3 Capacity tables

3 - 3 Heating capacity tables

REYQ20P

TC: Total capacity (kW); PI: Power input (kW) (Compressor + outdoor fan motor)

Combination

(%)

Capacity index

Outdoor air temp.

Indoor air temp.: °CDB

16°C 18°C 20°C 21°C 22°C 24°C

TC PI TC PI TC PI TC PI TC PI TC PI

°CDB °CWB kW kW kW kW kW kW kW kW kW kW kW kW

130 (650) -19.8 -20.0 36.9 8.05 36.8 8.81 36.7 9.56 36.6 9.93 36.5 10.3 36.4 11.1

-18.8 -19.0 37.8 8.36 37.6 9.10 37.5 9.83 37.4 10.2 37.3 10.6 37.2 11.3

-16.7 -17.0 39.5 8.97 39.3 9.67 39.2 10.4 39.1 10.7 39.1 11.1 38.9 11.8

-13.7 -15.0 41.3 9.56 41.2 10.2 41.0 10.9 40.9 11.2 40.9 11.6 40.7 12.2

-11.8 -13.0 43.2 10.1 43.1 10.8 42.9 11.4 42.9 11.7 42.8 12.0 42.7 12.7

-9.8 -11.0 45.3 10.7 45.1 11.3 45.0 11.9 44.9 12.2 44.8 12.5 44.7 13.1

-9.5 -10.0 46.3 10.9 46.2 11.5 46.0 12.1 46.0 12.4 45.9 12.7 45.7 13.3

-8.5 -9.1 47.3 11.2 47.1 11.7 47.0 12.3 46.9 12.6 46.9 12.9 46.7 13.5

-7.0 -7.6 48.9 11.5 48.8 12.1 48.7 12.6 48.6 12.9 48.5 13.2 48.4 13.8

-5.0 -5.6 51.3 12.0 51.1 12.5 51.0 13.1 50.9 13.3 50.8 13.6 50.7 14.1

-3.0 -3.7 53.5 12.4 53.4 12.9 53.3 13.5 53.2 13.7 53.1 14.0 53.0 14.5

0.0 -0.7 57.4 13.1 57.2 13.5 57.1 14.0 57.0 14.3 56.9 14.5 56.8 15.0

3.0 2.2 61.3 13.6 61.1 14.1 61.0 14.5 60.9 14.8 60.8 15.0 60.7 15.4

5.0 4.1 63.9 14.0 63.8 14.4 63.6 14.8 63.6 15.1 63.5 15.3 63.4 15.7

7.0 6.0 66.7 14.3 66.6 14.7 66.4 15.1 66.3 15.3 66.3 15.6 66.1 16.0

9.0 7.9 69.6 14.6 69.4 15.0 69.3 15.4 69.2 15.6 69.1 15.8 69.0 16.2

11.0 9.8 72.5 14.9 72.4 15.3 72.2 15.7 72.2 15.9 72.1 16.1 70.8 16.0

13.0 11.8 75.7 15.2 75.6 15.6 75.5 16.0 75.4 16.1 75.3 16.3 70.8 15.2

15.0 13.7 78.9 15.5 78.8 15.9 78.6 16.2 78.5 16.4 76.0 15.8 70.8 14.5

120 (600) -19.8 -20.0 36.8 9.07 36.6 9.76 36.5 10.5 36.4 10.8 36.4 11.2 36.2 11.8

-18.8 -19.0 37.6 9.36 37.4 10.0 37.3 10.7 37.2 11.1 37.2 11.4 37.0 12.1

-16.7 -17.0 39.3 9.92 39.2 10.6 39.0 11.2 39.0 11.5 38.9 11.9 38.8 12.5

-13.7 -15.0 41.1 10.5 41.0 11.1 40.8 11.7 40.8 12.0 40.7 12.3 40.6 12.9

-11.8 -13.0 43.0 11.0 42.9 11.6 42.8 12.2 42.7 12.5 42.6 12.8 42.5 13.3

-9.8 -11.0 45.1 11.5 44.9 12.0 44.8 12.6 44.7 12.9 44.7 13.2 44.5 13.7

-9.5 -10.0 46.1 11.7 46.0 12.3 45.9 12.8 45.8 13.1 45.7 13.4 45.6 13.9

-8.5 -9.1 47.1 11.9 47.0 12.5 46.8 13.0 46.8 13.3 46.7 13.5 46.6 14.1

-7.0 -7.6 48.8 12.3 48.6 12.8 48.5 13.3 48.4 13.6 48.4 13.8 48.2 14.4

-5.0 -5.6 51.1 12.7 50.9 13.2 50.8 13.7 50.7 14.0 50.7 14.2 50.5 14.7

-3.0 -3.7 53.4 13.1 53.2 13.6 53.1 14.1 53.0 14.3 53.0 14.5 52.8 15.0

0.0 -0.7 57.2 13.7 57.0 14.2 56.9 14.6 56.8 14.8 56.8 15.0 56.6 15.5

3.0 2.2 61.1 14.2 60.9 14.7 60.8 15.1 60.7 15.3 60.7 15.5 60.5 15.9

5.0 4.1 63.7 14.6 63.6 15.0 63.5 15.4 63.4 15.6 63.3 15.7 63.2 16.1

7.0 6.0 66.5 14.9 66.4 15.3 66.2 15.6 66.2 15.8 66.1 16.0 65.4 16.1

9.0 7.9 69.4 15.2 69.2 15.5 69.1 15.9 69.0 16.1 69.0 16.3 65.4 15.3

11.0 9.8 72.3 15.5 72.2 15.8 72.1 16.1 72.0 16.3 70.2 15.9 65.4 14.6

13.0 11.8 75.5 15.7 75.4 16.1 75.0 16.3 72.6 15.7 70.2 15.0 65.4 13.8

15.0 13.7 78.7 16.0 78.6 16.3 75.0 15.5 72.6 14.9 70.2 14.3 65.4 13.2

110 (550) -19.8 -20.0 36.6 10.1 36.4 10.7 36.3 11.4 36.3 11.7 36.2 12.0 36.1 12.6

-18.8 -19.0 37.4 10.4 37.3 11.0 37.1 11.6 37.1 11.9 37.0 12.2 36.9 12.8

-16.7 -17.0 39.1 10.9 39.0 11.5 38.9 12.1 38.8 12.4 38.7 12.6 38.6 13.2

-13.7 -15.0 40.9 11.4 40.8 11.9 40.7 12.5 40.6 12.8 40.6 13.1 40.4 13.6

-11.8 -13.0 42.8 11.8 42.7 12.4 42.6 12.9 42.5 13.2 42.5 13.5 42.4 14.0

-9.8 -11.0 44.9 12.3 44.8 12.8 44.6 13.3 44.6 13.6 44.5 13.9 44.4 14.4

-9.5 -10.0 45.9 12.5 45.8 13.0 45.7 13.5 45.6 13.8 45.6 14.0 45.4 14.5

-8.5 -9.1 46.9 12.7 46.8 13.2 46.7 13.7 46.6 14.0 46.5 14.2 46.4 14.7

-7.0 -7.6 48.6 13.0 48.4 13.5 48.3 14.0 48.3 14.2 48.2 14.5 48.1 14.9

-5.0 -5.6 50.9 13.4 50.7 13.9 50.6 14.4 50.6 14.6 50.5 14.8 50.4 15.3

-3.0 -3.7 53.2 13.8 53.0 14.2 52.9 14.7 52.9 14.9 52.8 15.1 52.7 15.5

0.0 -0.7 57.0 14.4 56.8 14.8 56.7 15.2 56.7 15.4 56.6 15.6 56.5 16.0

3.0 2.2 60.9 14.8 60.7 15.2 60.6 15.6 60.6 15.8 60.5 16.0 59.9 16.2

5.0 4.1 63.5 15.1 63.4 15.5 63.3 15.9 63.2 16.0 63.2 16.2 59.9 15.3

7.0 6.0 66.3 15.4 66.2 15.8 66.1 16.1 66.0 16.3 64.3 15.8 59.9 14.5

9.0 7.9 69.2 15.7 69.1 16.0 68.8 16.3 66.5 15.7 64.3 15.0 59.9 13.8

11.0 9.8 72.1 16.0 72.0 16.3 68.8 15.5 66.5 14.9 64.3 14.3 59.9 13.2

13.0 11.8 75.4 16.2 73.2 15.8 68.8 14.7 66.5 14.1 64.3 13.6 59.9 12.5

15.0 13.7 77.6 16.1 73.2 15.1 68.8 14.0 66.5 13.5 64.3 12.9 59.9 11.9

100 (500) -19.8 -20.0 36.4 11.1 36.3 11.7 36.2 12.3 36.1 12.6 36.0 12.8 35.9 13.4

-18.8 -19.0 37.2 11.3 37.1 11.9 37.0 12.5 36.9 12.8 36.9 13.0 36.7 13.6

-16.7 -17.0 38.9 11.8 38.8 12.4 38.7 12.9 38.6 13.2 38.6 13.4 38.5 14.0

-13.7 -15.0 40.7 12.3 40.6 12.8 40.5 13.3 40.5 13.6 40.4 13.8 40.3 14.3

-11.8 -13.0 42.6 12.7 42.5 13.2 42.4 13.7 42.4 13.9 42.3 14.2 42.2 14.7

-9.8 -11.0 44.7 13.1 44.6 13.6 44.5 14.1 44.4 14.3 44.3 14.5 44.2 15.0

-9.5 -10.0 45.7 13.3 45.6 13.8 45.5 14.2 45.5 14.5 45.4 14.7 45.3 15.2

-8.5 -9.1 46.7 13.5 46.6 14.0 46.5 14.4 46.4 14.6 46.4 14.9 46.3 15.3

-7.0 -7.6 48.4 13.8 48.3 14.2 48.1 14.7 48.1 14.9 48.0 15.1 47.9 15.5

-5.0 -5.6 50.7 14.2 50.6 14.6 50.5 15.0 50.4 15.2 50.3 15.4 50.2 15.8

-3.0 -3.7 53.0 14.5 52.9 14.9 52.7 15.3 52.7 15.5 52.6 15.7 52.5 16.1

0.0 -0.7 56.8 15.0 56.7 15.4 56.6 15.7 56.5 15.9 56.4 16.1 54.5 15.6

3.0 2.2 60.7 15.4 60.6 15.8 60.5 16.1 60.4 16.3 58.5 15.7 54.5 14.4

5.0 4.1 63.4 15.7 63.2 16.0 62.5 16.1 60.5 15.5 58.5 14.9 54.5 13.7

7.0 6.0 66.1 16.0 66.0 16.3 62.5 15.3 60.5 14.7 58.5 14.1 54.5 13.0

9.0 7.9 69.0 16.2 66.5 15.7 62.5 14.5 60.5 14.0 58.5 13.4 54.5 12.4

11.0 9.8 70.5 16.0 66.5 14.9 62.5 13.8 60.5 13.3 58.5 12.8 54.5 11.8

13.0 11.8 70.5 15.1 66.5 14.1 62.5 13.1 60.5 12.6 58.5 12.2 54.5 11.2

15.0 13.7 70.5 14.4 66.5 13.5 62.5 12.5 60.5 12.1 58.5 11.6 54.5 10.7

NOTES

1 is shown as reference.

When selecting the unit models, avoid the outdoor air temperature range shown by

2 The above table shows the average value of conditions which may occur.
