• Outdoor Units • VRV HEAT RECOVERY • REYQ8-48P7Y1B
1
3
• VRV Systems • Outdoor Units
56
3 Capacity tables
3 - 3 Heating capacity tables
REYQ14P
NOTES
1 is shown as reference
When selecting the unit models, avoid the Outdoor air temperature range shown by
2 The above table shows the avarage value of conditions which may occur.
TC: Total capacity (kW); PI: Power Input (kW) (Comp.+Outdoor fan motor)
Combination
(%)
Capacity
index
Outdoor air temp.
Indoor air temp. (°CDB)
16.0 18.0 20.0 21.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI
(°CDB)(°CWB)KWKWKWKWKWKWKWKWKWKWKWKW
130% (780)
-19.8 -20.0 27.0 6.23 26.9 6.78 26.8 7.34 26.8 7.61 26.7 7.89 26.6 8.44
-18.8 -19.0 27.5 6.42 27.4 6.96 27.3 7.50 27.3 7.77 27.2 8.04 27.1 8.58
-16.7 -17.0 28.6 6.79 28.5 7.31 28.4 7.83 28.3 8.09 28.3 8.35 28.2 8.87
-13.7 -15.0 29.8 7.18 29.7 7.68 29.6 8.17 29.5 8.42 29.4 8.67 29.3 9.17
-11.8 -13.0 31.1 7.57 31.0 8.04 30.8 8.52 30.8 8.76 30.7 9.00 30.6 9.47
-9.8 -11.0 32.5 7.96 32.4 8.41 32.3 8.86 32.2 9.09 32.2 9.32 32.1 9.77
-9.5 -10.0 33.2 8.15 33.1 8.59 33.0 9.03 33.0 9.26 32.9 9.48 32.8 9.92
-8.5 -9.1 33.9 8.32 33.8 8.75 33.7 9.19 33.7 9.40 33.6 9.62 33.5 10.1
-7.0 -7.6 35.2 8.60 35.0 9.02 34.9 9.44 34.9 9.64 34.8 9.85 34.7 10.3
-5.0 -5.6 36.9 8.97 36.8 9.36 36.7 9.76 36.6 9.96 36.6 10.2 36.5 10.6
-3.0 -3.7 38.7 9.30 38.5 9.68 38.4 10.1 38.4 10.2 38.3 10.4 38.2 10.8
0.0 -0.7 41.7 9.81 41.5 10.2 41.4 10.5 41.4 10.7 41.3 10.9 41.2 11.2
3.0 2.2 44.8 10.3 44.7 10.6 44.6 10.9 44.5 11.1 44.5 11.2 44.4 11.6
5.0 4.1 47.0 10.5 46.9 10.8 46.8 11.2 46.8 11.3 46.7 11.5 46.6 11.8
7.0 6.0 49.3 10.8 49.2 11.1 49.1 11.4 49.1 11.5 49.0 11.7 48.9 12.0
9.0 7.9 51.7 11.1 51.6 11.3 51.5 11.6 51.5 11.8 51.4 11.9 51.0 12.0
11.0 9.8 54.3 11.3 54.2 11.6 54.1 11.8 54.0 12.0 54.0 12.1 51.0 11.4
13.0 11.8 57.0 11.5 56.9 11.8 56.8 12.0 56.6 12.1 54.7 11.6 51.0 10.7
15.0 13.7 59.8 11.7 59.7 12.0 58.5 11.9 56.6 11.4 54.7 11.0 51.0 10.1
120% (720)
-19.8 -20.0 26.9 6.98 26.8 7.49 26.7 7.99 26.7 8.25 26.6 8.50 26.5 9.01
-18.8 -19.0 27.4 7.15 27.3 7.65 27.2 8.14 27.1 8.39 27.1 8.64 27.0 9.14
-16.7 -17.0 28.4 7.50 28.3 7.97 28.3 8.45 28.2 8.69 28.2 8.93 28.1 9.41
-13.7 -15.0 29.6 7.85 29.5 8.31 29.4 8.77 29.4 9.00 29.3 9.23 29.2 9.69
-11.8 -13.0 30.9 8.21 30.8 8.65 30.7 9.09 30.7 9.31 30.6 9.53 30.5 9.97
-9.8 -11.0 32.3 8.57 32.2 8.99 32.1 9.41 32.1 9.62 32.0 9.83 32.0 10.2
-9.5 -10.0 33.1 8.75 33.0 9.16 32.9 9.56 32.8 9.77 32.8 9.97 32.7 10.4
-8.5 -9.1 33.8 8.91 33.7 9.31 33.6 9.70 33.5 9.90 33.5 10.1 33.4 10.5
-7.0 -7.6 35.0 9.16 34.9 9.55 34.8 9.94 34.8 10.1 34.7 10.3 34.6 10.7
-5.0 -5.6 36.8 9.50 36.7 9.87 36.6 10.2 36.5 10.4 36.5 10.6 36.4 11.0
-3.0 -3.7 38.5 9.81 38.4 10.2 38.3 10.5 38.3 10.7 38.2 10.9 38.1 11.2
0.0 -0.7 41.5 10.3 41.4 10.6 41.3 10.9 41.3 11.1 41.2 11.2 41.1 11.6
3.0 2.2 44.7 10.7 44.6 11.0 44.5 11.3 44.4 11.4 44.4 11.6 44.3 11.9
5.0 4.1 46.9 11.0 46.8 11.2 46.7 11.5 46.6 11.7 46.6 11.8 46.5 12.1
7.0 6.0 49.2 11.2 49.1 11.5 49.0 11.7 48.9 11.9 48.9 12.0 47.1 11.6
9.0 7.9 51.6 11.4 51.5 11.7 51.4 12.0 51.4 12.1 50.5 11.9 47.1 10.9
11.0 9.8 54.1 11.7 54.0 11.9 53.9 12.1 52.3 11.7 50.5 11.2 47.1 10.3
13.0 11.8 56.9 11.9 56.8 12.1 54.0 11.4 52.3 11.0 50.5 10.6 47.1 9.72
15.0 13.7 59.6 12.1 57.5 11.6 54.0 10.8 52.3 10.4 50.5 9.98 47.1 9.19
110% (660)
-19.8 -20.0 26.8 7.72 26.7 8.19 26.6 8.65 26.5 8.89 26.5 9.12 26.4 9.59
-18.8 -19.0 27.2 7.88 27.2 8.33 27.1 8.79 27.0 9.02 27.0 9.25 26.9 9.71
-16.7 -17.0 28.3 8.20 28.2 8.64 28.1 9.08 28.1 9.30 28.0 9.51 28.0 9.95
-13.7 -15.0 29.5 8.52 29.4 8.94 29.3 9.37 29.3 9.58 29.2 9.79 29.1 10.2
-11.8 -13.0 30.8 8.85 30.7 9.26 30.6 9.66 30.6 9.86 30.5 10.1 30.4 10.5
-9.8 -11.0 32.2 9.18 32.1 9.57 32.0 9.95 32.0 10.1 31.9 10.3 31.8 10.7
-9.5 -10.0 32.9 9.35 32.9 9.72 32.8 10.1 32.7 10.3 32.7 10.5 32.6 10.8
-8.5 -9.1 33.6 9.49 33.6 9.86 33.5 10.2 33.4 10.4 33.4 10.6 33.3 11.0
-7.0 -7.6 34.9 9.73 34.8 10.1 34.7 10.4 34.7 10.6 34.6 10.8 34.5 11.1
-5.0 -5.6 36.6 10.0 36.5 10.4 36.4 10.7 36.4 10.9 36.4 11.0 36.3 11.4
-3.0 -3.7 38.4 10.3 38.3 10.6 38.2 11.0 38.2 11.1 38.1 11.3 38.0 11.6
0.0 -0.7 41.4 10.8 41.3 11.0 41.2 11.3 41.2 11.5 41.1 11.6 41.0 11.9
3.0 2.2 44.5 11.1 44.4 11.4 44.4 11.7 44.3 11.8 44.3 12.0 43.1 11.8
5.0 4.1 46.7 11.4 46.6 11.6 46.6 11.9 46.5 12.0 46.3 12.1 43.1 11.1
7.0 6.0 49.0 11.6 49.0 11.8 48.9 12.1 47.9 11.9 46.3 11.4 43.1 10.5
9.0 7.9 51.5 11.8 51.4 12.0 49.5 11.6 47.9 11.2 46.3 10.7 43.1 9.87
11.0 9.8 54.0 12.0 52.7 11.8 49.5 11.0 47.9 10.5 46.3 10.1 43.1 9.32
13.0 11.8 55.9 11.9 52.7 11.1 49.5 10.3 47.9 9.92 46.3 9.54 43.1 8.79
15.0 13.7 55.9 11.2 52.7 10.5 49.5 9.74 47.9 9.38 46.3 9.02 43.1 8.32
100% (600)
-19.8 -20.0 26.6 8.47 26.5 8.89 26.5 9.31 26.4 9.53 26.4 9.74 26.3 10.2
-18.8 -19.0 27.1 8.61 27.0 9.02 26.9 9.44 26.9 9.65 26.9 9.85 26.8 10.3
-16.7 -17.0 28.2 8.90 28.1 9.30 28.0 9.70 28.0 9.90 27.9 10.1 27.8 10.5
-13.7 -15.0 29.3 9.20 29.3 9.58 29.2 9.96 29.1 10.2 29.1 10.3 29.0 10.7
-11.8 -13.0 30.6 9.50 30.6 9.86 30.5 10.2 30.4 10.4 30.4 10.6 30.3 11.0
-9.8 -11.0 32.1 9.80 32.0 10.1 31.9 10.5 31.9 10.7 31.8 10.8 31.7 11.2
-9.5 -10.0 32.8 9.94 32.7 10.3 32.6 10.6 32.6 10.8 32.6 11.0 32.5 11.3
-8.5 -9.1 33.5 10.1 33.4 10.4 33.4 10.7 33.3 10.9 33.3 11.1 33.2 11.4
-7.0 -7.6 34.7 10.3 34.7 10.6 34.6 10.9 34.5 11.1 34.5 11.3 34.4 11.6
-5.0 -5.6 36.5 10.6 36.4 10.9 36.3 11.2 36.3 11.3 36.2 11.5 36.2 11.8
-3.0 -3.7 38.2 10.8 38.2 11.1 38.1 11.4 38.0 11.6 38.0 11.7 37.9 12.0
0.0 -0.7 41.2 11.2 41.2 11.5 41.1 11.8 41.0 11.9 41.0 12.0 39.2 11.5
3.0 2.2 44.4 11.6 44.3 11.8 44.2 12.1 43.6 11.9 42.1 11.4 39.2 10.5
5.0 4.1 46.6 11.8 46.5 12.0 45.0 11.7 43.6 11.2 42.1 10.8 39.2 9.91
7.0 6.0 48.9 12.0 47.9 11.9 45.0 11.0 43.6 10.6 42.1 10.2 39.2 9.36
9.0 7.9 50.8 12.0 47.9 11.2 45.0 10.4 43.6 9.98 42.1 9.60 39.2 8.84
11.0 9.8 50.8 11.3 47.9 10.5 45.0 9.79 43.6 9.43 42.1 9.07 39.2 8.36
13.0 11.8 50.8 10.6 47.9 9.92 45.0 9.23 43.6 8.89 42.1 8.55 39.2 7.90
15.0 13.7 50.8 10.0 47.9 9.38 45.0 8.73 43.6 8.41 42.1 8.10 39.2 7.49
