Specifications Si37-701
34 Specifications
Notes:
★
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp; 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
★
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp; 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
★
3 Indoor temp. : 20°CDB / outdoor temp.: 7°CDB, 6°CWB / Equivalent piping length; 7.5m, level difference;
0m. (Heat pump only)
4 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
★
5 External static pressure is changeable to set by the remote controller this pressure means “High static
pressure - Standard static pressure”.
★
6 Air filter is not a standard accessory. A suitable field supplied filter must be installed in the return air duct.
★
7 The operation sound levels are the conversion values in anechoic chamber. In practice, the sound tend to
be larger than the specified values due to ambient noise or reflections.
When the place of suction is changed to the bottom suction, the sound level will increase by approx.
5dBA.
Model FXDYQ180MV1 FXDYQ200MV1 FXDYQ250MV1
★
1 Cooling Capacity (19.5°CWB)
kcal/h 17,700 19,800 24,800
Btu/h 70,300 78,500 98,300
kW 20.6 23.0 28.8
★
2 Cooling Capacity (19.0°CWB) kW 20.0 22.4 28.0
★
3 Heating Capacity
kcal/h 19,300 21,500 27,000
Btu/h 76,400 85,300 107,500
kW 22.4 25.0 31.5
Casing Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) mm 500×1,210×910 500×1,210×910 500×1,410×910
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 2×22×2.0 3×22×2.0 3×22×2.0
Face Area m² 0.443 0.443 0.54
Fan
Type Twin Sirocco Fan Twin Sirocco Fan Twin Sirocco Fan
Motor Output W 700 750 1,100
Air Flow Rate
l/s 1,180 1,200 1,400
cfm 2500 2542 2965
External Static Pressure Pa 150
★
5 180
★
5200
★
5
Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Sound Absorbing Thermal Insulation Material Foamed Polyethylene Foamed Polyethylene Foamed Polyethylene
★
6 Air Filter — — —
Piping
Connections
Liquid Pipes mm
φ
9.5 (Brazing Connection)
φ
9.5 (Brazing Connection)
φ
9.5 (Brazing Connection)
Gas Pipes mm
φ
19.1 (Brazing Connection)
φ
19.1 (Brazing Connection)
φ
22.2 (Brazing Connection)
Drain Pipe mm BSP 3/4 inch internal thread BSP 3/4 inch internal thread BSP 3/4 inch internal thread
Mass (Weight) kg 77 79 98
★
7 Sound Level (240V) dBA 51 51 51
Safety Devices
Fuse for PCB,
Fuse for Fan Motor,
Thermal Protector for Fan Motor
Fuse for PCB,
Fuse for Fan Motor,
Thermal Protector for Fan Motor
Fuse for PCB,
Fuse for Fan Motor,
Thermal Protector for Fan Motor
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Standard Accessories
Operation Manual,
Installation Manual,
Drain Hose, Hose, Clamps
Operation Manual,
Installation Manual,
Drain Hose, Hose, Clamps
Operation Manual,
Installation Manual,
Drain Hose, Hose, Clamps
Drawing No. —
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
