POWERDOORLOCKSYSTEM
BL-17
C
D
E
F
G
H
J
K
L
M
A
B
BL
System Description
BIS000I7
OPERATION
Power is supplied (Without Intelligent Key System)
● through to 40A fusible link (letter J , located in the fusible link box)
● to BCM terminal 74 and 79.
● through 10A fuse [No.9, located in the fuse box (J/B)]
● to key switch terminal 2.
Power is supplied (With Intelligent Key System)
● through to 40A fusible link (letter J , located in the fusible link box)
● to BCM terminal 74 and 79.
● through 10A fuse [No.13, located in the fuse box (J/B)]
● to key switch and ignition knob switch terminal 1 and 3.
When the key switch is ON (Ignition key is inserted in ignition key cylinder), power is supplied (Without Intelli-
gent Key system)
● through key switch terminal 1
● to BCM terminal 3.
When the key switch is ON (Ignition key is inserted in ignition key cylinder), power is supplied. (With Intelligent
Key system)
● through key switch and ignition knob switch terminal 4
● to BCM terminal 3.
● to Intelligent Key unit terminal 7.
When the ignition switch is ON or START, power is supplied
● through 10A fuse [No. 5, located in the fuse block (J/B)]
● to BCM terminal 24.
Ground is supplied
● through BCM terminals 2 and 70
● to body ground M21 and M66.
When the front door switch LH (LHD Models) or RH (RHD Models) is ON (door is open), ground is supplied
● through BCM terminal 29
● through front door switch LH (LHD Models) or RH (RHD Models) terminal 1
● to front door switch LH (LHD Models) or RH (RHD Models) case ground.
When the front door switch RH (LHD Models) or LH (RHD Models) is ON (door is open), ground is supplied
● through BCM terminal 30
● through front door switch RH (LHD Models) or LH (RHD Models) terminal 1
● to front door switch RH (LHD Models) or LH (RHD Models) case ground.
When the rear door switch LH is ON (door is open), ground is supplied
● through BCM terminal 59
● through rear door switch LH terminal 1
● to rear door switch LH case ground.
1. BCM (Body Control Module)
M57, M58, M59
2. Front door lock actuator
Driver side: D11
Passenger side: D28
3. Rear door lock actuator
RH: D65
LH: D45
4. Front door switch
RH: B29
LH: B14
5. Rear door switch
RH: B42
LH: B19
6. Key switch and ignition knob switch
connector M34
(With Intelligent Key system)
7. Key switch connector M33
(Without Intelligent Key system)
8. Intelligent Key unit M60
(With Intelligent Key system)
9. Door lock/unlock switch M54
10. Back door switch D104 11. Back door release actuator B46 12. Door lock relay M20
(With Intelligent Key system)
