BL-158
INTELLIGENT KEY SYSTEM
KEY WARNING LAMP DOES NOT ILLUMINATE
NOTE:
● Before performing the diagnosis in the following table, check “Trouble Diagnosis Procedure”. Refer to BL-
153, "Trouble Diagnosis Procedure" .
● Make sure that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis,
and check each symptom.
● If the following “symptoms” are detected, check systems shown in the “Diagnoses/service procedure” col-
umninthisorder.
● Check if ignition switch turns using mechanical key. If it turns, check if “ENGINE START BY I-KEY” in
“WORK SUPPORT” mode is ON.
Conditions of Vehicle (Operating Conditions)
● Intelligent Key is registered.
● Key is not inserted in ignition switch.
● One or more registered Intelligent Keys are in the vehicle.
SELF-DIAGNOSIS RESULTS ARE NOT DISPLAYED
NOTE:
● Before performing the diagnosis in the following table, check “Trouble Diagnosis Procedure”. Refer to BL-
153, "Trouble Diagnosis Procedure" .
● Make sure that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis,
and check each symptom.
● If the following “symptoms” are detected, check systems shown in the “Diagnoses/service procedure” col-
umninthisorder.
Conditions of Vehicle (Operating Conditions)
● Intelligent Key is registered.
● Multiple mechanical keys are not set in a keyfob.
(If mechanical keys are near the ignition switch, the operation may not work properly.)
ENGINE START CONDITION CHECK
NOTE:
● Before performing the diagnosis in the following table, check “Trouble Diagnosis Procedure”. Refer to BL-
153, "Trouble Diagnosis Procedure" .
● If the following “symptoms” are detected, check systems shown in the ”Diagnoses/service procedure” col-
umninthisorder.
Symptom Diagnosis/service procedure Reference page
Ignition switch does not turn on with Intelligent Key.
(KEY warning lamp does not illuminate.)
1.
Check Intelligent Key unit power supply and ground
circuit.
BL-164
2. Check ignition knob switch. BL-168
3. Check key switch. BL-165
4. Replace Intelligent Key unit. BL-193
Symptom Diagnosis/service procedure Reference page
Ignition switch does not turn on with mechani-
cal key.
1. Check key switch. BL-165
2. Check NATS antenna amp. BL-233
Symptom Diagnosis/service procedure Reference page
Engine start condition check 1. Check stop lamp switch. BL-192
