Daikin REYQ14PY1B [33/137] Capacity tables
![Daikin REYQ16PY1B [33/137] Capacity tables](/views2/1713627/page33/bg21.png)
• Outdoor Units • VRV HEAT RECOVERY • REYQ8-48P7Y1B
1
3
• VRV Systems • Outdoor Units
32
3 Capacity tables
3 - 2 Cooling capacity tables
REYQ32P
TC: Total capacity (kW); PI: Power input (kW) (Compressor + outdoor fan motor)
Combination
(%)
Capacity index
Outdoor air
temp. °CDB
Indoor air temp.: °CWB
14°C 16°C 18°C 19°C 20°C 22°C 24°C
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW KW KW
130 (1040) 10 79.0 13.1 94.2 16.0 109 19.0 113 19.0 115 19.0 118 19.0 120 19.0
12 79.0 13.3 94.2 16.3 109 19.4 112 19.4 113 19.4 116 19.4 119 19.4
14 79.0 13.6 94.2 16.6 109 19.6 110 19.6 112 19.6 115 19.6 118 19.6
16 79.0 13.8 94.2 16.9 108 19.5 109 19.6 110 19.6 113 19.6 116 19.7
18 79.0 14.1 94.2 17.3 106 20.3 107 20.4 109 20.5 112 20.7 115 20.9
20 79.0 14.4 94.2 18.4 105 21.3 106 21.4 107 21.5 110 21.7 113 21.9
21 79.0 14.8 94.2 19.1 104 21.8 105 21.9 107 22.0 110 22.2 112 22.4
23 79.0 15.8 94.2 20.4 102 22.8 104 22.9 105 23.0 108 23.2 111 23.5
25 79.0 16.9 94.2 21.9 101 23.8 102 23.9 104 24.0 107 24.3 109 24.5
27 79.0 18.1 94.2 23.4 99.5 24.8 101 24.9 102 25.0 105 25.3 108 25.6
29 79.0 19.3 94.2 25.0 98.0 25.8 99.4 25.9 101 26.1 104 26.3 107 26.6
31 79.0 20.6 93.7 26.5 96.6 26.8 98.0 26.9 99.4 27.1 102 27.4 105 27.7
33 79.0 21.9 92.2 27.5 95.1 27.8 96.5 28.0 97.9 28.1 101 28.4 104 28.7
35 79.0 23.4 90.8 28.5 93.6 28.8 95.1 29.0 96.5 29.1 99.3 29.5 102 29.8
37 79.0 24.9 89.3 29.5 92.2 29.8 93.6 30.0 95.0 30.2 97.9 30.5 101 30.9
39 79.0 26.5 87.9 30.5 90.7 30.9 92.1 31.0 93.5 31.2 96.4 31.6 99.2 32.0
120 (960) 10 72.9 11.9 86.9 14.6 101 17.4 108 18.8 113 18.8 116 18.8 118 18.8
12 72.9 12.2 86.9 14.9 101 17.7 108 19.1 112 19.1 114 19.1 117 19.1
14 72.9 12.4 86.9 15.2 101 18.0 108 19.5 110 19.5 113 19.5 115 19.5
16 72.9 12.6 86.9 15.4 101 18.4 107 19.6 109 19.6 111 19.6 114 19.7
18 72.9 12.9 86.9 15.8 101 19.0 106 20.3 107 20.4 110 20.6 112 20.7
20 72.9 13.1 86.9 16.4 101 20.4 104 21.3 106 21.4 108 21.6 111 21.8
21 72.9 13.3 86.9 17.0 101 21.2 104 21.8 105 21.9 108 22.1 110 22.3
23 72.9 14.2 86.9 18.2 101 22.6 102 22.8 103 22.9 106 23.1 109 23.3
25 72.9 15.1 86.9 19.4 99.4 23.6 101 23.7 102 23.9 105 24.1 107 24.3
27 72.9 16.2 86.9 20.8 97.9 24.6 99.2 24.7 101 24.9 103 25.1 106 25.4
29 72.9 17.2 86.9 22.2 96.4 25.6 97.8 25.8 99.1 25.9 102 26.1 104 26.4
31 72.9 18.4 86.9 23.7 95.0 26.6 96.3 26.8 97.6 26.9 100 27.2 103 27.4
33 72.9 19.6 86.9 25.3 93.5 27.6 94.8 27.8 96.1 27.9 98.8 28.2 101 28.5
35 72.9 20.8 86.9 27.0 92.1 28.6 93.4 28.8 94.7 28.9 97.3 29.2 99.9 29.5
37 72.9 22.2 86.9 28.7 90.6 29.6 91.9 29.8 93.2 30.0 95.8 30.3 98.5 30.6
39 72.9 23.6 86.5 30.3 89.1 30.7 90.4 30.8 91.8 31.0 94.4 31.3 97.0 31.7
110 (880) 10 66.8 10.9 79.7 13.2 92.6 15.7 99.0 17.0 105 18.2 114 18.7 116 18.7
12 66.8 11.0 79.7 13.5 92.6 16.0 99.0 17.3 105 18.6 112 19.0 115 19.0
14 66.8 11.2 79.7 13.7 92.6 16.3 99.0 17.6 105 18.9 111 19.4 113 19.4
16 66.8 11.5 79.7 14.0 92.6 16.6 99.0 18.0 105 19.3 109 19.6 112 19.7
18 66.8 11.7 79.7 14.3 92.6 16.9 99.0 18.4 105 20.2 108 20.4 110 20.6
20 66.8 11.9 79.7 14.5 92.6 17.9 99.0 19.8 104 21.2 106 21.4 109 21.6
21 66.8 12.0 79.7 15.0 92.6 18.6 99.0 20.5 103 21.7 106 21.9 108 22.1
23 66.8 12.6 79.7 16.0 92.6 19.9 99.0 22.0 102 22.7 104 22.9 106 23.1
25 66.8 13.4 79.7 17.2 92.6 21.3 99.0 23.6 100 23.7 103 23.9 105 24.1
27 66.8 14.3 79.7 18.3 92.6 22.8 97.5 24.6 98.7 24.7 101 24.9 104 25.1
29 66.8 15.3 79.7 19.6 92.6 24.4 96.1 25.6 97.3 25.7 99.7 25.9 102 26.2
31 66.8 16.3 79.7 20.9 92.6 26.0 94.6 26.6 95.8 26.7 98.2 27.0 101 27.2
33 66.8 17.3 79.7 22.2 91.9 27.5 93.1 27.6 94.4 27.7 96.8 28.0 99.2 28.2
35 66.8 18.4 79.7 23.7 90.5 28.5 91.7 28.6 92.9 28.7 95.3 29.0 97.7 29.3
37 66.8 19.6 79.7 25.2 89.0 29.5 90.2 29.6 91.4 29.7 93.8 30.0 96.2 30.3
39 66.8 20.8 79.7 26.9 87.6 30.5 88.8 30.6 90.0 30.8 92.4 31.1 94.8 31.4
100 (800) 10 60.7 9.79 72.4 11.9 84.1 14.1 90.0 15.2 95.9 16.3 108 18.7 114 18.7
12 60.7 9.96 72.4 12.1 84.1 14.3 90.0 15.5 95.9 16.6 108 19.0 112 19.0
14 60.7 10.1 72.4 12.3 84.1 14.6 90.0 15.8 95.9 17.0 108 19.4 111 19.4
16 60.7 10.3 72.4 12.5 84.1 14.9 90.0 16.1 95.9 17.3 107 19.6 109 19.7
18 60.7 10.5 72.4 12.8 84.1 15.2 90.0 16.4 95.9 17.6 106 20.3 108 20.4
20 60.7 10.7 72.4 13.0 84.1 15.6 90.0 17.2 95.9 18.9 104 21.3 106 21.4
21 60.7 10.8 72.4 13.2 84.1 16.2 90.0 17.8 95.9 19.6 104 21.8 106 21.9
23 60.7 11.1 72.4 14.0 84.1 17.3 90.0 19.1 95.9 21.0 102 22.7 104 22.9
25 60.7 11.8 72.4 15.0 84.1 18.5 90.0 20.5 95.9 22.5 101 23.7 103 23.9
27 60.7 12.6 72.4 16.0 84.1 19.8 90.0 21.9 95.9 24.0 99.1 24.7 101 24.9
29 60.7 13.4 72.4 17.1 84.1 21.2 90.0 23.4 95.5 25.5 97.7 25.7 99.9 26.0
31 60.7 14.3 72.4 18.2 84.1 22.6 90.0 25.0 94.0 26.5 96.2 26.7 98.4 27.0
33 60.7 15.2 72.4 19.4 84.1 24.1 90.0 26.6 92.6 27.5 94.7 27.8 96.9 28.0
35 60.7 16.2 72.4 20.6 84.1 25.7 90.0 28.4 91.1 28.5 93.3 28.8 95.5 29.0
37 60.7 17.2 72.4 22.0 84.1 27.4 88.5 29.4 89.6 29.5 91.8 29.8 94.0 30.1
39 60.7 18.2 72.4 23.4 84.1 29.1 87.1 30.4 88.2 30.5 90.4 30.8 92.5 31.1
NOTES
1 The above table shows the average value of conditions which may occur.
