ASUS RS500A-E10 Series

4-19

15. M.2 (NGFF) connectors (NGFF1)

This connector allows you to install M.2 devices.

The M.2 (NGFF) device is purchased separately.

This connector supports type 2242/2260/2280/22110 devices on both PCI-E and SATA

interface.

16. Mezzanine PCIE card connectors (MEZZPCIE1-2)

The Mezzanine PCIE connector supports Open Compute Project (OCP) cards.
