Daikin REYQ14PY1B [89/137] Capacity tables
![Daikin REYQ14PY1B [89/137] Capacity tables](/views2/1713627/page89/bg59.png)
• Outdoor Units • VRV HEAT RECOVERY • REYQ8-48P7Y1B
1
3
• VRV Systems • Outdoor Units
88
3 Capacity tables
3 - 3 Heating capacity tables
REYQ46P
TC: Total capacity (kW); PI: Power input (kW) (Compressor + outdoor fan motor)
Combination
(%)
Capacity index
Outdoor air temp.
Indoor air temp.: °CDB
16°C 18°C 20°C 21°C 22°C 24°C
TC PI TC PI TC PI TC PI TC PI TC PI
°CDB °CWB kW kW kW kW kW kW kW kW kW kW kW kW
130 (1495) -19.8 -20.0 87.7 21.5 87.3 23.3 87.0 25.2 86.9 26.1 86.7 27.0 86.4 28.9
-18.8 -19.0 89.3 22.1 88.9 23.9 88.6 25.7 88.4 26.6 88.3 27.5 87.9 29.4
-16.7 -17.0 92.7 23.3 92.4 25.1 92.0 26.9 91.9 27.7 91.7 28.6 91.4 30.4
-13.7 -15.0 96.5 24.7 96.2 26.3 95.8 28.0 95.7 28.8 95.5 29.7 95.2 31.4
-11.8 -13.0 101 26.0 100 27.6 100 29.2 99.9 30.0 99.7 30.8 99.4 32.4
-9.8 -11.0 105 27.3 105 28.8 105 30.3 104 31.1 104 31.9 104 33.4
-9.5 -10.0 108 27.9 107 29.4 107 30.9 107 31.7 107 32.4 106 33.9
-8.5 -9.1 110 28.5 110 30.0 109 31.4 109 32.1 109 32.9 109 34.3
-7.0 -7.6 114 29.4 114 30.9 113 32.3 113 33.0 113 33.7 113 35.1
-5.0 -5.6 120 30.7 119 32.0 119 33.4 119 34.0 119 34.7 118 36.0
-3.0 -3.7 125 31.8 125 33.1 125 34.4 125 35.0 124 35.6 124 36.9
0.0 -0.7 135 33.5 135 34.7 134 35.9 134 36.5 134 37.0 134 38.2
3.0 2.2 145 35.0 145 36.1 145 37.2 145 37.8 144 38.3 144 39.4
5.0 4.1 152 36.0 152 37.0 152 38.1 152 38.6 151 39.1 151 40.1
7.0 6.0 160 36.9 160 37.9 159 38.9 159 39.4 159 39.8 159 40.8
9.0 7.9 168 37.7 167 38.7 167 39.6 167 40.1 167 40.6 164 40.6
11.0 9.8 176 38.5 176 39.4 175 40.3 175 40.8 175 41.2 164 38.3
13.0 11.8 185 39.3 185 40.2 184 41.0 182 40.8 176 39.2 164 36.0
15.0 13.7 194 40.1 194 40.9 189 40.1 182 38.5 176 37.0 164 34.0
120 (1380) -19.8 -20.0 87.2 24.0 86.9 25.7 86.6 27.4 86.5 28.3 86.3 29.1 86.0 30.8
-18.8 -19.0 88.8 24.5 88.5 26.2 88.2 27.9 88.0 28.7 87.9 29.6 87.6 31.3
-16.7 -17.0 92.2 25.7 91.9 27.3 91.6 28.9 91.5 29.8 91.3 30.6 91.0 32.2
-13.7 -15.0 96.1 26.9 95.8 28.5 95.4 30.0 95.3 30.8 95.1 31.6 94.8 33.1
-11.8 -13.0 100 28.1 100 29.6 99.7 31.1 99.5 31.8 99.3 32.6 99.0 34.1
-9.8 -11.0 105 29.3 105 30.8 104 32.2 104 32.9 104 33.6 104 35.0
-9.5 -10.0 107 29.9 107 31.3 107 32.7 107 33.4 106 34.1 106 35.5
-8.5 -9.1 110 30.5 109 31.8 109 33.2 109 33.8 109 34.5 108 35.9
-7.0 -7.6 114 31.3 113 32.6 113 33.9 113 34.6 113 35.2 112 36.5
-5.0 -5.6 119 32.5 119 33.7 119 35.0 118 35.6 118 36.2 118 37.4
-3.0 -3.7 125 33.5 125 34.7 124 35.9 124 36.5 124 37.1 124 38.2
0.0 -0.7 135 35.1 134 36.2 134 37.3 134 37.8 134 38.4 133 39.5
3.0 2.2 145 36.5 145 37.5 144 38.5 144 39.0 144 39.5 144 40.6
5.0 4.1 152 37.4 152 38.3 151 39.3 151 39.8 151 40.3 151 41.2
7.0 6.0 160 38.2 159 39.1 159 40.0 159 40.5 159 41.0 152 39.1
9.0 7.9 167 39.0 167 39.9 167 40.7 167 41.2 163 40.2 152 36.9
11.0 9.8 176 39.7 175 40.6 174 41.0 168 39.4 163 37.9 152 34.8
13.0 11.8 185 40.5 184 41.3 174 38.6 168 37.1 163 35.6 152 32.8
15.0 13.7 193 41.2 185 39.2 174 36.4 168 35.0 163 33.7 152 31.0
110 (1265) -19.8 -20.0 86.8 26.5 86.5 28.1 86.2 29.6 86.1 30.4 85.9 31.2 85.7 32.8
-18.8 -19.0 88.4 27.0 88.1 28.5 87.8 30.1 87.7 30.9 87.5 31.6 87.2 33.2
-16.7 -17.0 91.8 28.1 91.5 29.6 91.2 31.0 91.1 31.8 90.9 32.5 90.7 34.0
-13.7 -15.0 95.6 29.2 95.3 30.6 95.1 32.0 94.9 32.7 94.8 33.4 94.5 34.9
-11.8 -13.0 99.8 30.3 99.5 31.7 99.3 33.0 99.1 33.7 99.0 34.4 98.7 35.7
-9.8 -11.0 104 31.4 104 32.7 104 34.0 104 34.6 104 35.3 103 36.6
-9.5 -10.0 107 32.0 107 33.2 106 34.5 106 35.1 106 35.7 106 37.0
-8.5 -9.1 109 32.4 109 33.7 109 34.9 108 35.5 108 36.2 108 37.4
-7.0 -7.6 113 33.2 113 34.4 113 35.6 112 36.2 112 36.8 112 38.0
-5.0 -5.6 119 34.3 118 35.4 118 36.6 118 37.1 118 37.7 118 38.8
-3.0 -3.7 124 35.3 124 36.3 124 37.4 124 37.9 124 38.5 123 39.6
0.0 -0.7 134 36.7 134 37.7 134 38.7 134 39.2 133 39.7 133 40.7
3.0 2.2 144 38.0 144 38.9 144 39.8 144 40.3 144 40.8 139 39.7
5.0 4.1 152 38.8 151 39.7 151 40.6 151 41.0 149 40.8 139 37.4
7.0 6.0 159 39.6 159 40.4 159 41.2 154 40.0 149 38.4 139 35.3
9.0 7.9 167 40.3 167 41.1 160 39.2 154 37.7 149 36.2 139 33.3
11.0 9.8 175 41.0 170 39.8 160 37.0 154 35.5 149 34.2 139 31.4
13.0 11.8 180 40.2 170 37.4 160 34.8 154 33.5 149 32.2 139 29.6
15.0 13.7 180 37.9 170 35.3 160 32.9 154 31.6 149 30.4 139 28.1
100 (1150) -19.8 -20.0 86.3 29.0 86.1 30.4 85.8 31.8 85.7 32.6 85.6 33.3 85.3 34.7
-18.8 -19.0 87.9 29.5 87.7 30.9 87.4 32.3 87.3 33.0 87.1 33.7 86.9 35.1
-16.7 -17.0 91.3 30.4 91.1 31.8 90.8 33.1 90.7 33.8 90.6 34.5 90.3 35.8
-13.7 -15.0 95.2 31.5 94.9 32.7 94.7 34.0 94.5 34.7 94.4 35.3 94.1 36.6
-11.8 -13.0 99.4 32.5 99.1 33.7 98.9 34.9 98.7 35.5 98.6 36.2 98.4 37.4
-9.8 -11.0 104 33.5 104 34.7 103 35.8 103 36.4 103 37.0 103 38.2
-9.5 -10.0 106 34.0 106 35.1 106 36.3 106 36.8 106 37.4 105 38.6
-8.5 -9.1 109 34.4 108 35.5 108 36.7 108 37.2 108 37.8 108 38.9
-7.0 -7.6 113 35.2 112 36.2 112 37.3 112 37.9 112 38.4 112 39.5
-5.0 -5.6 118 36.1 118 37.1 118 38.2 118 38.7 118 39.2 117 40.2
-3.0 -3.7 124 37.0 124 38.0 124 38.9 123 39.4 123 39.9 123 40.9
0.0 -0.7 134 38.3 134 39.2 133 40.1 133 40.6 133 41.0 126 38.8
3.0 2.2 144 39.5 144 40.3 143 41.2 140 40.2 136 38.6 126 35.5
5.0 4.1 151 40.2 151 41.0 145 39.4 140 37.9 136 36.4 126 33.4
7.0 6.0 159 40.9 154 40.0 145 37.1 140 35.7 136 34.3 126 31.6
9.0 7.9 164 40.4 154 37.7 145 35.0 140 33.7 136 32.4 126 29.8
11.0 9.8 164 38.1 154 35.5 145 33.0 140 31.8 136 30.6 126 28.2
13.0 11.8 164 35.8 154 33.4 145 31.1 140 30.0 136 28.8 126 26.6
15.0 13.7 164 33.9 154 31.6 145 29.4 140 28.4 136 27.3 126 25.3
NOTES
1 is shown as reference.
When selecting the unit models, avoid the outdoor air temperature range shown by
2 The above table shows the average value of conditions which may occur.
