 16.6 81.9 18.1 83.0 18.2 84.2 18.3 86.5 18.5 88.8 18.6
27 64.0 13.8 76.4 17.8 80.7 18.8 81.8 18.9 83.0 19.0 85.3 19.2 87.6 19.4
29 64.0 14.7 76.4 19.0 79.5 19.6 80.7 19.7 81.8 19.8 84.1 20.0 86.4 20.2
31 64.0 15.7 76.0 20.1 78.3 20.4 79.5 20.5 80.6 20.6 82.9 20.8 85.2 21.0
33 64.0 16.7 74.8 20.9 77.1 21.1 78.3 21.3 79.4 21.4 81.7 21.6 84.1 21.8
35 64.0 17.8 73.6 21.7 75.9 21.9 77.1 22.0 78.3 22.2 80.6 22.4 82.9 22.7
37 64.0 18.9 72.4 22.4 74.8 22.7 75.9 22.8 77.1 23.0 79.4 23.2 81.7 23.5
39 64.0 20.2 71.3 23.2 73.6 23.5 74.7 23.6 75.9 23.8 78.2 24.0 80.5 24.3
120 (780) 10 59.1 9.09 70.5 11.1 81.9 13.2 87.6 14.3 91.6 14.3 93.8 14.3 95.9 14.3
12 59.1 9.25 70.5 11.3 81.9 13.4 87.6 14.5 90.5 14.5 92.6 14.5 94.7 14.5
14 59.1 9.43 70.5 11.5 81.9 13.7 87.6 14.8 89.3 14.8 91.4 14.8 93.5 14.8
16 59.1 9.60 70.5 11.7 81.9 14.0 87.0 14.9 88.1 14.9 90.2 14.9 92.3 15.0
18 59.1 9.79 70.5 12.0 81.9 14.5 85.8 15.4 86.9 15.5 89.0 15.6 91.2 15.8
20 59.1 9.98 70.5 12.5 81.9 15.5 84.6 16.2 85.7 16.2 87.8 16.4 90.0 16.5
21 59.1 10.1 70.5 12.9 81.9 16.1 84.0 16.6 85.1 16.6 87.2 16.8 89.4 16.9
23 59.1 10.8 70.5 13.8 81.8 17.2 82.9 17.3 83.9 17.4 86.1 17.6 88.2 17.7
25 59.1 11.5 70.5 14.8 80.6 18.0 81.7 18.1 82.7 18.1 84.9 18.3 87.0 18.5
27 59.1 12.3 70.5 15.8 79.4 18.7 80.5 18.8 81.5 18.9 83.7 19.1 85.8 19.3
29 59.1 13.1 70.5 16.9 78.2 19.5 79.3 19.6 80.4 19.7 82.5 19.9 84.6 20.1
31 59.1 14.0 70.5 18.0 77.0 20.2 78.1 20.4 79.2 20.5 81.3 20.7 83.4 20.9
33 59.1 14.9 70.5 19.2 75.9 21.0 76.9 21.1 78.0 21.2 80.1 21.4 82.2 21.7
35 59.1 15.8 70.5 20.5 74.7 21.8 75.7 21.9 76.8 22.0 78.9 22.2 81.1 22.5
37 59.1 16.8 70.5 21.8 73.5 22.5 74.5 22.7 75.6 22.8 77.7 23.0 79.9 23.3
39 59.1 17.9 70.2 23.1 72.3 23.3 73.4 23.5 74.4 23.6 76.6 23.8 78.7 24.1
110 (715) 10 54.2 8.25 64.6 10.0 75.1 11.9 80.3 12.9 85.5 13.9 92.1 14.2 94.1 14.2
12 54.2 8.40 64.6 10.2 75.1 12.2 80.3 13.1 85.5 14.1 91.0 14.5 92.9 14.5
14 54.2 8.55 64.6 10.4 75.1 12.4 80.3 13.4 85.5 14.4 89.8 14.7 91.7 14.7
16 54.2 8.71 64.6 10.6 75.1 12.6 80.3 13.7 85.5 14.7 88.6 14.9 90.5 15.0
18 54.2 8.88 64.6 10.8 75.1 12.9 80.3 14.0 85.4 15.4 87.4 15.5 89.3 15.7
20 54.2 9.05 64.6 11.1 75.1 13.6 80.3 15.1 84.2 16.1 86.2 16.3 88.2 16.4
21 54.2 9.14 64.6 11.4 75.1 14.1 80.3 15.6 83.7 16.5 85.6 16.7 87.6 16.8
23 54.2 9.57 64.6 12.2 75.1 15.2 80.3 16.8 82.5 17.3 84.4 17.4 86.4 17.6
25 54.2 10.2 64.6 13.0 75.1 16.2 80.3 18.0 81.3 18.0 83.2 18.2 85.2 18.3
27 54.2 10.9 64.6 13.9 75.1 17.4 79.1 18.7 80.1 18.8 82.0 19.0 84.0 19.1
29 54.2 11.6 64.6 14.9 75.1 18.5 77.9 19.5 78.9 19.5 80.9 19.7 82.8 19.9
31 54.2 12.4 64.6 15.9 75.1 19.8 76.7 20.2 77.7 20.3 79.7 20.5 81.6 20.7
33 54.2 13.2 64.6 16.9 74.6 20.9 75.6 21.0 76.5 21.1 78.5 21.3 80.4 21.5
35 54.2 14.0 64.6 18.0 73.4 21.6 74.4 21.7 75.3 21.9 77.3 22.1 79.3 22.3
37 54.2 14.9 64.6 19.2 72.2 22.4 73.2 22.5 74.2 22.6 76.1 22.8 78.1 23.1
39 54.2 15.8 64.6 20.4 71.0 23.2 72.0 23.3 73.0 23.4 74.9 23.6 76.9 23.9
100 (650) 10 49.3 7.44 58.8 9.03 68.3 10.7 73.0 11.6 77.7 12.4 87.2 14.2 92.3 14.2
12 49.3 7.57 58.8 9.19 68.3 10.9 73.0 11.8 77.7 12.7 87.2 14.5 91.1 14.5
14 49.3 7.71 58.8 9.36 68.3 11.1 73.0 12.0 77.7 12.9 87.2 14.7 89.9 14.7
16 49.3 7.85 58.8 9.54 68.3 11.3 73.0 12.2 77.7 13.2 86.9 14.9 88.7 15.0
18 49.3 7.99 58.8 9.72 68.3 11.5 73.0 12.5 77.7 13.4 85.8 15.4 87.5 15.5
20 49.3 8.15 58.8 9.91 68.3 11.9 73.0 13.1 77.7 14.4 84.6 16.2 86.3 16.3
21 49.3 8.22 58.8 10.0 68.3 12.3 73.0 13.6 77.7 14.9 84.0 16.5 85.8 16.7
23 49.3 8.44 58.8 10.7 68.3 13.2 73.0 14.5 77.7 16.0 82.8 17.3 84.6 17.4
25 49.3 9.01 58.8 11.4 68.3 14.1 73.0 15.6 77.7 17.1 81.6 18.1 83.4 18.2
27 49.3 9.60 58.8 12.2 68.3 15.1 73.0 16.6 77.7 18.3 80.4 18.8 82.2 19.0
29 49.3 10.2 58.8 13.0 68.3 16.1 73.0 17.8 77.5 19.4 79.2 19.6 81.0 19.7
31 49.3 10.9 58.8 13.8 68.3 17.2 73.0 19.0 76.3 20.2 78.0 20.3 79.8 20.5
33 49.3 11.6 58.8 14.7 68.3 18.3 73.0 20.3 75.1 20.9 76.9 21.1 78.6 21.3
35 49.3 12.3 58.8 15.7 68.3 19.5 73.0 21.6 73.9 21.7 75.7 21.9 77.4 22.1
37 49.3 13.1 58.8 16.7 68.3 20.8 71.8 22.4 72.7 22.5 74.5 22.7 76.3 22.9
39 49.3 13.9 58.8 17.8 68.3 22.2 70.6 23.1 71.5 23.2 73.3 23.4 75.1 23.7
NOTES
1 The above table shows the average value of conditions which may occur.
