FOREWORD
ThankyouforpurchasingthisneIcomproduct.TheID-51A
or ID-51E
v h f /u h f t r a n s c e i v e r is designed and build with
Icom’s superior technology and craftsmanship combining tra-
ditional analog technologies with the new digital technology,
Digital Smart Technologies for Amateur Radio (D-STAR), for
abalancedpackage.
With proper care, this product should provide you with years
of trouble-free operation.
WethankyouformakingyourID-51AorID-51Eyourradioof
choice, and hope you agree with Icom’s philosophy of “tech-
nology first.” Many hours or research and development went
into the design of your ID-51A or ID-51E.
FEATURES
Dual independent receivers in one radio; ❍
receives two bands simultaneously
Two band monitoring plus the Broadcast
(BC) Radio
•Dependingontheselectedoperatingmode,Dual-
watch or Triple-watch cannot be made.
Rapid charging is possible, and the charg- ❍
ing time period is approximately 3 hours
with the supplied battery pack. (Half peri-
ods of the ID-31A/E)
Built-in GPS receiver allows you to check ❍
your current position, or automatically send
a reply with your position to the called
ID-51A/E
Voice recorder records your QSO conver- ❍
sation, voice audio for TX and microphone
voice audio
microSD card slot that can accept different ❍
cards to backup settings, various memo-
ries, the GPS log and so on
