CN8000A User Manual

166

PPP Modem Operation

Basic Setup

In addition to the browser and AP methods, the CN8000A can also be accessed

through its RS-232 port using a PPP dial-in connection, as follows:

1. Set up your hardware configuration to match the diagram, below:

2. From your computer, use your modem terminal program to dial into the

CN8000A’s modem.

Note: 1. If you don’t know the CN8000A modem’s serial parameters, get

them from the CN8000A administrator.

2. An example of setting up a modem terminal program under

Windows XP is provided on the next page.

3. Once the connection is established, open your browser, and specify

192.168.192.1 in the URL box.

From here, operation is the same as if you had logged in from a browser or with

the AP programs.

Remote

Operator

Modem Modem

Phone Line

Serial Modem Cable Serial Modem Cable
