Si37-701 Troubleshooting by Indication on the Remote Controller
Troubleshooting 291
Troubleshooting
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
Power ON
FAN1 FAN2
REYQ8P
PC0511-1
-
REYQ10P
PC0511-1
-
REYQ12P
PC0511-3
PC0511-4
REYQ16P
PC0511-3
PC0511-4
Power OFF
<REYQ8/10/12P>
<REYQ14/16P>
<Multi>
REYQ18P
PC0511-1
PC0511-2
YES
YES
YES
NO
NO
NO
NO
NO
NO
NO
YES
YES
Check
whether or not
the power supply voltage
between L2 and N falls in
the range of 220 to
240VAC?
Is the type
(PC No.) of the fan
inverter correct?
The insulation
resistance is low (i.e., not
more than
100kΩ.)
The insulation
resistance is low (i.e., not
more than
1MΩ.)
Disconnect the cable from the
compressor, and then check
the compressor for the
insulation resistance.
Disconnect the cable from the
fan, and then check the fan
motor for the insulation
resistance.
Check for connector connections: Remove and insert the
connectors shown below.
[Fan 1] [Fan 2]
• A1P X28A ⇔ X6A A5P • A6P X51A ⇔ X5A A7P
• A1P X20A ⇔ X15A A2P • A6P X4A ⇔ X3A A7P
• A5P X61A ⇔ X402A A4P • A7P X4A Short connector
• A5P X1A ⇔ X403A A4P
• A5P X5A ⇔ X5A A6P
• A5P X41A ⇔ X3A A6P
• A7P X4A Short connector
Check for connector connections: Remove and insert the
connectors shown below.
[Fan 1] [Fan 2]
• A1P X28A ⇔ X6A A5P • A3P X28A ⇔ X6A A8P
• A1P X20A ⇔ X15A A2P • A3P X20A ⇔ X4A A8P
• A5P X61A ⇔ X402A A4P • A8P X61A ⇔ X402A A7P
• A5P X1A ⇔ X403A A4P • A8P X1A ⇔ X403A A7P
• A5P X5A ⇔ X5A A6P • A8P X5A ⇔ X5A A9P
• A5P X41A ⇔ X3A A6P • A8P X41A ⇔ X3A A9P
• A7P X4A Short connector • A9P X4A Short connector
Note) X3A: black
X4A: yellow
Check for connector connections: Remove and insert the
connectors shown below.
[Fan 1] [Fan 2]
• A1P X28A ⇔ X6A A4P • A5P X51A ⇔ X5A A7P
• A1P X20A ⇔ X15A A2P • A5P X4A ⇔ X3A A7P
• A4P X61A ⇔ X402A A3P • A7P X4A Short connector
• A4P X1A ⇔ X403A A3P
• A4P X5A ⇔ X5A A5P
• A4P X41A ⇔ X3A A5P
• A5P X4A Short connector
On-site cause.
Correct the wiring.
Mount the correct type
of fan inverter.
Replace the
compressor.
Replace the fan motor.
Replace the fan driver
PC board.
Are the fan
transmission wire
connectors (X3A: Black,
X4A: Yellow) wrongly
connected?
Connect the connectors
to the corresponding
color (black or yellow).
