Daikin REYQ14PY1B [54/137] Combination

• VRV Systems • Outdoor Units

• Outdoor Units • VRV HEAT RECOVERY • REYQ8-48P7Y1B

3 Capacity tables

3 - 3 Heating capacity tables

REYQ10P

TC: Total capacity (kW); PI: Power Input (kW) (Comp.+Outdoor fan motor)

Combination (%)

Capacity

index

Outdoor air temp.

Indoor air temp.(°CDB)

16.0 18.0 20.0 21.0 22.0 24.0

TC PI TC PI TC PI TC PI TC PI TC PI

(°CDB)(°CWB)KWKWKWKWKWKWKWKWKWKWKWKW

90% (450)

-19.8 -20.0 20.3 7.42 20.2 7.67 20.2 7.93 20.1 8.06 20.1 8.18 20.1 8.44

-18.8 -19.0 20.6 7.50 20.6 7.75 20.5 8.00 20.5 8.13 20.5 8.25 20.4 8.50

-16.7 -17.0 21.4 7.68 21.4 7.92 21.3 8.16 21.3 8.28 21.3 8.40 21.2 8.64

-13.7 -15.0 22.3 7.86 22.2 8.09 22.2 8.32 22.2 8.44 22.1 8.55 22.1 8.78

-11.8 -13.0 23.3 8.04 23.2 8.26 23.2 8.49 23.1 8.60 23.1 8.71 23.1 8.93

-9.8 -11.0 24.4 8.23 24.3 8.44 24.3 8.65 24.2 8.76 24.2 8.86 24.2 9.08

-9.5 -10.0 24.9 8.32 24.9 8.53 24.8 8.74 24.8 8.84 24.8 8.94 24.7 9.13

-8.5 -9.1 25.5 8.41 25.4 8.61 25.4 8.81 25.4 8.91 25.3 9.01 24.7 8.88

-7.0 -7.6 26.4 8.54 26.4 8.74 26.3 8.93 26.3 9.03 26.3 9.13 24.7 8.48

-5.0 -5.6 27.8 8.72 27.7 8.91 27.7 9.09 27.4 9.07 26.5 8.70 24.7 7.97

-3.0 -3.7 29.2 8.89 29.1 9.06 28.4 8.88 27.4 8.53 26.5 8.19 24.7 7.51

0.0 -0.7 31.5 9.13 30.2 8.70 28.4 8.06 27.4 7.75 26.5 7.44 24.7 6.84

3.0 2.2 32.0 8.50 30.2 7.92 28.4 7.34 27.4 7.06 26.5 6.79 24.7 6.25

5.0 4.1 32.0 7.99 30.2 7.45 28.4 6.92 27.4 6.66 26.5 6.40 24.7 5.90

7.0 6.0 32.0 7.52 30.2 7.01 28.4 6.52 27.4 6.28 26.5 6.04 24.7 5.57

9.0 7.9 32.0 7.08 30.2 6.61 28.4 6.15 27.4 5.92 26.5 5.70 24.7 5.26

11.0 9.8 32.0 6.67 30.2 6.23 28.4 5.81 27.4 5.60 26.5 5.39 24.7 4.98

13.0 11.8 32.0 6.28 30.2 5.87 28.4 5.47 27.4 5.28 26.5 5.08 24.7 4.71

15.0 13.7 32.0 5.93 30.2 5.55 28.4 5.18 27.4 5.00 26.5 4.82 24.7 4.46

80% (400)

-19.8 -20.0 20.2 7.92 20.1 8.14 20.1 8.37 20.1 8.48 20.0 8.60 20.0 8.82

-18.8 -19.0 20.5 7.99 20.5 8.21 20.4 8.44 20.4 8.55 20.4 8.66 20.3 8.88

-16.7 -17.0 21.3 8.15 21.3 8.36 21.2 8.58 21.2 8.68 21.2 8.79 21.1 9.01

-13.7 -15.0 22.2 8.31 22.1 8.52 22.1 8.72 22.1 8.83 22.1 8.93 22.0 9.10

-11.8 -13.0 23.2 8.48 23.1 8.67 23.1 8.87 23.1 8.97 23.0 9.07 22.0 8.61

-9.8 -11.0 24.3 8.64 24.2 8.83 24.2 9.02 24.1 9.11 23.6 8.88 22.0 8.13

-9.5 -10.0 24.8 8.73 24.8 8.91 24.8 9.09 24.4 8.99 23.6 8.62 22.0 7.90

-8.5 -9.1 25.4 8.80 25.3 8.98 25.2 9.11 24.4 8.74 23.6 8.39 22.0 7.69

-7.0 -7.6 26.3 8.92 26.3 9.10 25.2 8.69 24.4 8.35 23.6 8.01 22.0 7.35

-5.0 -5.6 27.7 9.08 26.8 8.82 25.2 8.17 24.4 7.85 23.6 7.53 22.0 6.92

-3.0 -3.7 28.4 8.92 26.8 8.30 25.2 7.69 24.4 7.40 23.6 7.10 22.0 6.53

0.0 -0.7 28.4 8.09 26.8 7.54 25.2 7.00 24.4 6.73 23.6 6.47 22.0 5.96

3.0 2.2 28.4 7.37 26.8 6.88 25.2 6.39 24.4 6.16 23.6 5.92 22.0 5.47

5.0 4.1 28.4 6.94 26.8 6.48 25.2 6.03 24.4 5.81 23.6 5.59 22.0 5.17

7.0 6.0 28.4 6.54 26.8 6.11 25.2 5.69 24.4 5.49 23.6 5.29 22.0 4.89

9.0 7.9 28.4 6.17 26.8 5.77 25.2 5.38 24.4 5.19 23.6 5.00 22.0 4.63

11.0 9.8 28.4 5.83 26.8 5.45 25.2 5.09 24.4 4.91 23.6 4.73 22.0 4.39

13.0 11.8 28.4 5.49 26.8 5.15 25.2 4.81 24.4 4.64 23.6 4.48 22.0 4.15

15.0 13.7 28.4 5.20 26.8 4.88 25.2 4.56 24.4 4.40 23.6 4.25 22.0 3.95

70% (350)

-19.8 -20.0 20.1 8.41 20.0 8.61 20.0 8.81 20.0 8.91 19.9 9.01 19.2 8.71

-18.8 -19.0 20.4 8.48 20.4 8.68 20.3 8.87 20.3 8.97 20.3 9.07 19.2 8.52

-16.7 -17.0 21.2 8.62 21.2 8.81 21.1 8.99 21.1 9.09 20.6 8.87 19.2 8.12

-13.7 -15.0 22.1 8.76 22.1 8.94 22.0 9.12 21.3 8.78 20.6 8.42 19.2 7.72

-11.8 -13.0 23.1 8.91 23.0 9.08 22.1 8.66 21.3 8.31 20.6 7.98 19.2 7.32

-9.8 -11.0 24.2 9.06 23.5 8.83 22.1 8.17 21.3 7.86 20.6 7.54 19.2 6.93

-9.5 -10.0 24.7 9.13 23.5 8.57 22.1 7.94 21.3 7.63 20.6 7.33 19.2 6.74

-8.5 -9.1 24.9 8.96 23.5 8.34 22.1 7.73 21.3 7.43 20.6 7.14 19.2 6.56

-7.0 -7.6 24.9 8.56 23.5 7.97 22.1 7.39 21.3 7.11 20.6 6.83 19.2 6.29

-5.0 -5.6 24.9 8.04 23.5 7.49 22.1 6.96 21.3 6.69 20.6 6.43 19.2 5.93

-3.0 -3.7 24.9 7.58 23.5 7.06 22.1 6.56 21.3 6.32 20.6 6.08 19.2 5.61

0.0 -0.7 24.9 6.89 23.5 6.44 22.1 5.99 21.3 5.77 20.6 5.56 19.2 5.13

3.0 2.2 24.9 6.30 23.5 5.89 22.1 5.49 21.3 5.29 20.6 5.10 19.2 4.72

5.0 4.1 24.9 5.94 23.5 5.56 22.1 5.19 21.3 5.01 20.6 4.83 19.2 4.47

7.0 6.0 24.9 5.61 23.5 5.26 22.1 4.91 21.3 4.74 20.6 4.57 19.2 4.24

9.0 7.9 24.9 5.31 23.5 4.97 22.1 4.65 21.3 4.49 20.6 4.33 19.2 4.02

11.0 9.8 24.9 5.02 23.5 4.71 22.1 4.41 21.3 4.26 20.6 4.11 19.2 3.82

13.0 11.8 24.9 4.74 23.5 4.45 22.1 4.17 21.3 4.03 20.6 3.89 19.2 3.62

15.0 13.7 24.9 4.50 23.5 4.23 22.1 3.96 21.3 3.83 20.6 3.70 19.2 3.45

60% (300)

-19.8 -20.0 20.0 8.91 19.9 9.08 18.9 8.53 18.3 8.20 17.7 7.87 16.5 7.22

-18.8 -19.0 20.3 8.97 20.1 9.01 18.9 8.34 18.3 8.02 17.7 7.70 16.5 7.07

-16.7 -17.0 21.1 9.09 20.1 8.59 18.9 7.96 18.3 7.65 17.7 7.35 16.5 6.75

-13.7 -15.0 21.3 8.78 20.1 8.17 18.9 7.57 18.3 7.28 17.7 6.99 16.5 6.43

-11.8 -13.0 21.3 8.31 20.1 7.74 18.9 7.18 18.3 6.91 17.7 6.64 16.5 6.11

-9.8 -11.0 21.3 7.85 20.1 7.32 18.9 6.79 18.3 6.54 17.7 6.29 16.5 5.80

-9.5 -10.0 21.3 7.62 20.1 7.11 18.9 6.61 18.3 6.36 17.7 6.12 16.5 5.64

-8.5 -9.1 21.3 7.43 20.1 6.93 18.9 6.44 18.3 6.20 17.7 5.96 16.5 5.50

-7.0 -7.6 21.3 7.10 20.1 6.63 18.9 6.17 18.3 5.94 17.7 5.72 16.5 5.28

-5.0 -5.6 21.3 6.69 20.1 6.25 18.9 5.82 18.3 5.61 17.7 5.40 16.5 4.99

-3.0 -3.7 21.3 6.32 20.1 5.90 18.9 5.50 18.3 5.31 17.7 5.11 16.5 4.73

0.0 -0.7 21.3 5.77 20.1 5.40 18.9 5.04 18.3 4.86 17.7 4.69 16.5 4.35

3.0 2.2 21.3 5.29 20.1 4.96 18.9 4.64 18.3 4.48 17.7 4.32 16.5 4.01

5.0 4.1 21.3 5.00 20.1 4.69 18.9 4.39 18.3 4.24 17.7 4.10 16.5 3.81

7.0 6.0 21.3 4.74 20.1 4.45 18.9 4.16 18.3 4.03 17.7 3.89 16.5 3.62

9.0 7.9 21.3 4.49 20.1 4.22 18.9 3.95 18.3 3.82 17.7 3.69 16.5 3.44

11.0 9.8 21.3 4.25 20.1 4.00 18.9 3.75 18.3 3.63 17.7 3.51 16.5 3.27

13.0 11.8 21.3 4.03 20.1 3.79 18.9 3.56 18.3 3.45 17.7 3.33 16.5 3.11

15.0 13.7 21.3 3.83 20.1 3.61 18.9 3.39 18.3 3.28 17.7 3.18 16.5 2.97

50% (250)

-19.8 -20.0 17.8 7.91 16.8 7.37 15.8 6.85 15.2 6.59 14.7 6.34 13.7 5.84

-18.8 -19.0 17.8 7.74 16.8 7.22 15.8 6.70 15.2 6.45 14.7 6.21 13.7 5.72

-16.7 -17.0 17.8 7.39 16.8 6.90 15.8 6.41 15.2 6.17 14.7 5.94 13.7 5.48

-13.7 -15.0 17.8 7.04 16.8 6.57 15.8 6.11 15.2 5.89 14.7 5.66 13.7 5.23

-11.8 -13.0 17.8 6.68 16.8 6.24 15.8 5.81 15.2 5.60 14.7 5.39 13.7 4.98

-9.8 -11.0 17.8 6.32 16.8 5.91 15.8 5.51 15.2 5.31 14.7 5.12 13.7 4.73

-9.5 -10.0 17.8 6.15 16.8 5.75 15.8 5.36 15.2 5.17 14.7 4.98 13.7 4.61

-8.5 -9.1 17.8 6.00 16.8 5.61 15.8 5.23 15.2 5.05 14.7 4.87 13.7 4.51

-7.0 -7.6 17.8 5.75 16.8 5.38 15.8 5.02 15.2 4.85 14.7 4.67 13.7 4.33

-5.0 -5.6 17.8 5.43 16.8 5.09 15.8 4.75 15.2 4.59 14.7 4.43 13.7 4.11

-3.0 -3.7 17.8 5.14 16.8 4.82 15.8 4.51 15.2 4.35 14.7 4.20 13.7 3.90

0.0 -0.7 17.8 4.72 16.8 4.43 15.8 4.15 15.2 4.01 14.7 3.87 13.7 3.60

3.0 2.2 17.8 4.34 16.8 4.08 15.8 3.83 15.2 3.70 14.7 3.58 13.7 3.34

5.0 4.1 17.8 4.12 16.8 3.88 15.8 3.64 15.2 3.52 14.7 3.40 13.7 3.17

7.0 6.0 17.8 3.91 16.8 3.68 15.8 3.46 15.2 3.35 14.7 3.24 13.7 3.02

9.0 7.9 17.8 3.71 16.8 3.50 15.8 3.29 15.2 3.19 14.7 3.09 13.7 2.88

11.0 9.8 17.8 3.53 16.8 3.33 15.8 3.13 15.2 3.04 14.7 2.94 13.7 2.75

13.0 11.8 17.8 3.35 16.8 3.16 15.8 2.98 15.2 2.89 14.7 2.80 13.7 2.62

15.0 13.7 17.8 3.19 16.8 3.02 15.8 2.85 15.2 2.76 14.7 2.68 13.7 2.51
