GPS LOGGER FUNCTION
New2001
12
GPS LOGGER FUNCTION
STEP 2
Turning ON the GPS Logger function
q Push [MENU] to enter
the Menu screen.
Push D-pad( w ) to select the
root item (GPS), and then
push D-pad(Ent) to go to the
next level.
D-pad
(�)
(Ent)
( MENU > GPS > GPS Logger
> GPS Logger)
Refer to the menu sequence e
shown directly above and
push D-pad() to select, and
then push D-pad(Ent) to en-
ter, one or more times until
the last screen is displayed.
r Push D-pad() to select
“ON.”
Push [MENU] t
to exit the
Menu screen.
•TheGPSLoggerstarts.
NOTE:
•OncetheGPSloggerfunctionisturned ON,thetrans-
ceiver continuously stores the position data from the
GPS receiver, even if the transceiver is rebooted. To can-
cel this function, turn the function OFF.
While this function is ON, and when the transceiver is
turned OFF, the log file will be closed. Then the trans-
ceiver is turned ON and positioning is carried out by the
GPS receiver, a new log file will be created.
•WhenthemicroSDcardisfull,thisfunctionwillbeauto-
matically paused.
<About log file>
You can display your route as you move, if you import the log
file into a mapping software.
•Youcanseeyourrouteonthesoftwaremap.Thelesmaynotbe
compatible with all mapping software.
•SeethePDFtypeAdvancedInstructionforcopyingthelogleto
your PC.
Go to step r
