SERVICE DATA AND SPECIFICATIONS (SDS)
EM-215
[HR]
C
D
E
F
G
H
I
J
K
L
M
A
EM
SERVICE DATA AND SPECIFICATIONS (SDS) PFP:00030
Standard and Limit
BBS002PC
GENERAL SPECIFICATIONS
DRIVE BELT
Belt Deflection:
*: When engine is cold.
EXHAUST MANIFOLD
Unit: mm (in)
SPARK PLUG (PLATINUM-TIPPED TYPE)
Unit: mm (in)
CYLINDER HEAD
Unit: mm (in)
Engine type HR16DE
Cylinder arrangement In-line 4
Displacement
cm
3
(cu in)
1,598 (97.51)
Bore and stroke mm (in) 78.0 x 83.6 (3.070 x 3.291)
Valve arrangement DOHC
Firing order 1-3-4-2
Number of piston rings
Compression 2
Oil 1
Compression ratio 9.8
Compression pressure
kPa (bar, kg/cm
2
,psi)/200rpm
Standard 1,510 (15.1, 15.4, 219)
Minimum 1,265 (12.69, 12.9, 183)
Differential limit between cylinders 981 (9.81, 10.0, 142)
Location
Deflection adjustment * Unit: mm (in)
Used belt
New belt
Limit After adjusted
Drive belt With A/C models 7.9 (0.31) 4.8 - 5.3 (0.19 - 0.21) 4.2 - 4.5 (0.17 - 0.18)
Without A/C models 7.1 (0.28) 4.3 - 4.7 (0.17 - 0.19) 3.6 - 3.9 (0.14 - 0.15)
Applied pushing force 98 N (10 kg, 22lb)
Items Limit
Surface distortion 0.3 (0.012)
Make NGK
Standard type PLZKAR6A-11
Hot type PLZKAR5A-11
Cold type PLZKAR7A-11
Spark plug gap Standard 1.1 (0.043)
Items Limit
Head surface distortion 0.1 (0.004)
