Daikin REYQ14PY1B [39/137] Capacity tables
![Daikin REYQ14PY1B [39/137] Capacity tables](/views2/1713627/page39/bg27.png)
• Outdoor Units • VRV HEAT RECOVERY • REYQ8-48P7Y1B
1
3
• VRV Systems • Outdoor Units
38
3 Capacity tables
3 - 2 Cooling capacity tables
REYQ38P
TC: Total capacity (kW); PI: Power input (kW) (Compressor + outdoor fan motor)
Combination
(%)
Capacity index
Outdoor air
temp. °CDB
Indoor air temp.: °CWB
14°C 16°C 18°C 19°C 20°C 22°C 24°C
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW KW KW
130 (1235) 10 93.9 14.4 112 17.6 130 20.9 135 20.9 136 20.9 140 20.9 143 20.9
12 93.9 14.6 112 17.9 130 21.3 133 21.3 135 21.3 138 21.3 141 21.3
14 93.9 14.9 112 18.3 130 21.6 131 21.6 133 21.6 136 21.6 140 21.6
16 93.9 15.2 112 18.6 128 21.5 130 21.6 131 21.6 135 21.6 138 21.6
18 93.9 15.5 112 19.0 126 22.3 128 22.4 129 22.5 133 22.7 136 23.0
20 93.9 15.8 112 20.2 124 23.4 126 23.5 128 23.6 131 23.9 135 24.1
21 93.9 16.2 112 21.0 123 23.9 125 24.0 127 24.2 130 24.4 134 24.6
23 93.9 17.4 112 22.5 122 25.0 123 25.1 125 25.3 129 25.5 132 25.8
25 93.9 18.6 112 24.0 120 26.1 122 26.3 123 26.4 127 26.7 130 26.9
27 93.9 19.9 112 25.7 118 27.2 120 27.4 122 27.5 125 27.8 128 28.1
29 93.9 21.2 112 27.5 117 28.3 118 28.5 120 28.6 123 28.9 127 29.2
31 93.9 22.6 111 29.1 115 29.4 116 29.6 118 29.7 122 30.1 125 30.4
33 93.9 24.1 110 30.2 113 30.5 115 30.7 116 30.9 120 31.2 123 31.6
35 93.9 25.7 108 31.3 111 31.7 113 31.8 115 32.0 118 32.4 121 32.7
37 93.9 27.3 106 32.4 110 32.8 111 33.0 113 33.2 116 33.5 120 33.9
39 93.9 29.1 104 33.5 108 33.9 110 34.1 111 34.3 115 34.7 118 35.1
120 (1140) 10 86.7 13.1 103 16.0 120 19.1 128 20.6 134 20.6 137 20.6 141 20.6
12 86.7 13.4 103 16.3 120 19.4 128 21.0 133 21.0 136 21.0 139 21.0
14 86.7 13.6 103 16.6 120 19.8 128 21.4 131 21.4 134 21.4 137 21.4
16 86.7 13.9 103 17.0 120 20.2 128 21.6 129 21.6 132 21.6 135 21.6
18 86.7 14.1 103 17.3 120 20.9 126 22.3 127 22.4 130 22.6 134 22.8
20 86.7 14.4 103 18.0 120 22.4 124 23.4 126 23.5 129 23.7 132 23.9
21 86.7 14.6 103 18.6 120 23.3 123 23.9 125 24.0 128 24.2 131 24.5
23 86.7 15.6 103 20.0 120 24.9 121 25.0 123 25.1 126 25.4 129 25.6
25 86.7 16.6 103 21.4 118 26.0 120 26.1 121 26.2 124 26.5 128 26.7
27 86.7 17.7 103 22.8 116 27.1 118 27.2 120 27.3 123 27.6 126 27.9
29 86.7 18.9 103 24.4 115 28.1 116 28.3 118 28.4 121 28.7 124 29.0
31 86.7 20.2 103 26.0 113 29.2 114 29.4 116 29.5 119 29.8 122 30.1
33 86.7 21.5 103 27.8 111 30.4 113 30.5 114 30.7 117 31.0 121 31.3
35 86.7 22.9 103 29.6 109 31.5 111 31.6 113 31.8 116 32.1 119 32.5
37 86.7 24.3 103 31.6 108 32.6 109 32.7 111 32.9 114 33.3 117 33.6
39 86.7 25.9 103 33.3 106 33.7 108 33.9 109 34.1 112 34.4 115 34.8
110 (1045) 10 79.4 11.9 94.7 14.5 110 17.2 118 18.6 125 20.0 135 20.5 138 20.5
12 79.4 12.1 94.7 14.8 110 17.6 118 19.0 125 20.4 133 20.9 136 20.9
14 79.4 12.4 94.7 15.1 110 17.9 118 19.3 125 20.8 132 21.3 134 21.3
16 79.4 12.6 94.7 15.4 110 18.2 118 19.7 125 21.2 130 21.6 133 21.6
18 79.4 12.8 94.7 15.7 110 18.6 118 20.3 125 22.2 128 22.4 131 22.6
20 79.4 13.1 94.7 16.0 110 19.7 118 21.8 123 23.3 126 23.5 129 23.7
21 79.4 13.2 94.7 16.5 110 20.4 118 22.6 123 23.9 125 24.1 128 24.3
23 79.4 13.8 94.7 17.6 110 21.9 118 24.2 121 25.0 124 25.2 127 25.4
25 79.4 14.8 94.7 18.8 110 23.4 118 25.9 119 26.0 122 26.3 125 26.5
27 79.4 15.7 94.7 20.1 110 25.1 116 27.0 117 27.1 120 27.4 123 27.6
29 79.4 16.8 94.7 21.5 110 26.8 114 28.1 116 28.2 119 28.5 121 28.8
31 79.4 17.9 94.7 22.9 110 28.6 112 29.2 114 29.3 117 29.6 120 29.9
33 79.4 19.0 94.7 24.4 109 30.2 111 30.3 112 30.5 115 30.7 118 31.0
35 79.4 20.2 94.7 26.0 108 31.3 109 31.4 110 31.6 113 31.9 116 32.2
37 79.4 21.5 94.7 27.7 106 32.4 107 32.5 109 32.7 112 33.0 114 33.3
39 79.4 22.9 94.7 29.5 104 33.5 106 33.6 107 33.8 110 34.1 113 34.5
100 (950) 10 72.2 10.8 86.1 13.0 100 15.4 107 16.7 114 17.9 128 20.5 135 20.5
12 72.2 10.9 86.1 13.3 100 15.7 107 17.0 114 18.3 128 20.9 134 20.9
14 72.2 11.1 86.1 13.5 100 16.0 107 17.3 114 18.6 128 21.3 132 21.3
16 72.2 11.3 86.1 13.8 100 16.3 107 17.7 114 19.0 127 21.6 130 21.6
18 72.2 11.5 86.1 14.0 100 16.7 107 18.0 114 19.4 126 22.3 128 22.4
20 72.2 11.8 86.1 14.3 100 17.2 107 18.9 114 20.8 124 23.4 127 23.5
21 72.2 11.9 86.1 14.5 100 17.8 107 19.6 114 21.5 123 23.9 126 24.1
23 72.2 12.2 86.1 15.4 100 19.0 107 21.0 114 23.1 121 25.0 124 25.2
25 72.2 13.0 86.1 16.5 100 20.4 107 22.5 114 24.7 120 26.1 122 26.3
27 72.2 13.9 86.1 17.6 100 21.8 107 24.0 114 26.4 118 27.2 120 27.4
29 72.2 14.8 86.1 18.8 100 23.3 107 25.7 114 28.0 116 28.3 119 28.5
31 72.2 15.7 86.1 20.0 100 24.8 107 27.4 112 29.1 114 29.4 117 29.6
33 72.2 16.7 86.1 21.3 100 26.5 107 29.3 110 30.2 113 30.5 115 30.8
35 72.2 17.8 86.1 22.7 100 28.2 107 31.2 108 31.3 111 31.6 114 31.9
37 72.2 18.9 86.1 24.1 100 30.0 105 32.3 107 32.4 109 32.7 112 33.0
39 72.2 20.0 86.1 25.7 100 32.0 104 33.4 105 33.6 107 33.9 110 34.2
NOTES
1 The above table shows the average value of conditions which may occur.
