New2001
10
EXPLICIT DEFINITIONS
WORD DEFINITION
R DANGER!
Personal death, serious injury or an ex-
plosion may occur.
R WARNING!
Personal injury, fire hazard or electric
shockmayoccur.
CAUTION Equipment damage may occur.
NOTE
Recommendedforoptimumuse.Norisk
ofpersonalinjury,reorelectricshock.
IMPORTANT
READ ALL INSTRUCTIONS carefully and completely
before using the transceiver.
SAvE THIS INSTRUCTION MANUAL— This in-
struction manual contains basic operating instructions for the
ID-51A/ID-51E.
SUPPLIED ACCESSORIES
The following accessories are supplied with the transceiver.
q Antenna .......................................................................... 1
w Hand strap ..................................................................... 1
e Battery charger (BC-167SA/SD/SV)* ............................. 1
r Belt clip .......................................................................... 1
tBatterypack(BP-271) .................................................... 1
y CD (Including the CS-51
c l o n i n g s o f t w a r e ) ................. 1
* Not supplied, or the shape is different, depending on the
transceiver version.
qew
ryt
