Icom ID-51A [42/56] Recording a qso onto a microsd card
![Icom ID-51A [42/56] Recording a qso onto a microsd card](/views2/1074074/page42/bg2a.png)
New2001New2001
41
10
RECORDING A QSO ONTO A microSD CARD
New2001
STEP 3
Recording a QSO audio
Push D-pad(Ent) to stop e
voice recording.
•The transceiver displays “Re-
cording stopped,” and auto-
matically exitstheQuick Menu
screen.
Push [QUICK] q to enter
theQuickMenuscreen.
Push D-pad( w ) to select
“<<REC Start>>.”
Push D-pad(Ent) to start e
voice recording.
•The transceiver displays “Re-
cording started” and auto-
matically exitstheQuick Menu
screen.
•“ ” appears while the trans-
ceiver is recording.
•“ ” appears while the record-
ing is paused.
•Recording is continuous until
you manually stop recording, or
the card becomes full.
•If the recording le’s content
reaches 2GB, the transceiver
automatically creates a new
file, and continues recording.
To D stop recording
Push [QUICK] q to enter
theQuickMenuscreen.
Push D-pad( w ) to select
“<<REC Stop>>.”
D-pad
(�)
(Ent)
While recording
While pausing
Convenient! ✓
When the PTT Automatic Recording function is set to ON in
the MENU screen, the recording automatically starts when
[PTT] is pushed.
( MENU > Voice Memo > QSO Recorder > Recorder Set >
PTT Auto REC)
NOTE: BC Radio audio cannot be recorded.
