1. Introduction
5
Console
Management
Serial console management – serial terminal access. Access the
CN8000A via a built-in serial viewer, or via third party software
(such as PuTTY) for Telnet and SSH sessions.
Out of Band Support – via dial up modem support. Access the
CN8000A through its RS-232 port using a dial-up connection.
Upgradeable
Firmware over
the Internet
No need to add yet another cable to your installation – stay current
with the latest functionality improvements and updates, all over the
Internet.
Remote Power
Control
You can add a PON (Power Over the NET™) power management
unit and remotely control the power status of devices on your
installation, including monitoring their current status, as well as
turning servers On, Off and Rebooting them.
Mouse DynaSync No need to re-sync your mouse – Mouse DynaSync provides
automatic locked-in synching of the remote and local mouse
pointers – eliminating the need to constantly resync the two
movements. Your local console mouse movement becomes the
remote unit’s mouse movement.
Full-Screen or
Sizable Remote
Desktop Window
Get a full screen even if your monitor’s resolution is lower than the
remote computer’s resolution. In full-screen mode the remote
desktop display scales to the user’s monitor display size. Supports
up to 1920 x 1200 @ 60Hz; 24-bit color depth for remote sessions.
DDNS Allows the mapping of a dynamic IP address assigned by a DHCP
server to a hostname.
End session Administrators can terminate running sessions
Features Benefits
