RECORDING A QSO ONTO A microSD CARD
New2001
10
RECORDING A QSO ONTO A
microSD CARD
When using a preformatted brand new microSD card, format-
ting is not necessary. However, we still recommend you format
it in the following way to get the card’s best performance.
IMPORTANT!
Formatting a card erases all its data. Before formatting any
programmedcard,makeabackupleontoyourPC.
D-pad
(�)
(Ent)
STEP 2
Format the microSD card
After formatting, the display u
automatically returns to the
SD CARD menu.
Push [MENU]
to return
to the frequency display.
q Turn ON the transceiver.
•“ ” appears when the micro
SD card is inserted.
•“ ” and “ ” alternately blinks
while accessing the microSD
card.
w Push [MENU] to enter
the Menu screen.
Push D-pad( e ) to select “SD
Card,” then push D-pad(Ent).
The confirmation screen “For- t
mat OK?” appears.
Push D-pad( y ) to select
“YES,” then push D-pad(Ent)
to format.
•The formatting starts and the
display shows the formatting
progress.
Shows the formatting
progress
Push D-pad( r ) to select “For-
mat,” then push D-pad(Ent).
Go to step t
