INTELLIGENT KEY SYSTEM
BL-135
C
D
E
F
G
H
J
K
L
M
A
B
BL
WARNING AND ALARM FUNCTION
Operation Description
Warnings and alarms shown as follows and are given to the user as warning notice when using the combina-
tions of Intelligent Key warning buzzer (driver door), inside vehicle buzzer (in combination meter), and warning
lamps “KEY” and “LOCK.”
● Ignition switch return forgotten warning
With the ignition in OFF or ACC position, if the driver door is opened, this warning is issued.
● Key left in ignition warning (when mechanical key is used)
While the mechanical key in the ignition knob and the ignition switch is in the OFF, ACC, or LOCK posi-
tion, if the driver door is opened, this warning is issued.
● Ignition switch OFF position warning (combination buzzer: when door closed)
This warning is issued when the user forgets to return the ignition knob to the LOCK position.
● Ignition switch OFF position warning [Intelligent key warning buzzer (driver door): when door opened/
closed]
This warning is issued when the user leaving the car without returning the ignition knob to the LOCK posi-
tion.
● This warning is issued if the Intelligent Key is taken outside the car while the engine is running. (when
door open → closed)
● This warning is issued if the Intelligent Key is taken outside the car through a window while the engine is
running. (from window)
● Intelligent Key low battery warning
This warning is issued when it detects that the battery in the Intelligent Key is running low.
Operation Condition
Condition Operation
Ignition knob rotation possible “KEY” warning lamp in combination meter is lit up green.
Ignition knob rotation not possible “KEY” warning lamp in combination meter is lit up red.
Warning and alarm names Operating conditions (when all the conditions below are met)
Ignition knob return forgotten warn-
ing
● The ignition switch is in the ACC, OFF, or LOCK position (knob pressed)
● The driver door is opened.
Ignition key warning
(When mechanical key used)
● The mechanical key is inserted in the ignition knob (key switch: ON)
● The ignition switch is in the ACC, OFF, or LOCK position.
● The driver door opened.
Ignition knob OFF position warning
(driver side door buzzer: when door
closed)
● The ignition switch is in the OFF or LOCK position (knob pressed)
● In the above state, when the ACC switch is switched from ON to OFF and 1 second
passes. (However, this warning is not issued if the mechanical key is inserted in the igni-
tion knob.)
Ignition knob OFF position warning
(E/G room buzzer: when door
opened/closed)
● The ignition switch is in the OFF or LOCK position (knob pressed)
● In the above state, when the ACC switch is changed from ON to OFF and 1 second
passes. (However, this warning is not issued if the mechanical key is inserted in the igni-
tion knob.)
● Driver door open → closed
Warning for Intelligent Key taken
outside the car (when door open →
closed)
When Any of the Following Conditions Are Met
● When the ignition knob is pressed in so that it can be rotated (or has been rotated), if any
of the doors has been opened, when all the doors are closed, the Intelligent Key unit
compares the key-ID with the Intelligent Key using the inside key antenna (center con-
sole), if the results of the comparison are NG (the Intelligent Key is not found)
● When the ignition knob is pressed and rotated (or has been rotated), if any of the doors is
open, the Intelligent Key unit compares the key-ID with that of the Intelligent Key every 5
seconds using the inside key antenna (center console), if the results of the comparison
are NG (the Intelligent Key is not found)
NOTE:
However, this warning is not issued if the mechanical key is inserted in the ignition knob.
