7. The JavaClient Viewer
115
Click to zoom the remote display window.
Note: This feature is only available in windowed mode (Full Screen
Mode is off). See Zoom, page 121, for details.
Click to bring up the on-screen keyboard (see The On-Screen
Keyboard, page 122).
Click to select the mouse pointer type.
Note: This icon changes depending on which mouse pointer type is
selected (see Mouse Pointer Type, page 122).
Click to toggle Automatic or Manual mouse sync.
When the selection is Automatic, the icon to the right appears.
When the selection is Manual, a
/
appears over the icon.
(See Mouse DynaSync Mode, page 104 for a complete explanation
of this feature.)
Click to display a drop-down list of User macros. Access and run
macros more conveniently rather than using the Macros dialog box
(see the Macros icon in the table above, and the Macros section on
page 116).
Click this icon to open a Viewer based GUI with the web browsers
administrative functionalities.
Click to bring up the Control Panel Configuration dialog box.
See Control Panel Configuration, page 123, for details on configuring
the Control Panel.
Click to exit the remote view.
These icons show the Num Lock, Caps Lock, and Scroll Lock status
of the remote computer.
When the lock state is On, the LED is bright green and the lock
hasp is closed.
When the lock state is Off, the LED is dull green and the lock hasp
is open.
Click on the icon to toggle the status.
Note: When you first connect, the LED display may not be accurate.
To be sure, click on the LEDs to set them.
Icon Function
