Si37-701 Specifications
Specifications 33
Ceiling Concealed (Duct) Type (Australia exclusive use)
Notes:
★
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp; 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
★
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp; 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
★
3 Indoor temp. : 20°CDB / outdoor temp.: 7°CDB, 6°CWB / Equivalent piping length; 7.5m, level difference;
0m. (Heat pump only)
4 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
★
5 External static pressure is changeable to set by the remote controller this pressure means “High static
pressure - Standard static pressure”.
★
6 Air filter is not a standard accessory. A suitable field supplied filter must be installed in the return air duct.
★
7 The operation sound levels are the conversion values in anechoic chamber. In practice, the sound tend to
be larger than the specified values due to ambient noise or reflections.
When the place of suction is changed to the bottom suction, the sound level will increase by approx.
5dBA.
Model FXDYQ80MV1 FXDYQ100MV1 FXDYQ125MV1 FXDYQ145MV1
★
1 Cooling Capacity (19.5°CWB)
kcal/h 8,000 10,000 12,500 14,500
Btu/h 31,700 39,600 49,500 57,700
kW 9.3 11.6 14.5 16.9
★
2 Cooling Capacity (19.0°CWB) kW 9.0 11.2 14.0 16.2
★
3 Heating Capacity
kcal/h 8,600 10,800 13,800 15,900
Btu/h 34,100 42,700 54,600 63,100
kW 10.0 12.5 16.0 18.5
Casing Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) mm 360×1,168×869 360×1,478×899 360×1,478×899 360×1,478×899
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 2×18×1.5 2×18×1.5 3×18×1.5 3×18×1.5
Face Area m² 0.284 0.435 0.435 0.435
Fan
Type Twin Sirocco Fan Twin Sirocco Fan Twin Sirocco Fan Twin Sirocco Fan
Motor Output W 290 490 490 655
Air Flow Rate
l/s 590 815 925 1070
cfm 1250 1726 1959 2266
External Static Pressure Pa 130
★
5 130
★
5 100
★
5 130
★
5
Drive Direct Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Sound Absorbing Thermal Insulation Material Foamed Polyethylene Foamed Polyethylene Foamed Polyethylene Foamed Polyethylene
★
6 Air Filter ————
Piping
Connections
Liquid Pipes mm
φ
9.5 (Flare Connection)
φ
9.5 (Flare Connection)
φ
9.5 (Flare Connection)
φ
9.5 (Flare Connection)
Gas Pipes mm
φ
15.9 (Flare Connection)
φ
15.9 (Flare Connection)
φ
15.9 (Flare Connection)
φ
15.9 (Flare Connection)
Drain Pipe mm
VP25
(External Dia. 32 Internal Dia. 25)
VP25
(External Dia. 32 Internal Dia. 25)
VP25
(External Dia. 32 Internal Dia. 25)
VP25
(External Dia. 32 Internal Dia. 25)
Mass (Weight) kg 52 61 65 66
★
7 Sound Level (240V) dBA 45 46 48 51
Safety Devices
Fuse for PCB,
Fuse for Fan Motor,
Thermal Protector for Fan Motor
Fuse for PCB,
Fuse for Fan Motor,
Thermal Protector for Fan Motor
Fuse for PCB,
Fuse for Fan Motor,
Thermal Protector for Fan Motor
Fuse for PCB,
Fuse for Fan Motor,
Thermal Protector for Fan Motor
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Standard Accessories
Operation Manual,
Installation Manual,
Drain Hose, Hose, Clamps
Operation Manual,
Installation Manual,
Drain Hose, Hose, Clamps
Operation Manual,
Installation Manual,
Drain Hose, Hose, Clamps
Operation Manual,
Installation Manual,
Drain Hose, Hose, Clamps
Drawing No. 4PDA0355
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
