3 Capacity tables

3 - 3 Heating capacity tables

REYQ8P

TC: Total capacity (kW); PI: Power Input (kW) (Comp.+Outdoor fan motor)

Combination (%)

Capacity

index

Outdoor air temp.

Indoor air temp. (°CDB)

16.0 18.0 20.0 21.0 22.0 24.0

TC PI TC PI TC PI TC PI TC PI TC PI

(°CDB)(°CWB)KWKWKWKWKWKWKWKWKWKWKWKW

90% (405)

-19.8 -20.0 16.3 5.72 16.3 5.92 16.3 6.11 16.2 6.21 16.2 6.30 16.2 6.50

-18.8 -19.0 16.8 5.83 16.8 6.02 16.7 6.20 16.7 6.30 16.7 6.39 16.7 6.58

-16.7 -17.0 17.8 6.02 17.8 6.20 17.7 6.38 17.7 6.47 17.7 6.55 17.7 6.73

-13.7 -15.0 18.8 6.20 18.8 6.37 18.7 6.53 18.7 6.62 18.7 6.70 18.6 6.87

-11.8 -13.0 19.8 6.35 19.7 6.51 19.7 6.67 19.7 6.75 19.7 6.83 19.6 6.98

-9.8 -11.0 20.8 6.50 20.7 6.65 20.7 6.80 20.7 6.87 20.7 6.95 19.6 6.56

-9.5 -10.0 21.3 6.56 21.2 6.71 21.2 6.86 21.2 6.93 21.1 6.96 19.6 6.37

-8.5 -9.1 21.7 6.62 21.7 6.76 21.6 6.91 21.6 6.98 21.1 6.78 19.6 6.21

-7.0 -7.6 22.5 6.71 22.4 6.85 22.4 6.99 21.8 6.77 21.1 6.50 19.6 5.96

-5.0 -5.6 23.4 6.82 23.4 6.96 22.5 6.68 21.8 6.42 21.1 6.16 19.6 5.66

-3.0 -3.7 24.4 6.92 23.9 6.87 22.5 6.36 21.8 6.12 21.1 5.87 19.6 5.40

0.0 -0.7 25.4 6.86 23.9 6.38 22.5 5.92 21.8 5.69 21.1 5.47 19.6 5.03

3.0 2.2 25.4 6.42 23.9 5.98 22.5 5.55 21.8 5.34 21.1 5.13 19.6 4.73

5.0 4.1 25.4 6.16 23.9 5.74 22.5 5.33 21.8 5.13 21.1 4.94 19.6 4.55

7.0 6.0 25.4 5.92 23.9 5.52 22.5 5.13 21.8 4.94 21.1 4.75 19.6 4.38

9.0 7.9 25.4 5.70 23.9 5.32 22.5 4.95 21.8 4.76 21.1 4.58 19.6 4.23

11.0 9.8 25.4 5.49 23.9 5.13 22.5 4.77 21.8 4.60 21.1 4.43 19.6 4.09

13.0 11.8 25.4 5.30 23.9 4.95 22.5 4.61 21.8 4.44 21.1 4.27 19.6 3.95

15.0 13.7 25.4 5.12 23.9 4.79 22.5 4.46 21.8 4.30 21.1 4.14 19.6 3.83

80% (360)

-19.8 -20.0 16.3 6.10 16.2 6.27 16.2 6.44 16.2 6.53 16.1 6.62 16.1 6.79

-18.8 -19.0 16.7 6.19 16.7 6.36 16.7 6.53 16.7 6.61 16.6 6.69 16.6 6.86

-16.7 -17.0 17.7 6.37 17.7 6.53 17.7 6.68 17.6 6.76 17.6 6.84 17.4 6.89

-13.7 -15.0 18.7 6.52 18.7 6.67 18.7 6.82 18.6 6.90 18.6 6.97 17.4 6.44

-11.8 -13.0 19.7 6.66 19.7 6.81 19.6 6.95 19.4 6.87 18.7 6.59 17.4 6.04

-9.8 -11.0 20.7 6.79 20.7 6.93 20.0 6.72 19.4 6.46 18.7 6.20 17.4 5.69

-9.5 -10.0 21.2 6.85 21.2 6.98 20.0 6.53 19.4 6.27 18.7 6.02 17.4 5.53

-8.5 -9.1 21.6 6.90 21.3 6.87 20.0 6.36 19.4 6.12 18.7 5.87 17.4 5.40

-7.0 -7.6 22.4 6.98 21.3 6.59 20.0 6.11 19.4 5.87 18.7 5.64 17.4 5.18

-5.0 -5.6 22.6 6.71 21.3 6.24 20.0 5.79 19.4 5.57 18.7 5.35 17.4 4.93

-3.0 -3.7 22.6 6.39 21.3 5.95 20.0 5.53 19.4 5.32 18.7 5.11 17.4 4.71

0.0 -0.7 22.6 5.94 21.3 5.54 20.0 5.15 19.4 4.96 18.7 4.77 17.4 4.40

3.0 2.2 22.6 5.57 21.3 5.20 20.0 4.84 19.4 4.66 18.7 4.48 17.4 4.14

5.0 4.1 22.6 5.35 21.3 5.00 20.0 4.65 19.4 4.48 18.7 4.32 17.4 3.99

7.0 6.0 22.6 5.15 21.3 4.81 20.0 4.48 19.4 4.32 18.7 4.16 17.4 3.85

9.0 7.9 22.6 4.96 21.3 4.64 20.0 4.33 19.4 4.17 18.7 4.02 17.4 3.72

11.0 9.8 22.6 4.79 21.3 4.48 20.0 4.18 19.4 4.03 18.7 3.89 17.4 3.60

13.0 11.8 22.6 4.62 21.3 4.33 20.0 4.04 19.4 3.90 18.7 3.76 17.4 3.48

15.0 13.7 22.6 4.47 21.3 4.19 20.0 3.91 19.4 3.78 18.7 3.64 17.4 3.37

70% (315)

-19.8 -20.0 16.2 6.48 16.1 6.63 16.1 6.78 16.1 6.85 16.1 6.93 15.3 6.53

-18.8 -19.0 16.7 6.56 16.6 6.71 16.6 6.85 16.6 6.93 16.4 6.86 15.3 6.29

-16.7 -17.0 17.7 6.71 17.6 6.85 17.5 6.93 16.9 6.65 16.4 6.39 15.3 5.86

-13.7 -15.0 18.6 6.85 18.6 6.98 17.5 6.47 16.9 6.22 16.4 5.97 15.3 5.48

-11.8 -13.0 19.6 6.97 18.6 6.55 17.5 6.07 16.9 5.84 16.4 5.61 15.3 5.16

-9.8 -11.0 19.8 6.62 18.6 6.16 17.5 5.72 16.9 5.50 16.4 5.29 15.3 4.87

-9.5 -10.0 19.8 6.43 18.6 5.99 17.5 5.56 16.9 5.35 16.4 5.14 15.3 4.74

-8.5 -9.1 19.8 6.27 18.6 5.84 17.5 5.42 16.9 5.22 16.4 5.02 15.3 4.62

-7.0 -7.6 19.8 6.01 18.6 5.61 17.5 5.21 16.9 5.02 16.4 4.82 15.3 4.45

-5.0 -5.6 19.8 5.71 18.6 5.32 17.5 4.95 16.9 4.77 16.4 4.59 15.3 4.24

-3.0 -3.7 19.8 5.44 18.6 5.08 17.5 4.73 16.9 4.56 16.4 4.39 15.3 4.05

0.0 -0.7 19.8 5.08 18.6 4.74 17.5 4.42 16.9 4.26 16.4 4.10 15.3 3.80

3.0 2.2 19.8 4.77 18.6 4.46 17.5 4.16 16.9 4.01 16.4 3.87 15.3 3.58

5.0 4.1 19.8 4.59 18.6 4.29 17.5 4.01 16.9 3.87 16.4 3.73 15.3 3.45

7.0 6.0 19.8 4.42 18.6 4.14 17.5 3.87 16.9 3.73 16.4 3.60 15.3 3.34

9.0 7.9 19.8 4.26 18.6 4.00 17.5 3.73 16.9 3.61 16.4 3.48 15.3 3.23

11.0 9.8 19.8 4.12 18.6 3.86 17.5 3.61 16.9 3.49 16.4 3.37 15.3 3.13

13.0 11.8 19.8 3.98 18.6 3.74 17.5 3.49 16.9 3.38 16.4 3.26 15.3 3.03

15.0 13.7 19.8 3.86 18.6 3.62 17.5 3.39 16.9 3.28 16.4 3.16 15.3 2.94

60% (270)

-19.8 -20.0 16.1 6.85 16.0 6.91 15.0 6.40 14.5 6.15 14.0 5.90 13.1 5.42

-18.8 -19.0 16.6 6.93 16.0 6.65 15.0 6.16 14.5 5.93 14.0 5.69 13.1 5.23

-16.7 -17.0 16.9 6.65 16.0 6.19 15.0 5.74 14.5 5.52 14.0 5.31 13.1 4.89

-13.7 -15.0 16.9 6.21 16.0 5.79 15.0 5.38 14.5 5.18 14.0 4.98 13.1 4.59

-11.8 -13.0 16.9 5.83 16.0 5.44 15.0 5.06 14.5 4.87 14.0 4.69 13.1 4.32

-9.8 -11.0 16.9 5.50 16.0 5.13 15.0 4.78 14.5 4.60 14.0 4.43 13.1 4.09

-9.5 -10.0 16.9 5.35 16.0 4.99 15.0 4.65 14.5 4.48 14.0 4.31 13.1 3.98

-8.5 -9.1 16.9 5.21 16.0 4.87 15.0 4.54 14.5 4.37 14.0 4.21 13.1 3.89

-7.0 -7.6 16.9 5.01 16.0 4.68 15.0 4.37 14.5 4.21 14.0 4.05 13.1 3.75

-5.0 -5.6 16.9 4.77 16.0 4.46 15.0 4.16 14.5 4.01 14.0 3.86 13.1 3.58

-3.0 -3.7 16.9 4.55 16.0 4.26 15.0 3.98 14.5 3.84 14.0 3.70 13.1 3.43

0.0 -0.7 16.9 4.26 16.0 3.99 15.0 3.73 14.5 3.60 14.0 3.47 13.1 3.22

3.0 2.2 16.9 4.01 16.0 3.76 15.0 3.52 14.5 3.40 14.0 3.28 13.1 3.05

5.0 4.1 16.9 3.86 16.0 3.63 15.0 3.39 14.5 3.28 14.0 3.17 13.1 2.94

7.0 6.0 16.9 3.73 16.0 3.50 15.0 3.28 14.5 3.17 14.0 3.06 13.1 2.85

9.0 7.9 16.9 3.60 16.0 3.39 15.0 3.17 14.5 3.07 14.0 2.96 13.1 2.76

11.0 9.8 16.9 3.49 16.0 3.28 15.0 3.07 14.5 2.97 14.0 2.87 13.1 2.68

13.0 11.8 16.9 3.37 16.0 3.17 15.0 2.98 14.5 2.88 14.0 2.78 13.1 2.59

15.0 13.7 16.9 3.27 16.0 3.08 15.0 2.89 14.5 2.80 14.0 2.71 13.1 2.52

50% (225)

-19.8 -20.0 14.1 5.94 13.3 5.54 12.5 5.15 12.1 4.96 11.7 4.77 10.9 4.40

-18.8 -19.0 14.1 5.72 13.3 5.34 12.5 4.97 12.1 4.78 11.7 4.60 10.9 4.25

-16.7 -17.0 14.1 5.34 13.3 4.99 12.5 4.64 12.1 4.47 11.7 4.31 10.9 3.98

-13.7 -15.0 14.1 5.01 13.3 4.68 12.5 4.36 12.1 4.20 11.7 4.05 10.9 3.75

-11.8 -13.0 14.1 4.71 13.3 4.41 12.5 4.11 12.1 3.97 11.7 3.82 10.9 3.54

-9.8 -11.0 14.1 4.45 13.3 4.17 12.5 3.89 12.1 3.76 11.7 3.62 10.9 3.36

-9.5 -10.0 14.1 4.33 13.3 4.06 12.5 3.79 12.1 3.66 11.7 3.53 10.9 3.28

-8.5 -9.1 14.1 4.23 13.3 3.97 12.5 3.71 12.1 3.58 11.7 3.45 10.9 3.20

-7.0 -7.6 14.1 4.08 13.3 3.82 12.5 3.57 12.1 3.45 11.7 3.33 10.9 3.09

-5.0 -5.6 14.1 3.89 13.3 3.65 12.5 3.41 12.1 3.30 11.7 3.18 10.9 2.96

-3.0 -3.7 14.1 3.72 13.3 3.49 12.5 3.27 12.1 3.16 11.7 3.05 10.9 2.84

0.0 -0.7 14.1 3.49 13.3 3.28 12.5 3.08 12.1 2.98 11.7 2.87 10.9 2.68

3.0 2.2 14.1 3.30 13.3 3.10 12.5 2.91 12.1 2.82 11.7 2.72 10.9 2.54

5.0 4.1 14.1 3.18 13.3 3.00 12.5 2.81 12.1 2.72 11.7 2.63 10.9 2.46

7.0 6.0 14.1 3.08 13.3 2.90 12.5 2.72 12.1 2.64 11.7 2.55 10.9 2.38

9.0 7.9 14.1 2.98 13.3 2.81 12.5 2.64 12.1 2.56 11.7 2.47 10.9 2.31

11.0 9.8 14.1 2.89 13.3 2.72 12.5 2.56 12.1 2.48 11.7 2.40 10.9 2.25

13.0 11.8 14.1 2.80 13.3 2.64 12.5 2.48 12.1 2.41 11.7 2.33 10.9 2.18

15.0 13.7 14.1 2.72 13.3 2.57 12.5 2.42 12.1 2.34 11.7 2.27 10.9 2.12
