Si37-701 Troubleshooting by Indication on the Remote Controller
Troubleshooting 289
Troubleshooting
Continued from the previous page.
(Start failure due to aged operation.)
Refrigerant
is sleeping. ( The unit is out
of power supply for more
than 6 hours.)
Check if the
insulation resistance of the
compressor is 100kΩ
or over.
Broken inside
the compressor
Cancel the sleeping state of
refrigerant.
Replace the inverter compressor.
Replace the inverter compressor.
Replace the compressor inverter
PC board (A2P).
Recheck the compressor/
refrigerant circuit.
NO
NO
NO
YES
NO
YES
YES
YES
Check 4
Check if the power
transistor is
normal.
∗
Check 4
: Referring to the information on P339.
∗
