POWER DOOR LOCK — SUPER LOCK —
BL-61
C
D
E
F
G
H
J
K
L
M
A
B
BL
● through rear door switch RH terminal 1
● to rear door switch RH case ground.
DOOR LOCK AND UNLOCK SWITCH OPERATION
When door lock/unlock switch is in LOCK position, ground is supplied
● through BCM terminal 6.
● through door lock/unlock switch terminal 2 and 3
● to body grounds M21 and M66
With power and ground supplied, doors are locked.
When door lock/unlock switch is in UNLOCK position, ground is supplied
● through BCM terminal 25
● through door lock/unlock switch terminal 2 and 3
● to body grounds M21and M66
With power and ground supplied, all doors are unlocked.
Lock/unlock switch indicated by LED when key in switch is on or on with timer.
BACK DOOR SWITCH OPERATION
When the back door switch is turn on, back door is opened
Ground is supplied
● through BCM terminal 5
● through back door switch terminal 1 and 2
● to body ground B13, B28, B38 and B48.
BACK DOOR RELEASE ACTUATOR OPERATION
When the back door release actuator receives a release signal from BCM
Ground is supplied
● through BCM terminal 68
● through back door release actuator terminal 4 and 3
● to body ground B13, B28, B38 and B48.
BACK DOOR SWITCH OPERATION
When the back door switch is opened, ground is supplied
● through BCM terminal 10
● through back door switch terminal 2 and 1
● to body ground B13, B28, B38 and B48.
KEY REMINDER SYSTEM
● If the ignition key is in the ignition key cylinder and driver door is open, setting door lock/unlock switch, key
or remote controller to “LOCK” locks the door once but then immediately unlocks all doors.
UNLOCK LINK FUNCTION
When this function is activated, if the car is locked by door lock/unlock switch, opening the driver or passenger
side door from the inside handle will override the lock state and unlock the whole car.
(This function will be deactivate if anti-hijack function is activated.)
Selectable Function
BACK DOOR OPENER OPERTION
Back door can be opened with back door switch: When all door are unlocked, or When back door request
switch is pushed (With Intelligent Key system).
Door Lock/unlock switch
How to change setting Press unlock for more than 4 seconds
Contents Unlock link activate/deactivate
How to confirm Buzzer should sound for 0.2 seconds
