Chapter 2: Hardware Information

2-6

9. Twist each of the four screws with a screwdriver just enough to attach the heatsink to

the motherboard. When the four screws are attached, tighten them one by one in a

diagonal sequence to complete the installation.

The heatsink screws are T20 models. A torque value of 16.1±1.2 kgf-cm (14.0±1.0 lbf-in) is

recommended.
