Daikin REYQ14PY1B [53/137] Capacity tables

• Outdoor Units • VRV HEAT RECOVERY • REYQ8-48P7Y1B

• VRV Systems • Outdoor Units

3 Capacity tables

3 - 3 Heating capacity tables

REYQ10P

NOTES

1 is shown as reference

When selecting the unit models, avoid the Outdoor air temperature range shown by

2 The above table shows the avarage value of conditions which may occur.

TC: Total capacity (kW); PI: Power Input (kW) (Comp.+Outdoor fan motor)

Combination

(%)

Capacity

index

Outdoor air temp.

Indoor air temp. (°CDB)

16.0 18.0 20.0 21.0 22.0 24.0

TC PI TC PI TC PI TC PI TC PI TC PI

(°CDB)(°CWB)KWKWKWKWKWKWKWKWKWKWKWKW

130% (650)

-19.8 -20.0 20.6 5.42 20.6 5.79 20.5 6.16 20.5 6.35 20.4 6.53 20.4 6.90

-18.8 -19.0 21.0 5.54 20.9 5.90 20.9 6.27 20.8 6.45 20.8 6.63 20.7 6.99

-16.7 -17.0 21.8 5.79 21.7 6.14 21.6 6.49 21.6 6.66 21.6 6.84 21.5 7.19

-13.7 -15.0 22.7 6.05 22.6 6.38 22.5 6.72 22.5 6.89 22.5 7.05 22.4 7.39

-11.8 -13.0 23.7 6.31 23.6 6.63 23.5 6.95 23.5 7.11 23.4 7.27 23.4 7.59

-9.8 -11.0 24.7 6.58 24.7 6.88 24.6 7.19 24.6 7.34 24.5 7.49 24.5 7.80

-9.5 -10.0 25.3 6.71 25.3 7.01 25.2 7.31 25.1 7.46 25.1 7.60 25.0 7.90

-8.5 -9.1 25.9 6.83 25.8 7.12 25.7 7.41 25.7 7.56 25.7 7.70 25.6 8.00

-7.0 -7.6 26.8 7.02 26.7 7.30 26.7 7.58 26.6 7.73 26.6 7.87 26.5 8.15

-5.0 -5.6 28.2 7.28 28.1 7.54 28.0 7.81 28.0 7.94 28.0 8.08 27.9 8.35

-3.0 -3.7 29.5 7.51 29.5 7.77 29.4 8.02 29.4 8.15 29.3 8.27 29.3 8.53

0.0 -0.7 31.9 7.86 31.8 8.10 31.8 8.33 31.7 8.45 31.7 8.57 31.6 8.80

3.0 2.2 34.4 8.18 34.3 8.40 34.3 8.62 34.2 8.73 34.2 8.84 34.1 9.05

5.0 4.1 36.1 8.38 36.1 8.59 36.0 8.80 36.0 8.90 35.9 9.00 35.7 9.14

7.0 6.0 38.0 8.57 37.9 8.77 37.8 8.96 37.8 9.06 37.8 9.16 35.7 8.59

9.0 7.9 39.9 8.75 39.8 8.94 39.8 9.12 39.6 9.19 38.3 8.81 35.7 8.07

11.0 9.8 41.9 8.92 41.8 9.10 41.0 8.99 39.6 8.63 38.3 8.28 35.7 7.60

13.0 11.8 44.1 9.09 43.6 9.10 41.0 8.42 39.6 8.09 38.3 7.77 35.7 7.14

15.0 13.7 46.2 9.20 43.6 8.56 41.0 7.93 39.6 7.62 38.3 7.32 35.7 6.73

120% (600)

-19.8 -20.0 20.6 5.92 20.5 6.26 20.4 6.60 20.4 6.77 20.4 6.94 20.3 7.28

-18.8 -19.0 20.9 6.03 20.8 6.37 20.8 6.70 20.7 6.87 20.7 7.04 20.6 7.37

-16.7 -17.0 21.7 6.26 21.6 6.58 21.6 6.91 21.5 7.07 21.5 7.23 21.4 7.55

-13.7 -15.0 22.6 6.50 22.5 6.81 22.4 7.12 22.4 7.27 22.4 7.43 22.3 7.74

-11.8 -13.0 23.6 6.75 23.5 7.04 23.4 7.34 23.4 7.48 23.4 7.63 23.3 7.93

-9.8 -11.0 24.6 6.99 24.6 7.27 24.5 7.56 24.5 7.70 24.4 7.84 24.4 8.12

-9.5 -10.0 25.2 7.11 25.2 7.39 25.1 7.66 25.1 7.80 25.0 7.94 25.0 8.21

-8.5 -9.1 25.8 7.22 25.7 7.49 25.6 7.76 25.6 7.90 25.6 8.03 25.5 8.30

-7.0 -7.6 26.7 7.40 26.7 7.66 26.6 7.92 26.6 8.05 26.5 8.18 26.5 8.44

-5.0 -5.6 28.1 7.64 28.0 7.88 27.9 8.13 27.9 8.25 27.9 8.38 27.8 8.62

-3.0 -3.7 29.5 7.85 29.4 8.09 29.3 8.32 29.3 8.44 29.3 8.56 29.2 8.79

0.0 -0.7 31.8 8.18 31.7 8.40 31.7 8.62 31.6 8.72 31.6 8.83 31.5 9.05

3.0 2.2 34.3 8.48 34.2 8.68 34.2 8.88 34.1 8.98 34.1 9.08 32.9 8.82

5.0 4.1 36.0 8.66 36.0 8.85 35.9 9.04 35.9 9.14 35.4 9.04 32.9 8.28

7.0 6.0 37.9 8.84 37.8 9.02 37.7 9.20 36.6 8.85 35.4 8.49 32.9 7.79

9.0 7.9 39.8 9.00 39.7 9.17 37.8 8.66 36.6 8.32 35.4 7.98 32.9 7.33

11.0 9.8 41.8 9.16 40.2 8.79 37.8 8.14 36.6 7.83 35.4 7.52 32.9 6.91

13.0 11.8 42.7 8.86 40.2 8.24 37.8 7.64 36.6 7.35 35.4 7.06 32.9 6.50

15.0 13.7 42.7 8.34 40.2 7.76 37.8 7.20 36.6 6.93 35.4 6.66 32.9 6.14

110% (550)

-19.8 -20.0 20.5 6.42 20.4 6.73 20.3 7.04 20.3 7.20 20.3 7.36 20.2 7.67

-18.8 -19.0 20.8 6.52 20.7 6.83 20.7 7.14 20.7 7.29 20.6 7.44 20.6 7.75

-16.7 -17.0 21.6 6.73 21.5 7.03 21.5 7.32 21.4 7.47 21.4 7.62 21.4 7.91

-13.7 -15.0 22.5 6.95 22.4 7.24 22.4 7.52 22.3 7.66 22.3 7.80 22.2 8.09

-11.8 -13.0 23.5 7.18 23.4 7.45 23.3 7.72 23.3 7.86 23.3 7.99 23.2 8.26

-9.8 -11.0 24.6 7.40 24.5 7.66 24.4 7.92 24.4 8.05 24.4 8.18 24.3 8.44

-9.5 -10.0 25.1 7.52 25.1 7.77 25.0 8.02 25.0 8.15 24.9 8.27 24.9 8.53

-8.5 -9.1 25.7 7.62 25.6 7.86 25.6 8.11 25.5 8.23 25.5 8.36 25.4 8.60

-7.0 -7.6 26.6 7.78 26.6 8.02 26.5 8.26 26.5 8.38 26.4 8.50 26.4 8.73

-5.0 -5.6 28.0 8.00 27.9 8.22 27.9 8.45 27.8 8.56 27.8 8.68 27.7 8.90

-3.0 -3.7 29.4 8.20 29.3 8.41 29.2 8.63 29.2 8.74 29.2 8.84 29.1 9.06

0.0 -0.7 31.7 8.50 31.6 8.70 31.6 8.90 31.6 9.00 31.5 9.10 30.2 8.71

3.0 2.2 34.2 8.77 34.1 8.96 34.1 9.14 33.5 9.01 32.4 8.64 30.2 7.92

5.0 4.1 35.9 8.94 35.9 9.12 34.7 8.81 33.5 8.47 32.4 8.12 30.2 7.45

7.0 6.0 37.8 9.10 36.9 8.94 34.7 8.28 33.5 7.96 32.4 7.64 30.2 7.02

9.0 7.9 39.1 9.03 36.9 8.40 34.7 7.79 33.5 7.49 32.4 7.19 30.2 6.61

11.0 9.8 39.1 8.49 36.9 7.90 34.7 7.33 33.5 7.05 32.4 6.78 30.2 6.24

13.0 11.8 39.1 7.96 36.9 7.42 34.7 6.89 33.5 6.63 32.4 6.38 30.2 5.88

15.0 13.7 39.1 7.50 36.9 7.00 34.7 6.50 33.5 6.26 32.4 6.02 30.2 5.56

100% (500)

-19.8 -20.0 20.4 6.92 20.3 7.20 20.2 7.49 20.2 7.63 20.2 7.77 20.1 8.05

-18.8 -19.0 20.7 7.01 20.7 7.29 20.6 7.57 20.6 7.71 20.5 7.85 20.5 8.13

-16.7 -17.0 21.5 7.20 21.4 7.47 21.4 7.74 21.4 7.88 21.3 8.01 21.3 8.28

-13.7 -15.0 22.4 7.41 22.3 7.66 22.3 7.92 22.2 8.05 22.2 8.18 22.2 8.44

-11.8 -13.0 23.4 7.61 23.3 7.86 23.3 8.10 23.2 8.23 23.2 8.35 23.1 8.60

-9.8 -11.0 24.5 7.82 24.4 8.05 24.3 8.29 24.3 8.40 24.3 8.52 24.2 8.76

-9.5 -10.0 25.0 7.92 25.0 8.15 24.9 8.38 24.9 8.49 24.9 8.61 24.8 8.84

-8.5 -9.1 25.6 8.01 25.5 8.24 25.5 8.46 25.4 8.57 25.4 8.68 25.4 8.91

-7.0 -7.6 26.5 8.16 26.5 8.38 26.4 8.60 26.4 8.70 26.4 8.81 26.3 9.03

-5.0 -5.6 27.9 8.36 27.8 8.57 27.8 8.77 27.7 8.87 27.7 8.98 27.5 9.07

-3.0 -3.7 29.3 8.54 29.2 8.74 29.1 8.93 29.1 9.03 29.1 9.13 27.5 8.54

0.0 -0.7 31.6 8.82 31.6 9.00 31.5 9.18 30.5 8.81 29.5 8.45 27.5 7.75

3.0 2.2 34.1 9.07 33.5 9.01 31.5 8.34 30.5 8.02 29.5 7.70 27.5 7.07

5.0 4.1 35.5 9.10 33.5 8.46 31.5 7.84 30.5 7.54 29.5 7.24 27.5 6.66

7.0 6.0 35.5 8.55 33.5 7.95 31.5 7.38 30.5 7.10 29.5 6.82 27.5 6.28

9.0 7.9 35.5 8.03 33.5 7.48 31.5 6.95 30.5 6.69 29.5 6.43 27.5 5.93

11.0 9.8 35.5 7.56 33.5 7.05 31.5 6.55 30.5 6.31 29.5 6.07 27.5 5.60

13.0 11.8 35.5 7.10 33.5 6.63 31.5 6.17 30.5 5.94 29.5 5.72 27.5 5.28

15.0 13.7 35.5 6.70 33.5 6.26 31.5 5.83 30.5 5.62 29.5 5.41 27.5 5.00
