Special Control Si37-701
112 Function
3.1.2 Startup Control in Heating Operation
Actuator Symbol
Elect.
symbol
Control
before
startup
Startup control
STEP1 STEP2
Compressor 1
—
M1C
0 Hz 52 Hz+OFF+OFF
52Hz+OFF+OFF+2STEP /
20 sec.
(Until it reaches
Pc-Pe>0.39 MPa)
Compressor 2 M2C
Compressor 3 M3C
Outdoor unit fan 1
—
M1F
STEP4
20SA=ON: STEP7
20SA=OFF
+1step/15 sec. (When
Pc_max>2.16 MPa)
-1step/15 sec. (When
Pc_max<1.77 MPa)
20SA=ON: STEP7
20SA=OFF
+1step/15 sec. (When
Pc_max>2.16 MPa)
-1step/15 sec. (When
Pc_max<1.77 MPa)
Outdoor unit fan 2 M2F
Electronic expansion
valve (Main)
EVM
Y1E
Y3E
0 pls
20SA=ON: SH Control
20SA=OFF: 1375 pls
20SA=ON: SH Control
20SA=OFF: 1375 pls
Electronic expansion
valve (Supercooling)
EVT
Y2E
Y5E
0 pls 0 pls 0 pls
Electronic expansion
valve (Refrigerant
charge)
EVJ Y4E 80 pls 80 pls 80 pls
Four way valve
(Heat exchanger switch)
20SA
Y2S
Y9S
When
outdoor
heat
exchanger
is
evaporator
: ON
When
outdoor
heat
exchanger
is
condenser
: OFF
When outdoor heat
exchanger is evaporator:
ON
When outdoor heat
exchanger is condenser:
OFF
When outdoor heat
exchanger is evaporator:
ON
When outdoor heat
exchanger is condenser:
OFF
Four way valve (High/
low pressure gas pipe
switch)
20SB Y8S OFF OFF OFF
Solenoid valve (Main
bypass)
SVE
Y5S
Y10S
OFF OFF OFF
Solenoid valve (Hot gas) SVP Y4S OFF OFF OFF
Solenoid valve
(Refrigerant regulator
liquid pipe )
SVL Y3S OFF OFF OFF
Solenoid valve
(Refrigerant regulator
gas vent pipe)
SVG Y1S OFF OFF OFF
Solenoid valve
(Refrigerant regulator
exhaust pipe)
SVO Y7S OFF OFF OFF
Solenoid valve
(Refrigerant regulator
discharge pipe)
SVT Y6S OFF OFF OFF
Ending conditions
A lapse
of 60
sec.
A lapse of 15 sec.
•
A lapse of 90 sec.
• Pc - Pe>0.39 MPa
OR
