Special Control Si37-701
122 Function
3.6 Standby
3.6.1 Restart Standby
Used to forcedly stop the compressor for a period of 2 minutes, in order to prevent the frequent ON/OFF of the
compressor and equalize the pressure within the refrigerant system.
3.6.2 Crankcase Heater Control
In order to prevent the refrigerant from melting in the compressor oil in the stopped mode, this mode is used to control
the crankcase heater.
Actuator Symbol
Elect.
symbol
Operation
REYQ8~16P REMQ8P REMQ10•12P REMQ14•16P
Compressor1 — M1C OFF OFF OFF OFF
Compressor2 — M2C OFF — OFF OFF
Compressor3 — M3C — — — OFF
Outdoor unit fan1 — MF1
Ta>30
°
C: STEP4
Ta≤30°C: OFF
Ta>30
°
C: STEP4
Ta≤30°C: OFF
Ta>30
°
C: STEP4
Ta≤30°C: OFF
Ta>30
°
C: STEP4
Ta≤30°C: OFF
Outdoor unit fan2 — MF2
Ta>30
°
C: STEP4
Ta≤30°C: OFF
——
Ta>30
°
C: STEP4
Ta≤30°C: OFF
Electronic expansion valve
(Main)
EVM
Y1E
Y3E
0 pls
Electronic expansion valve
(Supercooling)
EVT
Y2E
Y5E
0 pls
Electronic expansion valve
(Refrigerant charge)
EVJ Y4E 80 pls
Four way valve (Heat
exchanger switch)
20SA
Y2S
Y9S
Holds
Four way valve (High/low
pressure gas pipe switch)
20SB Y8S Holds
Solenoid valve (Main bypass)
SVE
Y5S
Y10S
OFF
Solenoid valve (Hot gas) SVP Y4S OFF
Solenoid valve (Refrigerant
regulator liquid pipe )
SVL Y3S OFF
Solenoid valve (Refrigerant
regulator gas vent pipe)
SVG Y1S OFF
Solenoid valve (Refrigerant
regulator exhaust pipe)
SVO Y7S OFF
Solenoid valve (Refrigerant
regulator discharge pipe)
SVT Y6S OFF
Ending conditions — 2 min.
Crankcase heater
OFF
Crankcase heater
ON
Discharge pipe
temperature < 70
˚C
Discharge pipe
temperature > 75
˚C
