SPARK PLUG (PLATINUM-TIPPED TYPE)
EM-31
[CR]
C
D
E
F
G
H
I
J
K
L
M
A
EM
● Checking and adjusting plug gap is not required between
change intervals.
INSTALLATION
Install in the reverse order of removal.
SMA806CA
Spark plug
: 19.6 - 29.4 N·m (2.0 - 3.0 kg-m, 15 - 21 ft-lb)
