Troubleshooting by Remote Controller Si37-701
228 Troubleshooting
<Selection of setting item>
<Monitor mode>
<Confirmation of malfunction 1>
To enter the monitor mode, push the
MODE (BS1) button when in
“Setting mode 1”.
Push the SET (BS2) button and set
the LED display to a setting item.
Push the RETURN (BS3) button
once to display "First digit" of
malfunction code.
<Confirmation of malfunction 2>
Push the SET (BS2) button once to
display "Second digit" of malfunction
code.
Push the RETURN (BS3) button and
switches to the initial status of
“Monitor mode”.
∗ Push the MODE (BS1) button and
returns to “Setting mode 1”.
<Confirmation of malfunction 3>
Push the SET (BS2) button once to
display "malfunction location".
* Refer Page 196 for Monitor mode.
* Refer Page 196 for Monitor mode.
Detail
description
on next
page.
<Confirmation of malfunction 4>
Push the SET (BS2) button once to
display "master or slave 1 or slave 2"
and "malfunction location".
Malfunctions Malfunction
code
Description of malfunction Description of malfunction (PGF) Remote
controller
INV PC board malfunction Faulty IPM
Current sensor failure confirmation 1
Current sensor failure confirmation 2
IGBT malfunction
L1
Rise in INV radiation fin temperature Overheat of INV radiation fin
temperature
L4
DC output overcurrent Instantaneous overcurrent of INV L5
IGBT malfunction
Electronic thermal Electronic thermal 1 L8
Electronic thermal 2
Loss of synchronization
Speed degradation after startup
Thunder detected
Stall prevention (time limit) Stall prevention (increased current) L9
Stall prevention (startup failure)
Abnormal starting waveform
Loss of synchronization
INV transmission malfunction INV transmission data malfunction LC
INV transmission malfunction
Open phase and unbalanced power
supply
Unbalanced INV power supply voltage P1
INV radiation fin temperature sensor
malfunction
INV fin thermistor malfunction P4
Faulty combination of INV and fan
driver
Faulty combination of INV PJ
Out of gas Out-of-gas alarm U0
Reversed phase Reversed phase malfunction U1
Reversed phase malfunction (ON)
Abnormal power supply voltage Insufficient INV voltage U2
INV open phase (single phase)
Abnormal charge of capacitor of INV
main circuit
Test run not carried out yet Test run not carried out yet U3
Faulty transmission between indoor
and outdoor units
IN-OUT transmission malfunction U4
System malfunction
Faulty transmission between outdoor
units
Malfunction caused when mounting
the external control adapter
U7
Alarm given when mounting the
external control adapter
Malfunction caused between the
master and the slave 1
Malfunction caused between the
master and the slave 2
Multi REYP models connected
Faulty address setting of slaves 1 and 2
4 or more outdoor units connected in
the same system
Erroneous address of slaves 1 and 2
Faulty transmission with other
systems
Other system or other unit in the same
system
U9
Excess indoor units connected
Faulty field setting Erroneous refrigerant used for indoor
unit
UA
Faulty combination of outdoor units
Faulty independent installation
Faulty connection of former BS unit
Faulty connection between outdoor
and BS unit
Faulty connection between BS units
Wrong number of indoor units
connected to BS unit
Faulty system line Wrong wiring (auto address error) UH
Faulty transmission with accessory
equipment
Multi level converter malfunction UJ
Multi level converter alarm
Unmatched wiring/piping, no system
settings
Multi level converter data malfunction UF
Multi level converter transmission
malfunction
8
: ON
9
: Blink
1
: OFF
