Test Operation Si37-701
150 Test Operation
Correction amount with indoor unit Correction amount with a total capacity of indoor units
•
If there is a refrigerant shortage, charge a liquid refrigerant through the stop valve service
port with the stop valves of liquid and those of gas closes after the completion of vacuum
drying.
•
If the refrigerant charging is still insufficient, "turn ON the power supply" following the
information on the next page.
System name
Correction
amount
Ratio of total capacity of the
connected indoor units to the
rated capacity of the outdoor
unit (A)
Correction amount
Model REYQ8-16PY1 3.6 kg
Model REYQ18-20PY1 1.0kg Model
REYQ18 -
32PY1
Model
REYQ34 -
48PY1
Model REYQ22-24PY1 1.5kg
+
Model REYQ26PY1 2.0kg
+
Model REYQ28-30PY1 2.5kg 100%<A
≤
120
%
0.5kg
Model REYQ32-40PY1 3.0kg 120%<A
≤
130
%
0.5kg 1.0kg
Model REYQ42PY1 3.5kg
Model REYQ44-46PY1 4.0kg
Model REYQ48PY1 4.5kg
Check the stop valves for
conditions.
Has the additional refrigerant charging amount been
recorded on the "Precautions for servicing" label?
Check to be sure the stop valves are under the following
conditions.
Liquid-pipe
stop valve
Open Open Open
Suction pipe
stop valve
Open
Equalizing pipe
stop valve
Dual pressure gas
pipe stop valve
