OPTION menu
Function
Command Direction
Parameter Reply Control/Response contents *
DATE/TIME SETTING DATE
WR
AABBCCDDEE AABBCCDDEE
AA: Year, BB: Month, CC: Day, DD: Time, EE: Minute
Yes
SCHEDULE SC01-
SC08
WR ABCDEFFGGH ABCDEFFGGH Schedule of a specified number
A: Schedule 0 = Not effective, 1 = Effective
B: Power 0 = OFF, 1 = ON
C: Day of the week 1 0 = Only once, 1 = Every week, 2 = Every day
D: Day of the week 2 0 = Sunday, 1 = Monday through 6 = Saturday,
9 = Not exist
E: Day of the week 3 0 = Sunday, 1 = Monday through 6 = Saturday,
9 = Not exist
F: Time
00-23
G: Minute 00-59
H: Input 0 = Not specified, 1 = PC1/AV1, 2 = PC2,
3 = PC3/AV2, 4 = AV3
Yes
DVI SELECT DVSL WR 0-1 0-1 0: PC (DIGITAL), 1: AV (DIGITAL) Yes
BNC SELECT BNSL WR 0-1 0-1 0: PC (ANALOG), 1: AV (COMPONENT) Yes
QUICK SHOOT (PC)
QSPC WR 0-1 0-1 0: OFF, 1: ON Yes
QUICK SHOOT (AV) QSAV
WR 0-1 0-1 0: OFF, 1: ON Yes
COLOR SYSTEM CSYS WR 0-5 0-5 0: AUTO, 1: PAL, 2: PAL-60, 3: SECAM, 4: NTSC 3.58, 5: NTSC 4.43 Yes
AUDIO OUTPUT AOUT WR 0-1 0-1 0: VARIABLE, 1: FIXED Yes
INPUT
RESOLUTION
(PC)
RESOLUTION
CHECK
PXCK R - Returns current resolution in the form of hhh, vvv.
No
PIXEL SETTING
(PC2, PC3)
PXSL WR 1 1 V: 768) 1360 x 768
2 2 V: 768) 1280 x 768
3 3 V: 768) 1024 x 768
5 5 V: 480) 848 x 480
6 6 V: 480) 640 x 480
INPUT
RESOLUTION
(AV)
RESOLUTION
CHECK
RESO R - 480i, 480p, 1080i, 720p, 1080p, VGA, etc.
No
SELF ADJUST AADJ WR 0-1 0-1 0: OFF, 1: ON Yes
POWER MANAGEMENT PMNG WR 0-1 0-1 0: OFF, 1: ON Yes
AUTO INPUT CHANGE
AINC WR 0-1 0-1 0: OFF, 1: ON Yes
ENLARGE menu (When the input mode is PC)
Function
Command Direction
Parameter Reply Control/Response contents *
ENLARGE MODE EMAG WR 0-4 0-4 0: OFF, 1: 2 x 2, 2: 3 x 3, 3: 4 x 4, 4: 5 x 5
No
BEZEL WIDTH
WIDTH OF THE
SHORTER
SIDE
BEZH WR 0-100 0-100
WIDTH OF THE
LONGER SIDE
BEZV WR 0-100 0-100
IMAGE POSITION (2 x 2) EPOS WR 0-3 0-3 See page 21.
IMAGE POSITION (3 x 3) EPOS WR 0-8 0-8
IMAGE POSITION (4 x 4) EPOS WR 0-15 0-15
IMAGE POSITION (5 x 5) EPOS WR 0-24 0-24
ENLARGED
SCREEN
POSITIONING
THE LONGEST
DIRECTION
EPSH WR -999-999 -999-999 The setting range depends on the ENLARGE MODE setting and the
IMAGE POSITION.
THE SHORTEST
DIRECTION
EPSV WR -999-999 -999-999
ENLARGE/IMAGE POSITION SETTING ESTG WR XXYY XXYY XX: ENLARGE MODE (Same as EMAG), YY: IMAGE POSITION (Same
as EPOS)
PIP/PbyP menu
Function
Command Direction
Parameter Reply Control/Response contents *
PIP MODES
MWIN WR 0-3 0-3 0: OFF, 1: PIP, 2: PbyP, 3: PbyP2 Yes
PIP SIZE
MPSZ WR 1-12 1-12 Yes
PIP POS THE LONGEST
DIRECTION
MHPS W 0-100 Yes
R 0-100 Yes
THE SHORTEST
DIRECTION
MVPS W 0-100 Yes
R 0-100 Yes
PIP V/H-POS
MPOS W 0-100,0-100 Specify the position in MPOSxxxyyy format.
(xxx: Longer side, yyy: Shorter side position)
Yes
R 0-100,0-100 Returns a response in (xxx,yyy) format.
(xxx: Longer side, yyy: Shorter side position)
Yes
PIP BLEND
MWBL WR 0-15 0-15 Yes
PIP SOURCE
MWIP WR 1 1 PC1 DIGITAL
Yes
2 2 PC2 ANALOG
3 3 AV2 COMPONENT
4 4 AV3 VIDEO
6 6 PC3 ANALOG
7 7 AV1 DIGITAL
SOUND CHANGE MWAD WR 1-2 1-2 1: MAIN, 2: SUB Yes
MAIN POS (Main screen) MWPP WR 0-1 0-1 0: POS1, 1: POS2 Yes
PbyP2 POS (Sub screen) MW2P WR 0-2 0-2 0: POS1, 1: POS2, 2: POS3 Yes
AUTO OFF
MOFF WR 0-1 0-1 0: MANUAL, 1: AUTO Yes
