• Outdoor Units • VRV HEAT RECOVERY • REYQ8-48P7Y1B
1
3
• VRV Systems • Outdoor Units
30
3 Capacity tables
3 - 2 Cooling capacity tables
REYQ30P
TC: Total capacity (kW); PI: Power input (kW) (Compressor + outdoor fan motor)
Combination
(%)
Capacity index
Outdoor air
temp. °CDB
Indoor air temp.: °CWB
14°C 16°C 18°C 19°C 20°C 22°C 24°C
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW KW KW
130 (975) 10 74.6 12.2 88.9 15.0 103 17.8 107 17.8 108 17.8 111 17.8 114 17.8
12 74.6 12.5 88.9 15.3 103 18.2 106 18.2 107 18.2 110 18.2 112 18.2
14 74.6 12.7 88.9 15.6 103 18.4 104 18.4 106 18.4 108 18.4 111 18.4
16 74.6 13.0 88.9 15.9 102 18.3 103 18.4 104 18.4 107 18.4 110 18.4
18 74.6 13.2 88.9 16.2 100 19.0 102 19.1 103 19.2 106 19.4 108 19.6
20 74.6 13.5 88.9 17.2 98.8 19.9 100 20.0 101 20.1 104 20.3 107 20.5
21 74.6 13.8 88.9 17.9 98.1 20.4 99.5 20.5 101 20.6 103 20.8 106 21.0
23 74.6 14.8 88.9 19.1 96.7 21.3 98.1 21.4 99.4 21.5 102 21.8 105 22.0
25 74.6 15.9 88.9 20.5 95.3 22.3 96.7 22.4 98.0 22.5 101 22.7 103 23.0
27 74.6 16.9 88.9 21.9 94.0 23.2 95.3 23.3 96.6 23.4 99.3 23.7 102 23.9
29 74.6 18.1 88.9 23.4 92.6 24.1 93.9 24.3 95.3 24.4 98.0 24.7 101 24.9
31 74.6 19.3 88.5 24.8 91.2 25.1 92.5 25.2 93.9 25.4 96.6 25.6 99.3 25.9
33 74.6 20.5 87.1 25.7 89.8 26.0 91.2 26.2 92.5 26.3 95.2 26.6 97.9 26.9
35 74.6 21.9 85.7 26.7 88.4 27.0 89.8 27.1 91.1 27.3 93.8 27.6 96.5 27.9
37 74.6 23.3 84.4 27.6 87.0 27.9 88.4 28.1 89.7 28.3 92.4 28.6 95.1 28.9
39 74.6 24.8 83.0 28.6 85.7 28.9 87.0 29.1 88.4 29.3 91.0 29.6 93.7 29.9
120 (900) 10 68.8 11.2 82.1 13.7 95.4 16.3 102 17.6 107 17.6 109 17.6 112 17.6
12 68.8 11.4 82.1 13.9 95.4 16.6 102 17.9 105 17.9 108 17.9 110 17.9
14 68.8 11.6 82.1 14.2 95.4 16.9 102 18.2 104 18.2 106 18.2 109 18.2
16 68.8 11.8 82.1 14.5 95.4 17.2 101 18.4 103 18.4 105 18.4 108 18.4
18 68.8 12.1 82.1 14.8 95.4 17.8 99.9 19.0 101 19.1 104 19.3 106 19.4
20 68.8 12.3 82.1 15.3 95.4 19.1 98.6 19.9 99.8 20.0 102 20.2 105 20.4
21 68.8 12.4 82.1 15.9 95.4 19.8 97.9 20.4 99.1 20.5 102 20.7 104 20.9
23 68.8 13.3 82.1 17.0 95.2 21.2 96.5 21.3 97.7 21.4 100 21.6 103 21.8
25 68.8 14.2 82.1 18.2 93.9 22.1 95.1 22.2 96.3 22.4 98.8 22.6 101 22.8
27 68.8 15.1 82.1 19.5 92.5 23.1 93.7 23.2 95.0 23.3 97.4 23.5 99.9 23.7
29 68.8 16.1 82.1 20.8 91.1 24.0 92.3 24.1 93.6 24.2 96.1 24.5 98.5 24.7
31 68.8 17.2 82.1 22.2 89.7 24.9 90.9 25.1 92.2 25.2 94.7 25.4 97.2 25.7
33 68.8 18.3 82.1 23.7 88.3 25.9 89.6 26.0 90.8 26.1 93.3 26.4 95.8 26.7
35 68.8 19.5 82.1 25.2 86.9 26.8 88.2 27.0 89.4 27.1 91.9 27.4 94.4 27.7
37 68.8 20.7 82.1 26.9 85.6 27.8 86.8 27.9 88.0 28.1 90.5 28.4 93.0 28.7
39 68.8 22.1 81.7 28.4 84.2 28.7 85.4 28.9 86.7 29.0 89.1 29.4 91.6 29.7
110 (825) 10 63.1 10.2 75.3 12.4 87.4 14.7 93.5 15.9 99.6 17.1 107 17.5 110 17.5
12 63.1 10.3 75.3 12.6 87.4 15.0 93.5 16.2 99.6 17.4 106 17.8 108 17.8
14 63.1 10.5 75.3 12.8 87.4 15.3 93.5 16.5 99.6 17.7 105 18.2 107 18.2
16 63.1 10.7 75.3 13.1 87.4 15.6 93.5 16.8 99.6 18.1 103 18.4 105 18.4
18 63.1 10.9 75.3 13.3 87.4 15.9 93.5 17.3 99.5 19.0 102 19.1 104 19.3
20 63.1 11.1 75.3 13.6 87.4 16.8 93.5 18.6 98.1 19.9 100 20.1 103 20.2
21 63.1 11.3 75.3 14.0 87.4 17.4 93.5 19.2 97.4 20.3 99.7 20.5 102 20.7
23 63.1 11.8 75.3 15.0 87.4 18.7 93.5 20.6 96.0 21.3 98.3 21.5 101 21.6
25 63.1 12.6 75.3 16.1 87.4 20.0 93.5 22.1 94.6 22.2 96.9 22.4 99.2 22.6
27 63.1 13.4 75.3 17.2 87.4 21.4 92.1 23.0 93.3 23.1 95.5 23.3 97.8 23.6
29 63.1 14.3 75.3 18.3 87.4 22.8 90.7 24.0 91.9 24.1 94.2 24.3 96.4 24.5
31 63.1 15.2 75.3 19.5 87.4 24.4 89.4 24.9 90.5 25.0 92.8 25.2 95.0 25.5
33 63.1 16.2 75.3 20.8 86.8 25.7 88.0 25.8 89.1 26.0 91.4 26.2 93.7 26.5
35 63.1 17.2 75.3 22.2 85.5 26.7 86.6 26.8 87.7 26.9 90.0 27.2 92.3 27.4
37 63.1 18.3 75.3 23.6 84.1 27.6 85.2 27.7 86.3 27.9 88.6 28.1 90.9 28.4
39 63.1 19.5 75.3 25.2 82.7 28.5 83.8 28.7 85.0 28.8 87.2 29.1 89.5 29.4
100 (750) 10 57.4 9.17 68.4 11.1 79.5 13.2 85.0 14.2 90.5 15.3 102 17.5 107 17.5
12 57.4 9.33 68.4 11.3 79.5 13.4 85.0 14.5 90.5 15.6 102 17.8 106 17.8
14 57.4 9.49 68.4 11.5 79.5 13.7 85.0 14.8 90.5 15.9 102 18.2 105 18.2
16 57.4 9.66 68.4 11.7 79.5 13.9 85.0 15.1 90.5 16.2 101 18.4 103 18.4
18 57.4 9.84 68.4 12.0 79.5 14.2 85.0 15.4 90.5 16.5 99.9 19.0 102 19.1
20 57.4 10.0 68.4 12.2 79.5 14.6 85.0 16.1 90.5 17.7 98.5 19.9 101 20.1
21 57.4 10.1 68.4 12.3 79.5 15.2 85.0 16.7 90.5 18.3 97.8 20.4 99.8 20.5
23 57.4 10.4 68.4 13.1 79.5 16.2 85.0 17.9 90.5 19.7 96.4 21.3 98.5 21.5
25 57.4 11.1 68.4 14.1 79.5 17.4 85.0 19.2 90.5 21.1 95.0 22.2 97.1 22.4
27 57.4 11.8 68.4 15.0 79.5 18.6 85.0 20.5 90.5 22.5 93.6 23.2 95.7 23.4
29 57.4 12.6 68.4 16.0 79.5 19.8 85.0 21.9 90.2 23.9 92.3 24.1 94.3 24.3
31 57.4 13.4 68.4 17.0 79.5 21.2 85.0 23.4 88.8 24.8 90.9 25.1 92.9 25.3
33 57.4 14.2 68.4 18.2 79.5 22.6 85.0 24.9 87.4 25.8 89.5 26.0 91.6 26.2
35 57.4 15.1 68.4 19.3 79.5 24.0 85.0 26.6 86.0 26.7 88.1 27.0 90.2 27.2
37 57.4 16.1 68.4 20.6 79.5 25.6 83.6 27.5 84.7 27.7 86.7 27.9 88.8 28.2
39 57.4 17.1 68.4 21.9 79.5 27.3 82.2 28.5 83.3 28.6 85.3 28.9 87.4 29.1
NOTES
1 The above table shows the average value of conditions which may occur.
