Option List Si37-701
398 Appendix
4.2 Option Lists (Outdoor Unit)
REYQ8 ~ 16PY1(E)
C : 3D057610A
REYQ18 ~ 32PY1(E)
C : 3D057611C
REYQ34 ~ 48PY1(E)
C : 3D057612C
Note)
:
Order products
Series
Models
Optional accessories
VRV III H/R
REYQ8PY1 REYQ8PY1
E
REYQ10PY1
REYQ12PY1
REYQ14PY1
REYQ16PY1
REYQ10PY1E
REYQ12PY1E
REYQ14PY1E
REYQ16PY1E
Distributive
Piping
Refnet header Model
KHRP25M33H
(Max. 8 branch)
KHRP25M33H, KHRP25M72H
(Max. 8 branch) (Max. 8 branch)
Refnet joint Model KHRP25A22T, KHRP25A33T
KHRP25A22T, KHRP25A33T
(KHRP25A72T+KHRP25M72TP)
Central drain pan kit Model KWC25C450
KWC25C450E
KWC25C450
KWC25C450E
Digital pressure gauge kit Model BHGP26A1 BHGP26A1E BHGP26A1 BHGP26A1E
Series
Models
Optional accessories
VRV III H/R
REYQ18PY1 REYQ18PY1
E
REYQ20PY1
REYQ22PY1
REYQ24PY1
REYQ20PY1E
REYQ22PY1E
REYQ24PY1E
Distributive
Piping
Refnet header Model
KHRP25M33H, KHRP25M72H
(Max. 8 branch) (Max. 8 branch)
KHRP25M33H, KHRP25M72H, KHRP25M73H
(Max. 8 branch) (Max. 8 branch) (Max. 8 branch)
Refnet joint Model
KHRP25A22T, KHRP25A33T
(KHRP25A72T+KHRP25M72TP)
KHRP25A22T, KHRP25A33T, (KHRP25A72T+
KHRP25M72TP), (KHRP25A73T+KHRP25M73TP)
Outdoor unit multi connection piping kit Model BHFP26P90
Central drain pan kit Model KWC26C280×2
KWC26C280E×2
KWC26C280×2
KWC26C280E×2
Digital pressure gauge kit Model BHGP26A1 BHGP26A1E BHGP26A1 BHGP26A1E
Series
Models
Optional accessories
VRV III H/R
REYQ26PY1
REYQ28PY1
REYQ26PY1E
REYQ28PY1E
REYQ30PY1
REYQ32PY1
REYQ30PY1E
REYQ32PY1E
Distributive
Piping
Refnet header Model
KHRP25M33H, KHRP25M72H, KHRP25M73H
(Max. 8 branch) (Max. 8 branch) (Max. 8 branch)
Refnet joint Model KHRP25A22T, KHRP25A33T, (KHRP25A72T+KHRP25M72TP), (KHRP25A73T+KHRP25M73TP)
Outdoor unit multi connection piping kit Model BHFP26P90
Central drain pan kit Model
KWC26C280
KWC26C450
KWC26C280
E
KWC26C450
E
KWC26C450×2
KWC26C450E×2
Digital pressure gauge kit Model BHGP26A1 BHGP26A1E BHGP26A1 BHGP26A1E
Series
Models
Optional accessories
VRV III H/R
REYQ34PY1
REYQ36PY1
REYQ38PY1
REYQ40PY1
REYQ34PY1E
REYQ36PY1E
REYQ38PY1E
REYQ40PY1E
REYQ42PY1
REYQ44PY1
Distributive
Piping
Refnet header Model
KHRP25M33H, KHRP25M72H, KHRP25M73H
(Max. 8 branch) (Max. 8 branch) (Max. 8 branch)
Refnet joint Model
KHRP25A22T, KHRP25A33T, (KHRP25A72T+
KHRP25M72TP), (KHRP25A73T+KHRP25M73TP)
Outdoor unit multi connection piping kit Model BHFP26P136
Central drain pan kit Model
KWC26C280×2
KWC26C450
KWC26C280E×2
KWC26C450E
KWC26C280
KWC26C450×2
Digital pressure gauge kit Model BHGP26A1 BHGP26A1E BHGP26A1
Series
Models
Optional accessories
VRV III H/R
REYQ42PY1E
REYQ44PY1E
REYQ46PY1
REYQ48PY1
REYQ46PY1E
REYQ48PY1E
Distributive
Piping
Refnet header Model
KHRP25M33H, KHRP25M72H, KHRP25M73H
(Max. 8 branch) (Max. 8 branch) (Max. 8 branch)
Refnet joint Model
KHRP25A22T, KHRP25A33T, (KHRP25A72T+
KHRP25M72TP), (KHRP25A73T+KHRP25M73TP)
Outdoor unit multi connection piping kit Model BHFP26P136
Central drain pan kit Model
KWC26C280E
KWC26C450E×2
KWC26C450×3
KWC26C450×3
Digital pressure gauge kit Model BHGP26A1E BHGP26A1 BHGP26A1E
