Daikin REYQ34PY1 [237/438] Malfunction code indication by outdoor unit pc board
![Daikin REYQ34PY1 [237/438] Malfunction code indication by outdoor unit pc board](/views2/1717837/page237/bged.png)
Troubleshooting by Remote Controller Si37-701
226 Troubleshooting
<Selection of setting item>
<Monitor mode>
<Confirmation of malfunction 1>
To enter the monitor mode, push the
MODE (BS1) button when in
“Setting mode 1”.
Push the SET (BS2) button and set
the LED display to a setting item.
Push the RETURN (BS3) button
once to display "First digit" of
malfunction code.
<Confirmation of malfunction 2>
Push the SET (BS2) button once to
display "Second digit" of malfunction
code.
Push the RETURN (BS3) button and
switches to the initial status of
“Monitor mode”.
∗ Push the MODE (BS1) button and
returns to “Setting mode 1”.
<Confirmation of malfunction 3>
Push the SET (BS2) button once to
display "malfunction location".
* Refer Page 196 for Monitor mode.
* Refer Page 196 for Monitor mode.
Detail
description
on next
page.
<Confirmation of malfunction 4>
Push the SET (BS2) button once to
display "master or slave 1 or slave 2"
and "malfunction location".
Malfunction code indication by outdoor unit
PC board
Malfunctions Malfunction
code
Description of malfunction Description of malfunction (PGF) Remote
controller
PC board malfunction PC board malfunction E1
Faulty PC board
Abnormal discharge pressure HPS activated E3
Abnormal suction pressure Pe malfunction E4
Compressor lock INV compressor lock detected E5
OC activation STD1 compressor lock detected E6
STD2 compressor lock detected
Overload, overcurrent and abnormal
lock of outdoor unit fan motor
Instantaneous overcurrent of 1DC fan
motor
E7
1DC fan motor lock detected
Instantaneous overcurrent of 2DC fan
motor
2DC fan motor lock detected
Electronic expansion valve
malfunction
EV4M (main) E9
EV3J (refrigerant charging)
EV2T (subcool heat exchanger)
Positioning signal malfunction of
outdoor unit fan motor
1DC fan motor positioning signal
malfunction
H7
2DC fan motor positioning signal
malfunction
Abnormal outdoor temperature Ta sensor malfunction (short-circuited
or open)
H9
Abnormal discharge pipe temperature Td malfunction F3
Abnormal heat exchanger
temperature
Refrigerant overcharged F6
BS unit electronic expansion valve
malfunction
BS EVH disconnected (Y4E) F9
BS EVL disconnected (Y5E)
BS EVHS disconnected (Y2E)
BS EVLS disconnected (Y3E)
BS EVSC disconnected (Y4C)
Current sensor malfunction CT1 sensor malfunction (STD
compressor 1)
J2
CT2 sensor malfunction (STD
compressor 2)
CT sensor malfunction (system)
Discharge pipe temperature sensor
malfunction
Tdi sensor malfunction (R31T) J3
Tds1 sensor malfunction (short-
circuited) (R32T)
Tds2 sensor malfunction (short-
circuited) (R33T)
Heat exchanger gas temperature
sensor malfunction
Tg sensor malfunction (R2T, R11T) J4
Suction pipe temperature sensor
malfunction
TsA sensor malfunction (short-
circuited) (R8T, R10T)
J5
Heat exchanger temperature sensor
malfunction
Tb sensor malfunction (R4T, R12T) J6
Liquid pipe temperature sensor
malfunction
Tsc sensor malfunction (R6T, R14T) J7
TL sensor malfunction (R9T)
Heat exchanger liquid pipe
temperature sensor malfunction
Tf sensor malfunction (R7T, R15T) J8
Subcool heat exchanger temperature
sensor malfunction
Tsh sensor malfunction (R5T, R13T) J9
Discharge pressure sensor
malfunction
Pc sensor malfunction (S1NPH) JA
Suction pressure sensor malfunction Pe sensor malfunction (S1NPL) JC
8
: ON
9
: Blink
1
: OFF
