Icom ID-51A [17/56] Important notes
![Icom ID-51A [17/56] Important notes](/views2/1074074/page17/bg11.png)
New2001
16
D When using the GPS receiver
•GPSsignalscannotpassthroughmetalobjects.Whenus-
ing the ID-51A or ID-51E inside a vehicle, you may not re-
ceive GPS signals. We recommend you use it near a win-
dow. Please avoid the areas shown in the following:
1.DONOTusewhereitwillblockthedriver’sview.
2. DO NOT use where the air bags could deploy.
3. DO NOT use where it becomes a driving obstacle.
•TheGlobalPositioningSystem(GPS)isbuiltandoperated
by the U.S. Department of Defence. The Department is re-
sponsible for accuracy and maintenance of the system. Any
changes by the Department may affect the accuracy and
function of the GPS system.
•When the GPSreceiver isactivated, please do notcover
theID-51AorID-51Ewithanythingthatwillblockthesatel-
lite signals.
•TheGPSreceivermaynotworkifusedinthefollowingloca-
tions:
1. Tunnels or high-rise buildings
2.Undergroundparkinglots
3. Under a bridge or viaduct
4. In remote forested areas
5. Under bad weather conditions (rainy or cloudy day)
•TheGPSreceivermaynotworkifthetransceiveroperates
near the 440.205 MHz. This is due to signals made in the
internal circuit and does not indicate a transceiver malfunc-
tion.
D Spurious signals
Depending on the combination of the operating band and
mode, the Dualwatch or Triple-watch operation may generate
certain spurious signals, or noise may be heard. These do not
indicate a transceiver malfunction.
D
About charging at power ON
ID-51A/E’schargingcircuitchargesthesuppliedbatterypack
in approximately 3 hours. But with this rapid circuit, the bat-
terypackcannotbechargedatpowerON,bydefault.So,be
sure to turn OFF the power before charging.
When “Charging (Power ON)”* is set to ON in the MENU screen,
thebatterypackcanbechargedevenifthepowerisON.(Only
whenthebatterypackis attached, and the optional CP-12L,
CP-19RorOPC-254L externalDCpowercableisconnected
to [DC IN].) But this operation may generate certain spurious
signals; the S-meter appears, or noise may be heard.
*MENU > Function > Charging (Power ON) (Default: OFF)
•Charging time period at power ON may differ, depending on the
operating condition.
•TheexternalDCpowersupplyvoltagemustbebetween10–16V,
and the current capacity must be more than 2.5 A to charge the
batterypackwhenoperating.
•Whenyouoperatethetransceiverwhilecharging,andifyoucannot
receive signals correctly, set “Charging (Power ON)”* to OFF, and
disconnect the external DC power cable from [DC IN].
IMPORTANT NOTES
