Si37-701 Troubleshooting by Remote Controller
Troubleshooting 225
Outdoor Unit LA 999Malfunction of power unit —
LC 999Malfunction of transmission between inverter and
control PC board
290
P1 999Inverter over-ripple protection 293
P4 999Malfunction of inverter radiating fin temperature rise
sensor
294
PJ 999Faulty field setting after replacing main PC board or
faulty combination of PC board
296
System U0 879Gas shortage alert 297
U1 999Reverse phase / open phase 299
U2 999Power supply insufficient or instantaneous failure 300
U3 999Check operation is not completed. 303
U4 999Malfunction of transmission between indoor and
outdoor units
304
U5 999Malfunction of transmission between remote
controller and indoor unit
307
U5 787Failure of remote controller PC board or setting
during control by remote controller
307
U7 999Malfunction of transmission between outdoor units 308
U8 997Malfunction of transmission between main and sub
remote controllers (malfunction of sub remote controller)
314
U9 999Malfunction of transmission between indoor unit and
outdoor unit in the same system
315
UA 999Improper combination of indoor and outdoor units,
indoor units and remote controller
316
UC 888Address duplication of central remote controller 319
UE 999Malfunction of transmission between central remote
controller and indoor unit
320
UF 999Refrigerant system not set, incompatible wiring /
piping
323
UH 999Malfunction of system, refrigerant system address
undefined
324
Central
Remote
Controller
and
Schedule
Timer
M1 8 or 79 9Central remote controller PC board defect
Schedule timer PC board defect
326
M8 8 or 79 9Malfunction of transmission between optional
controllers for centralized control
327
MA 8 or 79 9Improper combination of optional controllers for
centralized control
328
MC 8 or 79 9Address duplication, improper setting 330
Heat
Reclaim
Ventilation
64 879Indoor unit’s air thermistor error —
65 879Outside air thermistor error —
6A 879Damper system alarm —
6A 999Damper system + thermistor error —
6F 879Malfunction of simple remote controller —
6H 879Malfunction of door switch or connector —
94 999Internal transmission error —
8: ON 7: OFF 9: Blink
Malfunction
code
Operation
lamp
Inspection
display
Unit No. Malfunction contents Page
Referred
The system operates for malfunction codes indicated in black squares, however, be sure to check and repair.
