BL-160
INTELLIGENT KEY SYSTEM
● If the following “symptoms” are detected, check systems shown in the “Diagnosis/service procedure” col-
umninthisorder.
Conditions of Vehicle (Operating Conditions)
● Ignition switch is not depressed.
● All doors are closed.
Symptom Diagnosis/service procedure
Reference
page
All of the remote keyless entry functions
do not operate.
1. Check Intelligent Key battery inspection. BL-193
2. Replace Intelligent Key unit. BL-193
Anti-hijack function does not operate by
Intelligent Key button.
1.
Check “SELECTIVE UNLOCK FUNCTION” setting in “WORK
SUPPORT”.
BL-156
2. Check Intelligent Key battery inspection. BL-193
3. Replace Intelligent Key unit. BL-193
Auto lock function does not operate.
1. Check “AUTO RELOCK TIMER” setting in “WORK SUPPORT”. BL-156
2. Check key switch. BL-165
3. Check ignition knob switch. BL-168
4. Check door switch. BL-174
5. Replace Intelligent Key unit. BL-193
Key reminder function does not operate.
1. Check door switch. BL-174
2. Check inside key antenna. BL-187
3. Check Intelligent Key battery inspection. BL-193
4. Replace Intelligent Key unit. BL-193
